FERROLI
TEMPRA - (Appliance Overview)
Appliance Code: 41-267-06

Appliance Diagram


Appliance Overview diagram for Ferroli TempraClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE SUPPORT UPPER - PRESSURE SWITCH
Ferroli part no. 818130
3   OBSOLETE SUPPORT - AIR PRESSURE SWITCH LOWER 100FF
Ferroli part no. 818141
5   OBSOLETE FITTINGS - MOUNTING JIG
Ferroli part no. 806949
7   BRACKET - PILOT
Ferroli part no. 31209560		 £0.47
8   OBSOLETE PLATE - FLUE GASES BAFFLE
Ferroli part no. 806684
17 Part number 39801090, TEST POINT - "GAS/AIR" TEST POINT - "GAS/AIR"
Ferroli part no. 39801090		 £5.39
17 Part number 33400280, NOW USE 39801090 TEST POINT - NOW USE 39801090 TEST POINT -
Ferroli part no. 33400280
18 Part number 30810710, WASHER - 3/4" CF4324 (K42) WASHER - 3/4" CF4324 (K42)
Ferroli part no. 30810710		 £0.19
19   OBSOLETE GASKET - PUMP
Ferroli part no. 806290
20 Part number 33700381, WASHER - PRESSURE GAUGE WASHER - PRESSURE GAUGE
Ferroli part no. 33700381		 £0.71
21 Part number 30810850, WASHER - 1/2" CF4324 (K42) WASHER - 1/2" CF4324 (K42)
Ferroli part no. 30810850		 £0.19
22   GASKET - 38MM
Ferroli part no. 33700420		 £1.15
23 Part number 33700480, GASKET -INJECTOR GASKET -INJECTOR
Ferroli part no. 33700480		 £1.70
24 Part number 33700530, GASKET - EXPANSION VESSEL GASKET - EXPANSION VESSEL
Ferroli part no. 33700530		 £0.33
26   INJECTOR - PILOT (0.22-LPG)
Ferroli part no. 39801470		 £4.31
29 Part number 34007430, NUT - 3/4" JIG VALVE NUT - 3/4" JIG VALVE
Ferroli part no. 34007430
30   OBSOLETE NUT 1/8IN RING
Ferroli part no. 818430
32   INJECTOR - MAIN (0.77-LPG)
Ferroli part no. 34009651		 £1.42
32   INJECTOR - MAIN (1.20-NG)
Ferroli part no. 34009790		 £1.96
33 Part number 39801520, TEST POINT - PRESSURE "AIR" TEST POINT - PRESSURE "AIR"
Ferroli part no. 39801520		 £4.65
33 Part number 34010240, NOW USE 39801520 TEST POINT - "FAN" NOW USE 39801520 TEST POINT - "FAN"
Ferroli part no. 34010240
34   TEST POINT -
Ferroli part no. 33400250		 £2.39
37   SHROUD - SIGHT INSPECTION GLASS COVER E50
Ferroli part no. 34100431		 £1.96
39 Part number 39801290, KNOB - SELECTOR SWITCH KNOB - SELECTOR SWITCH
Ferroli part no. 39801290		 £5.75
39 Part number 35001800, KNOB - SELECTOR SWITCH KNOB - SELECTOR SWITCH
Ferroli part no. 35001800
41   OBSOLETE GASKET 27.5MM C/W GUIDE
Ferroli part no. 806159
42   OBSOLETE INSULATION - COMBUSTION CHAMBER SIDE
Ferroli part no. 806401
43 Part number 39835890, BURNER COVER GASKET E51 (OR USE 39806250 AS ALTERNATIVE) BURNER COVER GASKET E51 (OR USE 39806250 AS ALTERNATIVE)
Ferroli part no. 39835890		 £33.88
43   NOW USE 39835890 SIGHT GLASS - BURNER INSPECTION E50
Ferroli part no. 35315240
44   SIGHT GLASS - 50MM X 30MM X 3.3MM
Ferroli part no. 39821970		 £19.83
44   NOW USE 39821970 SIGHT GLASS - 50MM X 30MM X 3.3MM
Ferroli part no. 35315250
45   OBSOLETE INSULATION - COMBUSTION CHAMBER REAR
Ferroli part no. 806028
48 Part number 39822040, SWITCH - ON/OFF DOUBLE POLE SWITCH - ON/OFF DOUBLE POLE
Ferroli part no. 39822040		 £17.75
48 Part number 36100360, NOW USE 39822040 SWITCH - ON/OFF DOUBLE POLE NOW USE 39822040 SWITCH - ON/OFF DOUBLE POLE
Ferroli part no. 36100360
49 Part number 39802290, THERMOSTAT - BOILER THERMOSTAT - BOILER
Ferroli part no. 39802290		 £36.50
49 Part number 36401210, NOW USE 39802290 THERMOSTAT - BOILER NOW USE 39802290 THERMOSTAT - BOILER
Ferroli part no. 36401210
50 Part number 39800180, THERMOSTAT - 14 DEG FROST THERMOSTAT - 14 DEG FROST
Ferroli part no. 39800180		 £8.14
51 Part number 39800160, THERMOSTAT - 88 DEG CH LIMIT THERMOSTAT - 88 DEG CH LIMIT
Ferroli part no. 39800160		 £9.06
52 Part number 36401450, THERMOSTAT - 1000C MANUAL RESET THERMOSTAT - 1000C MANUAL RESET
Ferroli part no. 36401450
53 Part number 39800140, AIR PRESSURE SWITCH AIR PRESSURE SWITCH
Ferroli part no. 39800140		 £50.11
55 Part number 39805840, GAUGE - PRESSURE GAUGE - PRESSURE
Ferroli part no. 39805840		 £22.42
60   OBSOLETE INSULATION BUSHING SHORT - BLACK NYLON
Ferroli part no. 814860
62 Part number 39805810, PCB - FULL AUTO CONTROL-S4585D PCB - FULL AUTO CONTROL-S4585D
Ferroli part no. 39805810		 £328.37
66 Part number 39805820, FAN ASSEMBLY FAN ASSEMBLY
Ferroli part no. 39805820		 £170.62
67   PUMP ASSEMBLE
Ferroli part no. 36601220		 £35.81
68 Part number 39800220, RELAY - 6 PIN 24VOLT DC RELAY - 6 PIN 24VOLT DC
Ferroli part no. 39800220
69   OBSOLETE PILOT ASSEMBLY - TEMPRA
Ferroli part no. 800244
70 Part number 39821450, EXPANSION VESSEL - ( 6 LITRE ) EXPANSION VESSEL - ( 6 LITRE )
Ferroli part no. 39821450		 £200.37
70 Part number 36801060, NOW USE 39821450 EXPANSION VESSEL - ( 6 LITRE ) NOW USE 39821450 EXPANSION VESSEL - ( 6 LITRE )
Ferroli part no. 36801060
71 Part number 39805790, GAS VALVE - VK4100C GAS VALVE - VK4100C
Ferroli part no. 39805790		 £198.38
72 Part number 39800130, SAFETY VALVE - 3 BAR SAFETY VALVE - 3 BAR
Ferroli part no. 39800130		 £21.23
73   OBSOLETE AUTO AIR VENT
Ferroli part no. 36901450
74   OBSOLETE JACKET-WRAP ROUND (TEMPRA)
Ferroli part no. 806343
75   OBSOLETE BRACKET - WIRING SUPPORT
Ferroli part no. 806458
76   COMBUSTION CHAMBER
Ferroli part no. 37402440		 £43.38
77   PANEL - COMBUSTION CHAMBER
Ferroli part no. 37402470		 £28.68
78   OBSOLETE ROOM SEALED COMPARTMENT
Ferroli part no. 806441
79   SMOKE BOX
Ferroli part no. 37514430		 £28.93
80   ROOM SEALED COMPARTMENT
Ferroli part no. 37514440		 £20.25
81   BURNER - MAIN
Ferroli part no. 30806333		 £234.42
82   OBSOLETE
Ferroli part no. 38404920
83   PIPE - GAS VALVE TO MANIFOLD
Ferroli part no. 38404930
84   PIPE - PUMP
Ferroli part no. 38404940		 £8.68
85   OBSOLETE PIPE - HEAT EXCHANGER TO PUMP
Ferroli part no. 809950
86   OBSOLETE PIPE - SYSTEM FLOW
Ferroli part no. 809960
87   PIPE - EXPANSION VESSEL
Ferroli part no. 38404970		 £5.28
89 Part number 39800530, GASKET - COMBUSTION CHAMBER (10mm X10mm) GASKET - COMBUSTION CHAMBER (10MM X10MM)
Ferroli part no. 39800530		 £21.59
90 Part number 37402460, HEAT EXCHANGER HEAT EXCHANGER
Ferroli part no. 37402460		 £310.71
