GLOWWORM
MIAMI 3 BBU F.FRONT TEAK - (Burner)
Appliance Code: 37-047-04A

Appliance Diagram


Burner diagram for Glowworm Miami 3 BBU F.Front TeakClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE HEAT EXCHANGER
Glowworm part no. 2000800763

3   INSUL-CASING BOARD
Glowworm part no. 411932

3   INSULATION - CASING BOARD
Glowworm part no. S411932

4   OBSOLETE SPARES-AIR GUIDE +FEET
Glowworm part no. 2000800765

5 Part number 203746, NOW USE S203746 RADIANT PACK(203701 PACKED) NOW USE S203746 RADIANT PACK(203701 PACKED)
Glowworm part no. 203746

5 Part number S203746, Radiant pack RADIANT PACK
Glowworm part no. S203746

6 Part number 427504, DRESS GUARD DRESS GUARD
Glowworm part no. 427504

6 Part number 2000801477, DRESS GUARD DRESS GUARD
Glowworm part no. 2000801477

7   OBSOLETE FLUE SPIGOT ASY (SW) GLSGLG
Glowworm part no. 427024

8   OBSOLETE PLINTH ASSY MIAMI3/MEL BBU
Glowworm part no. 459077

9 Part number 427524, CONTROL KNOB ASSY CONTROL KNOB ASSY
Glowworm part no. 427524

9 Part number S427524, Control knob CONTROL KNOB
Glowworm part no. S427524

11 Part number 2000800713, Supply tube with nuts & olives SUPPLY TUBE WITH NUTS & OLIVES
Glowworm part no. 2000800713

12   SCREW -M5X10MM
Glowworm part no. SK6214
£6.61
13 Part number SK6219, Nut NUT
Glowworm part no. SK6219

14   RADIANT SPACER (NPF) CTGLG+
Glowworm part no. 423011

14   RADIANT SPACER
Glowworm part no. S423011

15 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330

16   H/E FRONT TRIM (DE-BURR)CTGLG+
Glowworm part no. 423071

16   FRONT TRIM-HEAT EXCHANGER
Glowworm part no. S423071

18   SILENCER
Glowworm part no. S423029

18   SILENCER ASSY--PH CTGLG+
Glowworm part no. 423029

19   NOW USE S208283 SCREW-M4X16MM+5DG MS PN
Glowworm part no. 208283

19   SCREW ( M4X16MM )
Glowworm part no. S208283

20   OBSOLETE SPARES-REAR PANEL MONARCH BBU
Glowworm part no. 2000800764

21 Part number 204718, CONNECTING ROD CONNECTING ROD
Glowworm part no. 204718

21 Part number S204718, CONNECTING ROD CONNECTING ROD
Glowworm part no. S204718

22 Part number SK5148, Split pin -3/32 dia X 3/4 SPLIT PIN -3/32 DIA X 3/4
Glowworm part no. SK5148

23   INJECTOR
Glowworm part no. S205735

23   INJECTOR-BRAY CAT 19/130
Glowworm part no. 205735

24   INJECTOR
Glowworm part no. S205736

24   INJECTOR-BRAY CAT 22/240
Glowworm part no. 205736

25 Part number 2000800772, Oxypilot OXYPILOT
Glowworm part no. 2000800772

26 Part number 203653, CONTROL TAP-C/W ELBOW CONTROL TAP-C/W ELBOW
Glowworm part no. 203653

26 Part number S203653, CONTROL TAP-C/W ELBOW CONTROL TAP-C/W ELBOW
Glowworm part no. S203653

27 Part number 417019, NUT-COMP-4MM-SIT 0.958.030 NUT-COMP-4MM-SIT 0.958.030
Glowworm part no. 417019

27 Part number S417019, Nut - Compression 4mm NUT - COMPRESSION 4MM
Glowworm part no. S417019

28 Part number S208737, SILICONE TUBE-40MM CLEAR SILICONE TUBE-40MM CLEAR
Glowworm part no. S208737
£6.61
28 Part number 208737, NOW USE S208737 SILICONE TUBE-40MM CLEAR NOW USE S208737 SILICONE TUBE-40MM CLEAR
Glowworm part no. 208737

29   SCREW-M4X8MM MS PN REC
Glowworm part no. 403014

29   SCREW - M4X8MM
Glowworm part no. S403014

30 Part number 800766, Pilot pipe assembly PILOT PIPE ASSEMBLY
Glowworm part no. 800766

31   OLIVE-5/32 QC
Glowworm part no. 66360012

31   OLIVE - 5/32
Glowworm part no. S66360012

32   BURNER
Glowworm part no. S900606

32   BURNER - ALTERNATIVES
Glowworm part no. 900606

33   NUT - LOCK M15
Glowworm part no. SK8833

34   IGNITION LEAD
Glowworm part no. SWW4615

35   OBSOLETE CASING SUB ASSY-MIAM.FIRE TEAK
Glowworm part no. 451211

36   OBSOLETE BEZEL - PRINTED MIAMI3 BBU
Glowworm part no. 459074

37   WASHER-SEAL 1/2X3/16X1/16 BSW
Glowworm part no. 69953

37   WASHER - SEAL 1/2X3/16X1/16
Glowworm part no. S69953

38   SCREW ( NO.6 X 1/2 )
Glowworm part no. S208377
£5.58
38   NOW USE S208377 SCREW-NO.6 X 1/2 REC
Glowworm part no. 208377

39   OBSOLETE CONV APERT ASSY-PNTD
Glowworm part no. 427612

40   SCREW (NO 8X1/2)
Glowworm part no. SK7688

41   RADIANT TRIM ASSY
Glowworm part no. 451206

41   RADIANT TRIM
Glowworm part no. S451206

42   OBSOLETE FRONT PANEL - PNTD
Glowworm part no. 451204

43   SPRING CLIP
Glowworm part no. 208656

43   SPRING CLIP
Glowworm part no. S208656

44 Part number SFF0652, Screw, no6 x 3/8 SCREW, NO6 X 3/8
Glowworm part no. SFF0652

45 Part number SK8019, Screw ( M5X10mm ) SCREW ( M5X10MM )
Glowworm part no. SK8019
£6.61
46   CASE CLAMP.PLATE (P) G/ALL-G
Glowworm part no. 427618

46   CASE CLAMP.PLATE
Glowworm part no. S427618

47   REAR SURROUND TOP
Glowworm part no. S427603

47   REAR SURR TOP ASSY G
Glowworm part no. 427603

48   CASING LOCATION BRKT(PCF) GLG+
Glowworm part no. 427526

48   CASING LOCATION BRACKET
Glowworm part no. S427526

49   LOUVRE ASSEMBLY-REAR SIDE
Glowworm part no. S427025

49   RR SIDE LOUVRE ASY-PNTD GLSGLG
Glowworm part no. 427025

50   PLINTH GUIDE (NPF) GLSGLG
Glowworm part no. 427528

50   PLINTH GUIDE
Glowworm part no. S427528

51   SEAL
Glowworm part no. S212064

51   KASEAL-13X4X630MM RA51/PLASMAR
Glowworm part no. 212064

52   OBSOLETE CASING TOP TRIM (DE-BURR) GLG+
Glowworm part no. 427509

53   REINFORCING STRIP(PF)GALALGLG+
Glowworm part no. 427534

53   REINFORCING STRIP
Glowworm part no. S427534

57   NOW USE S204244 END CAP - DRESS GUARD
Glowworm part no. 204244

57   END CAP - DRESS GUARD
Glowworm part no. S204244
£4.29
61   OBSOLETE SENSING TUBE FITTING-OPUS/OPUL
Glowworm part no. S204971

61   OBSOLETE SENSING TUBE FITTING-OPUS/OPUL
Glowworm part no. 204971

62 Part number 208680, SENSING TUBE FILTER SENSING TUBE FILTER
Glowworm part no. 208680

62 Part number S208680, Filter - Sensing tube FILTER - SENSING TUBE
Glowworm part no. S208680

63   SCREW ( M4 X 6MM )
Glowworm part no. S208365

63   SCREW-M4 X 6MM REC
Glowworm part no. 208365

64   UNION NUT-6MM FLARED
Glowworm part no. S204810

64   UNION NUT-6MM FLARED
Glowworm part no. 204810

66 Part number 451461, UPPER SENSING TUBE-(F) UPPER SENSING TUBE-(F)
Glowworm part no. 451461

66 Part number S451461, Upper sensing tube UPPER SENSING TUBE
Glowworm part no. S451461

67   CLIP-CTRL KNOB-TRW 17020-07
Glowworm part no. 204631

67   CLIP
Glowworm part no. S204631

68   UNION NUT-5/32 OLIVE
Glowworm part no. S204966

68   UNION NUT-5/32 OLIVE
Glowworm part no. 204966

69   UNION NUT 3/8 BSPF
Glowworm part no. 12248

69   UNION NUT 3/8 BSPF
Glowworm part no. S12248

70   OLIVE - 3/8 DIA
Glowworm part no. SK4740
