IDEAL
VICEROY MK 5 IS 622 OIL 5 - 19 SECTIONS - (Boiler Assembly 1)
Appliance Code: IS 622 MK5

Appliance Diagram


Boiler Assembly 1 diagram for Ideal Viceroy MK 5 IS 622 Oil 5 - 19 SectionsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE COC BASE RETAIN CLIP V/ROY
Ideal part no. 052676

0   OBSOLETE V PRESS T/METER (150VPR37P4)
Ideal part no. 065727

0   OBSOLETE FIBRE WASHER 1/16 AF2000
Ideal part no. 052689

0   OBSOLETE BURNER ADAPTER PLATE GASKET VROY
Ideal part no. 048513

0   OBSOLETE TAPERFILL 10MM H1060210/56 (29M)
Ideal part no. 083184

0   OBSOLETE 5LB TINS NO.5 MASTIC
Ideal part no. 000418

0   OBSOLETE M8 HEX NUT BRASS
Ideal part no. 002232

0   OBSOLETE TRI-WING NUT VRY
Ideal part no. 035217

0   OBSOLETE 5LB TIN BLACK BLR PUTTY
Ideal part no. 000759

0   OBSOLETE M8 FORM F WASHER
Ideal part no. 000618

0   OBSOLETE M8 X 70 HEX HD SET SCREW
Ideal part no. 000617

0   M8 HEX NUT ZP DES SPEC 0250
Ideal part no. 003380
£2.36
0   OBSOLETE BNR ADAPTER PLT V/ROY 9
Ideal part no. 052244

4   OBSOLETE SECTION SET NIPPLES
Ideal part no. 076585

5   OBSOLETE REF TILE 300X400X40MM: VICEROY
Ideal part no. 043047

6   OBSOLETE TOP TAPPED FLANGE
Ideal part no. 030154

7   OBSOLETE FLOW ADAPTER:VICEROY 18
Ideal part no. 052400

8   OBSOLETE RETURN ADAPTER VICEROY
Ideal part no. 052527

9   OBSOLETE BLANK FLANGE (FOR DIST TUBE)
Ideal part no. 030155

10   OBSOLETE 182X130X3MM RUBBER GASKET
Ideal part no. 011111

11   OBSOLETE SEALING GASKETS 182 X 95 X 3MM
Ideal part no. 011112

12   OBSOLETE RUBBER GASKETS 160X108X3MM
Ideal part no. 011113

13   OBSOLETE TDOM BOLTS S/ASSY VISCOUNT
Ideal part no. 010683

14   OBSOLETE SET ASS RODS VICEROY 5SECT
Ideal part no. 076586

15   OBSOLETE ASSY RODS 770 VICEROY 6 SECT
Ideal part no. 076587

16   OBSOLETE ASSY RODS V/ROY 7SECT (AC)
Ideal part no. 076588

17   OBSOLETE ASSY RODS V/ROY 8 SECT
Ideal part no. 076589

18   OBSOLETE ASSY RODS VICEROY 9 SECT
Ideal part no. 076590

19   OBSOLETE SS RODS W/FGTS V/ROY 10 SECT
Ideal part no. 076591

20   OBSOLETE ASSY RODS VRY 11 SECT
Ideal part no. 076592

21   OBSOLETE SET ASSEM RODS V/ROY 12 SECT
Ideal part no. 076593

22   OBSOLETE ASSY RODS W/FXGS VICEROY 13
Ideal part no. 076594

23   OBSOLETE ASSY RODS VICEROY 14SECT
Ideal part no. 076595

24   OBSOLETE SET ASSY RODS V/ROY 15 SECT
Ideal part no. 076596

25   OBSOLETE ASSY RODS V/ROY 16 SECT
Ideal part no. 076597

26   OBSOLETE TIE ROD/ASS ROD PKG:VCRY 17
Ideal part no. 059459

27   OBSOLETE TIE ROD/ASS ROD PKG:VCRY 18
Ideal part no. 059460

28   OBSOLETE TIE ROD/ASS ROD PKG:VCRY 19
Ideal part no. 059461

29   OBSOLETE SET ASSEMBLING COLLS & WASHERS
Ideal part no. 076621

30   OBSOLETE SET FLAT & SPRING WASHERS
Ideal part no. 076584

31   OBSOLETE DIST TUBE ASSY 5SECT VROY
Ideal part no. 038761

32   OBSOLETE DIST TUBE ASSY 6SECT VROY
Ideal part no. 040610

33   OBSOLETE DIST TUBE ASSY 7SECT VROY
Ideal part no. 040611

34   OBSOLETE DIST TUBE ASSY 8SECT VROY
Ideal part no. 040612

35   OBSOLETE DIST TUBE ASSY 9SECT VROY
Ideal part no. 040613

36   OBSOLETE DIST TUBE ASSY 10 SECT VROY
Ideal part no. 040614

37   OBSOLETE DIST TUBE ASSY 11SECT VROY
Ideal part no. 076599

38   OBSOLETE DIST TUBE ASSY 12 SECT VROY
Ideal part no. 076600

39   OBSOLETE DIST TUBE ASSY 13 SECT VROY
Ideal part no. 076601

40   OBSOLETE DIST TUBE ASSY 14SECT VROY
Ideal part no. 076602

41   OBSOLETE DIST TUBE ASSY 15SECT VROY
Ideal part no. 076603

42   OBSOLETE DIST TUBE ASSY 16SECT VROY
Ideal part no. 076604

43   OBSOLETE DIST TUBE ASSY 17SECT VROY
Ideal part no. 078663

44   OBSOLETE DIST TUBE ASSY 18SECT VROY
Ideal part no. 078664

45   OBSOLETE DIST TUBE ASSY 19SECT VROY
Ideal part no. 078665

46   OBSOLETE DIST TUBE ASSY 11-16SECT VROY
Ideal part no. 076598

47   OBSOLETE DISTRIBUTOR TUBE EXT W/FTGS
Ideal part no. 078660

48   OBSOLETE DIST TUBE EXT W/FTGS VROY 18
Ideal part no. 078661

49   OBSOLETE DISTRIBUTOR TUBE EXT W/FTGS
Ideal part no. 078662

50   OBSOLETE HINGE MTG PLT S/ASS VICEROY
Ideal part no. 053291

52   OBSOLETE HINGE PIN W/FTGS
Ideal part no. 076607

53   OBSOLETE S/GLASS ASSY KIT VRY/FALC
Ideal part no. 077268

54   OBSOLETE VICEROY QUARL 125MM. 1357/0
Ideal part no. 052688

55   OBSOLETE QUARL 160MM:VICEROY
Ideal part no. 052687

56   OBSOLETE QUARL 220MM:VICEROY
Ideal part no. 052686

58   OBSOLETE C/O COVER S/ASS-S/HOOD:VICEROY
Ideal part no. 039239

59   OBSOLETE 20MM OVAL ROPE
Ideal part no. 076583

60   OBSOLETE SM/HOOD FL ADAPTER PK:VRY 8-10
Ideal part no. 059465

61   OBSOLETE SM/HOOD FL ADAPTER PK:VRY 11-14
Ideal part no. 059466

62   OBSOLETE SM/HOOD FL ADAPTER PK:VRY 15-19
Ideal part no. 059467

63   OBSOLETE UPPER C.O.C. ASSY MK 3 VICEROY
Ideal part no. 076605

64   OBSOLETE GASKET CO COVER VICEROY
Ideal part no. 010641

65   OBSOLETE LOWER C.O.C.V/ROY
Ideal part no. 076606

66   OBSOLETE GASKET CO COVER VICEROY
Ideal part no. 038249

68   OBSOLETE TREBLE COVER GASKET.FOR V/ROY MK
Ideal part no. 052677

70   OBSOLETE DOUBLE COVER GASKET.FOR V/ROY MK
Ideal part no. 052678

71   OBSOLETE T/STAT L & G RAZ13/2890B VCRY
Ideal part no. 013384

72   OBSOLETE WIRING HARNESS W/FXGS
Ideal part no. 076622

73   OBSOLETE TKD 3504 THERMOSTAT VICEROY
Ideal part no. 047636

74   OBSOLETE WIRING HARNESS HI-LOW:VISCOUNT
Ideal part no. 058399

75   OBSOLETE P/GAUGE 150/A/A/E/3/3 0-6BAR
Ideal part no. 003973

76   OBSOLETE P/GAUGE 150/A/A/E/3/3 0-1BAR
Ideal part no. 003974

78   OBSOLETE P/GAUGE 150/A/A/3/3 0-2.5BAR
Ideal part no. 003976

79   OBSOLETE P/GAUGE 150/A/A/E/3/3 0-4BAR
Ideal part no. 003977

80   OBSOLETE VAPOUR PRESSURE THERMOMETER 15
Ideal part no. 003972

82   OBSOLETE CONTROL BOX-SATRONIC TMG 740/1
Ideal part no. 065096

83   OBSOLETE MMI 810.1 MOD 43 C/BOX SATRONIC.
Ideal part no. 065138

84   OBSOLETE JKT SIDE PANEL A ASS:VCRY 5/19
Ideal part no. 059442

85   OBSOLETE JKT SIDE PANEL B ASS VCRY 5/19
Ideal part no. 059443

86   OBSOLETE JKT SIDE PANEL C ASS VRY 5/19
Ideal part no. 059444

87   OBSOLETE JKT TOP PNL D ASS:VRY 5/19
Ideal part no. 059445

88   OBSOLETE JKT TOP PNL E ASS VRY 5/19 A
Ideal part no. 059446

89   OBSOLETE JKT TOP PNL F ASS VRY 7/19 A
Ideal part no. 059447

90   OBSOLETE FRT PANEL G RH VRY (A)
Ideal part no. 058396

91   OBSOLETE FRT PANEL LH H VRY (A)
Ideal part no. 058397

92   OBSOLETE RH REAR
Ideal part no. 058394

93   OBSOLETE JACKET LH REAR PANEL ASS:VCRY
Ideal part no. 058395

94   OBSOLETE JACKET INSTRUMENT PANEL H
Ideal part no. 059440

96   OBSOLETE JKT PKG:VCRY 5/6 (A)
Ideal part no. 058712

97   OBSOLETE JKT PKG:VCRY 7/8 SECT (A)
Ideal part no. 058713

98   OBSOLETE JKT PKG:VCRY 9/10 SECT
Ideal part no. 058714

99   OBSOLETE JKT PKG:VCRY 11/12
Ideal part no. 058715

100   OBSOLETE JKT PKG:VCRY 13/14 SECT
Ideal part no. 058716

101   OBSOLETE JKT PKG:VCRY 15/16 SECT
Ideal part no. 058717

104   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078666

105   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078667

106   OBSOLETE INSUL W/3 CLIPS VICEROY
Ideal part no. 078668

107   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078669

108   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078670

109   OBSOLETE INSUL W/3 CLIPS & 3 ADH PADS
Ideal part no. 078671

110   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078672

111   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078673

112   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078674

113   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078690

114   OBSOLETE INSULATION W/FXGS VICEROY
Ideal part no. 078691

116   OBSOLETE F/BRUSH FLEXI VERT COMP V/ROY
Ideal part no. 017156

117   OBSOLETE FLUE BRUSH 5 X 5 X 5 WIRE
Ideal part no. 017018

119   OBSOLETE FLUE BRUSH HEAD VERTICAL
Ideal part no. 017086

120   OBSOLETE T/STAT & HARNESS PK NO 2:VRY
Ideal part no. 058693
