IDEAL
CONCORD SUPER SERIES 4- 300 V & H - (Boiler Assembly 1)
Appliance Code: SUPER MK4 300

Appliance Diagram


Boiler Assembly 1 diagram for Ideal Concord Super Series 4- 300 V & HClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   SD INSL PNL LESS HOLE SUPER
Ideal part no. 056274		 £55.60
1   HT EXCH ASS SUPER VH SER 4
Ideal part no. 100805		 £3,156.68
1   HT EXCH ASS SUPER HH SER 4
Ideal part no. 100806		 £3,164.60
2   TOP COVER PLATE SUPER 4
Ideal part no. 057829		 £402.00
3 Part number 100936, TOP COVER GASKET SUPER 4 TOP COVER GASKET SUPER 4
Ideal part no. 100936		 £15.93
4 Part number 054699, BTM COVER PLT SUPER 4 A BTM COVER PLT SUPER 4 A
Ideal part no. 054699		 £206.71
5 Part number 100935, BTM COVER GASKET SUPER 4 BTM COVER GASKET SUPER 4
Ideal part no. 100935		 £15.93
6 Part number 078152, NOW USE 171968 GAS DIST SCREENS CONCORD SUPER 50 K NOW USE 171968 GAS DIST SCREENS CONCORD SUPER 50 K
Ideal part no. 078152
6 Part number 171968, GAS DISTRIBUTION SCREEN + SCREWS GAS DISTRIBUTION SCREEN + SCREWS
Ideal part no. 171968		 £92.82
7   FLOW PIPE C/WGSKT SUPER 4 - HZNTL
Ideal part no. 079757		 £145.31
7   OBSOLETE TDOM ROD SET 4 M10X 425/8 NUTS
Ideal part no. 078676
8 Part number 079758, RETURN PIPE C/WGSKT SUPER 4 RETURN PIPE C/WGSKT SUPER 4
Ideal part no. 079758		 £124.33
8   RETURN PIPE C/W GSKT SUPER4
Ideal part no. 079759		 £204.32
9 Part number 012593, TRIANGULAR GASKET SUPER TRIANGULAR GASKET SUPER
Ideal part no. 012593		 £9.60
10 Part number 055865, T/STAT POCKET ASS 6339004 T/STAT POCKET ASS 6339004
Ideal part no. 055865		 £25.42
11   T/STAT POCKET 100MM X 7MM
Ideal part no. 003573		 £33.76
12   MODULE COVER ASS SUPER 4 HORZ
Ideal part no. 100824		 £403.39
12   MODULE COVER ASS SUPER 4 VERT
Ideal part no. 100823		 £363.15
13   H/WARE PK-MODULE SUPER 4
Ideal part no. 100822		 £21.42
14 Part number 100619, MODULE FILTER SUPER 4 MODULE FILTER SUPER 4
Ideal part no. 100619		 £154.74
15 Part number 170950, FAN ASSY SUPER SER 4(SPARES ONLY) FAN ASSY SUPER SER 4(SPARES ONLY)
Ideal part no. 170950		 £493.70
16   MULTI HOLE PLATE SUPER 4
Ideal part no. 100325		 £11.22
17 Part number 078162, SQUARE/ROUND CAST W/FXG SQUARE/ROUND CAST W/FXG
Ideal part no. 078162		 £129.38
18 Part number 012601, SQUARE CORK GASKET SUPER SQUARE CORK GASKET SUPER
Ideal part no. 012601		 £7.87
19 Part number 012589, GASKET-CORK ROUND SUPER 3 GASKET-CORK ROUND SUPER 3
Ideal part no. 012589		 £8.11
20   GAS TRAIN ASS SUPER 4 VERT
Ideal part no. 100825		 £823.36
20   GAS TRAIN ASS SUPER 4 HORZ
Ideal part no. 100826		 £835.20
21   GAS INJECTOR C/W WASHER SP4
Ideal part no. 079722		 £11.55
22   GAS VALVE ASS SUPER 4
Ideal part no. 079723		 £663.67
23 Part number 058014, BURNER BRAY ASS NO AB 3000 BURNER BRAY ASS NO AB 3000
Ideal part no. 058014		 £248.67
24 Part number 057860, BNR FLG GASKET SUPER 50KV BNR FLG GASKET SUPER 50KV
Ideal part no. 057860		 £6.40
25 Part number 058010, IGN PROBE EARTH LD SUPER4 IGN PROBE EARTH LD SUPER4
Ideal part no. 058010		 £6.17
26 Part number 100613, IGN ELECTRODE ASS SUPER 4 IGN ELECTRODE ASS SUPER 4
Ideal part no. 100613		 £53.48
27 Part number 100612, FLAME DECT ELECTRODE PROBE ASS SUPER 4 FLAME DECT ELECTRODE PROBE ASS SUPER 4
Ideal part no. 100612		 £27.38
28 Part number 078881, SIGHT GLASS ASSY SUP 3 SIGHT GLASS ASSY SUP 3
Ideal part no. 078881		 £21.10
29 Part number 079724, PRESSURE SENSING PIPE SUPER 4 A V/H PRESSURE SENSING PIPE SUPER 4 A V/H
Ideal part no. 079724		 £93.19
30 Part number 079725, PRESSURE SNSG PIPE SUP B 4V/H PRESSURE SNSG PIPE SUP B 4V/H
Ideal part no. 079725		 £62.67
31   NOW USE 179185 L/STAT LM5 SUPER 4
Ideal part no. 004038
31   STAT REPLACEMENT ASSEMBLY FOR 004038
Ideal part no. 179185		 £163.15
32 Part number 013241, CONTROL KNOB T/STAT K526 CONTROL KNOB T/STAT K526
Ideal part no. 013241		 £17.14
33   OBSOLETE POTENTIOMETER SUPER 4
Ideal part no. 100614
33 Part number 100609, POTENTIOMETER HARNESS SUPER 4 POTENTIOMETER HARNESS SUPER 4
Ideal part no. 100609		 £15.08
34 Part number 100814, SOCKET WIRING HARNESS SUPER 4 SOCKET WIRING HARNESS SUPER 4
Ideal part no. 100814		 £15.24
35   MOD CVR FASCIA SUPER 4
Ideal part no. 100816		 £15.14
36   1 1/2 GAS SUPPLY ASS SUPER 4
Ideal part no. 100652		 £720.74
36   1 1/4 GAS SUPPLY ASS SUPER 4
Ideal part no. 100651		 £709.81
37   GAS HEADER ASS SUPER4 H550/600
Ideal part no. 101088		 £1,120.97
37   GAS HEADER ASS SUPER4 V350/400
Ideal part no. 101084		 £977.99
37   GAS HEADER ASS SUPER4 V450/500
Ideal part no. 101085		 £1,069.83
37   GAS HEADER ASS SUPER4 V550/600
Ideal part no. 101086		 £1,148.90
37   GAS HEADER ASS SUPER4 H450/500
Ideal part no. 101087		 £1,062.66
37   GAS HEADER ASS SUPER 4 150VA
Ideal part no. 100965		 £1,162.02
37   GAS HEADER ASS SUPER 4 V100
Ideal part no. 100963		 £546.82
37   GAS HEADER ASS SUPER 4 V150
Ideal part no. 100964		 £831.10
38   REAR GAS HDR ASS SUPER 4 400V
Ideal part no. 100970		 £977.99
38   REAR GAS HDR ASS SUPER 4 350V
Ideal part no. 100969		 £920.98
38   REAR GAS HEADER ASS SUPER 4 500-550H
Ideal part no. 100977		 £1,058.77
38   REAR GAS HDR ASS SUPER 4 450H
Ideal part no. 100976		 £1,033.09
38   REAR GAS HDR ASS SUPER 4 600H
Ideal part no. 100978		 £1,120.97
38   REAR GAS HDR ASS SUPER 4 450V
Ideal part no. 100971		 £1,045.32
38   REAR GAS HDR ASS SUPER 4 600V
Ideal part no. 100973		 £1,151.22
38   REAR GAS HEADER ASS SUPER 4 500/550V
Ideal part no. 100972		 £1,076.98
39 Part number 131343, FLEXIBLE HOSE GAS SUPER 3 FLEXIBLE HOSE GAS SUPER 3
Ideal part no. 131343		 £341.25
39 Part number 005872, FLEXIBLE HOSE(GAS):SERIES 4 FLEXIBLE HOSE(GAS):SERIES 4
Ideal part no. 005872		 £94.59
40   R1 X RC1 SQ HD GAS COCK GASCON
Ideal part no. 002048		 £110.27
40   R1 1/2 X RP1 1/2 SQ HD GAS COCK
Ideal part no. 000875		 £278.88
40   R1 1/4 X RC1 1/4 SQ HD GAS COCK
Ideal part no. 003817		 £258.72
41   FLOW/RTN WATER HEADER SUPER 4 250-600V
Ideal part no. 100271		 £1,642.34
41   WATER HEADER 150VA-400V SERIES 4
Ideal part no. 100270		 £1,103.16
42   H/WARE PK-BOLTS 450-600V
Ideal part no. 100992		 £165.99
42   H/WARE PK-WASHERS 450-600V
Ideal part no. 100994		 £32.33
42   H/WARE PK-NUTS 450/600V
Ideal part no. 100993		 £47.75
42   H/WARE PK-NUTS 450-600H
Ideal part no. 100996		 £34.34
42   H/WARE PK-BOLTS 450-600H
Ideal part no. 100995		 £119.17
42   H/WARE PK-WASHERS 450-600H
Ideal part no. 100997		 £23.43
43   WATER MANIFOLD FLOW SUPER 4
Ideal part no. 100338		 £2,457.73
43   WATER FLOW MANIFOLD SUPER 4
Ideal part no. 100340		 £1,660.70
44   WATER RETURN MANIFOLD SUPER 4
Ideal part no. 100341		 £1,652.51
44   WATER RETURN MANIFOLD SUPER 4
Ideal part no. 100339		 £2,461.67
45   FLOW + RETURN SPOOL PIPE SUP 4
Ideal part no. 100360		 £301.67
45   FLOW/RTN SPOOL SUPER 4
Ideal part no. 100361		 £342.46
46   WATER HDR SUPP BRKT SUPER 4
Ideal part no. 100956		 £84.46
48 Part number 130397, FLEXIBLE CONNECTOR 1 1/2INCH 1303 FLEXIBLE CONNECTOR 1 1/2INCH 1303
Ideal part no. 130397		 £332.21
49   MAIN WIRING HARNESS SUPER 4
Ideal part no. 100606		 £52.93
50   CSG/INSL/TRIMS 100VH SERIES 4
Ideal part no. 100740		 £3,072.72
50   CSG/INSL/TRIMS 450VH SERIES 4
Ideal part no. 100748		 £8,229.38
50   CSG/INSL/TRIMS 400VH SERIES 4
Ideal part no. 100747		 £7,350.61
50   CSG/INSL/TRIMS 550VH SERIES 4
Ideal part no. 100750		 £8,311.70
50   CSG/INSL/TRIMS 450HH SERIES 4
Ideal part no. 100754		 £8,162.11
50   CSG/INSL/TRIMS 600HH SERIES 4
Ideal part no. 100757		 £8,300.81
50   CSG/INSL/TRIMS 500HH SERIES 4
Ideal part no. 100755		 £8,095.51
50   CSG/INSL/TRIMS 550HH SERIES 4
Ideal part no. 100756		 £8,248.75
50   CSG/INSL/TRIMS 500VH SERIES 4
Ideal part no. 100749		 £8,288.83
50   CSG/INSL/TRIMS 250VH SERIES 4
Ideal part no. 100744		 £4,946.76
50   OBSOLETE CSG/INSL/TRIMS 200VH SERIES 4
Ideal part no. 100743
50   CSG/INSL/TRIMS 350VH SERIES 4
Ideal part no. 100746		 £7,181.92
50   CSG/INSL/TRIMS 300VH SERIES 4
Ideal part no. 100745		 £5,006.20
50   CSG/INSL/TRIMS 600VH SERIES 4
Ideal part no. 100751		 £8,415.33
50   CSG/INSL/TRIMS 250HH SERIES 4
Ideal part no. 100752		 £5,023.08
50   CSG/INSL/TRIMS 150VH ALT SER 4
Ideal part no. 100742		 £4,320.03
50   CSG/INSL/TRIMS 50VH SERIES 4
Ideal part no. 100739		 £2,171.70
51   TOP PORTION INSL 350/400V
Ideal part no. 056040		 £122.56
51   TOP PORTION INSL 550/600V
Ideal part no. 056042		 £122.56
51   TOP PORTION INSL 450/500V
Ideal part no. 056041		 £122.56
51   TOP INSL PANEL 250/300V
Ideal part no. 056030		 £70.30
51   TOP PORTION INSL 150VA/200V
Ideal part no. 056029		 £65.90
51   TOP PORTION INSL 250/300H
Ideal part no. 056031		 £137.53
51   TOP PORTION INSULATION 100V
Ideal part no. 056027		 £37.73
51   TOP PORTION INSULATION 50V
Ideal part no. 056026		 £44.23
51   TOP PORTION INSL 150KW
Ideal part no. 056028		 £37.73
52   OBSOLETE TOP INS PNL ENDS SUPER 4
Ideal part no. 058402
53   BACK INSL PNL CONCORD SUPER 464X644
Ideal part no. 056032		 £68.05
53   BACK INSL PNL CONCORD SUPER 464X1774
Ideal part no. 056034		 £207.48
53   BACK INSL PNL CONCORD SUPER 464X1294
Ideal part no. 056033		 £143.91
54   SIDE INSULATION PNL SUPER 4
Ideal part no. 100727		 £36.14
54   SIDE INSULATION PANEL SUPER 4
Ideal part no. 100729		 £45.97
56   FRT PORTION INSL 50V SER 4
Ideal part no. 056037		 £66.95
56 Part number 056038, FRONT INSL SUPER 4 100/400 VH FRONT INSL SUPER 4 100/400 VH
Ideal part no. 056038		 £137.06
56   FRT INSL PANEL SUPER
Ideal part no. 056039		 £205.85
57   TRIM-648MM UPRIGHT 50V S4
Ideal part no. 056520		 £25.29
57   TRIM-UPRIGHT 1778MM SUPER 4
Ideal part no. 056522		 £66.83
57   TRIM-UPRIGHT 1298MM 150/400 S4
Ideal part no. 056521		 £48.96
57   TRIM-914MM UPRIGHT SUP+
Ideal part no. 056628		 £34.44
58   TRIM-TOP FRONT/REAR SUPER 4
Ideal part no. 056630		 £66.83
58   TRIM-TP FRT/REAR 50-150V S4
Ideal part no. 056523		 £17.11
58   TRIM-TP FRT/REAR 150A-600V S4
Ideal part no. 056524		 £34.05
59   TRIM-TP SD 338MM 50/300V+H S4
Ideal part no. 056525		 £13.97
59   TRIM-TP SD 738MM 350/600V+H S4
Ideal part no. 056526		 £28.44
60   CORNER PIECE SUPER 4
Ideal part no. 056589		 £8.92
61   TRIM- T SCT 1755MM 250/600V S4
Ideal part no. 056529		 £58.96
61   TRIM- T SCT 1277MM 200/400V S4
Ideal part no. 056528		 £43.57
61   TRIM- T SCTN 338MM 100-600V S4
Ideal part no. 056527		 £12.73
61   TRIM- T SCTN 914MM 450/600H S4
Ideal part no. 056632		 £31.43
61   TRIM- T SCTN 1735MM 250/600H
Ideal part no. 056633		 £58.33
61   TRIM- T SCTN SHORT 450/600H S4
Ideal part no. 056631		 £25.85
62   CASING FOOT ASS RH 150VA-300V
Ideal part no. 130176		 £122.40
62   CASING FOOT ASS 450-600
Ideal part no. 130179		 £175.64
62   CASING FOOT ASS 250/300HH
Ideal part no. 130178		 £167.66
62   CASING FOOT ASS 350-600V
Ideal part no. 130177		 £135.74
62   CASING FOOT ASS RH 50-150V
Ideal part no. 130116		 £117.31
62   CASING FOOT ASS LH 150VA-300V
Ideal part no. 130175		 £122.40
62   CASING FOOT ASS LH 50-150V
Ideal part no. 130115		 £91.92
63   SLIDE RAIL ASS SUPER 4 50-600V
Ideal part no. 056045		 £26.37
64   FLUE SOCKET/AD PLT ASS 150VA
Ideal part no. 025025		 £82.79
64   FLUE SOCKET/AD PLT ASS SUPER 4
Ideal part no. 024835		 £99.66
65   OBSOLETE BLANKING PLATE PTD SUPER 4
Ideal part no. 055997
66   OBSOLETE 9MM GRADA 515 SILICONE RUBS
Ideal part no. 082704
67   MODULE SUPPORT RING SUPER 4
Ideal part no. 055996		 £87.64
68 Part number 055998, M8 X 57 MODULE FIXING STUD M8 X 57 MODULE FIXING STUD
Ideal part no. 055998		 £5.01
69   M8 X 73 BLANKING PLATE STUD
Ideal part no. 056272		 £5.05
70   H/WARE PK SUPER 4 50V
Ideal part no. 101122		 £114.37
71   OBSOLETE ELBOW MF 3/4INX3/4INFIG 152 MI
Ideal part no. 000032
72   SP NPL 1 1/2 X 287
Ideal part no. 100959		 £58.84
72   SP NPL 1 1/2 X 1380
Ideal part no. 100958		 £54.65
72   SP NPL 1 1/4 X 1353
Ideal part no. 100961		 £45.75
72   SP NPL 1 1/4 X 1390
Ideal part no. 100960		 £45.75
72   SP NPL 1 1/2 X 1892
Ideal part no. 100957		 £78.86
72   SP NPL 1 1/4 X 293
Ideal part no. 100962		 £19.27
73   END CAP RC 1 1/4 IN TAPPED 1/8 IN BSP
Ideal part no. 055261		 £19.11
73   END CAP 1 1/2 IN TAPPED 1/8IN BSP
Ideal part no. 055099		 £20.90
73   END CAP RC 1 IN TAPPED 1/8 IN BSP
Ideal part no. 055260		 £15.18
73   3/4 BSP M/I BLANKING OFF CAPS
Ideal part no. 000039		 £4.92
74   FLANGE BLANK 50NB BS4504 1969
Ideal part no. 004601		 £55.89
74   65NB BLANK FLANGE SUPER 4
Ideal part no. 100225		 £63.51
74   80NB BLANK FLANGE SUPER 4
Ideal part no. 100226		 £80.80
74   40NB TABLE E BLANK FLANGE
Ideal part no. 099967		 £56.06
75   80NB GASKET SUPER 4
Ideal part no. 100233		 £3.73
75 Part number 004595, 50NB FLANGE GASKET 50NB FLANGE GASKET
Ideal part no. 004595		 £8.61
75   40NB TABLE D GASKET SUPER 3
Ideal part no. 012745		 £21.44
76   1/8 PRESSURE TEST NIPPLE
Ideal part no. 000030		 £9.86
78   BULGIN PLUG NO 551
Ideal part no. 003934		 £35.02
79 Part number 060570, PCB 28 BOARD (415200) PCB 28 BOARD (415200)
Ideal part no. 060570		 £477.71
80 Part number 060572, PCB 29 BOARD (415400) PCB 29 BOARD (415400)
Ideal part no. 060572		 £384.65
81 Part number 060571, PCB 30 BOARD (415300) PCB 30 BOARD (415300)
Ideal part no. 060571		 £705.20
82 Part number 003912, DOUBLE POLE ROCKER SWITCH BLK DOUBLE POLE ROCKER SWITCH BLK
Ideal part no. 003912		 £20.35
83 Part number 100610, BOARD TO BOARD HARNESS SUPER 4 BOARD TO BOARD HARNESS SUPER 4
Ideal part no. 100610		 £33.56
84   RESET SWITCH HARNESS SUPER 4
Ideal part no. 100611		 £20.26
85 Part number 013755, SENSOR ASS ST9 SUPER SENSOR ASS ST9 SUPER
Ideal part no. 013755		 £78.07
86   FRONT PNL ASS SUPER 4
Ideal part no. 100700		 £537.63
87   UNION ELBOW 1 1/2 FF GF96 MI
Ideal part no. 002997		 £70.28
87   UNION ELBOW 1 X1 FF FIG 261
Ideal part no. 000441		 £45.59
87   UNION ELBOW 1 1/4IN DF GF96 MI
Ideal part no. 003634		 £59.24
88   OBSOLETE RC3/4 X RC3/4 GAS COCK STRAIGHT
Ideal part no. 004391
89   RC3/4 X RC3/4 UNION GAS COCK
Ideal part no. 000471		 £80.52


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
