IDEAL
VANGUARD S 190-1200 - (Boiler Components)
Appliance Code: Vanguard S 190-1200

Appliance Diagram


Boiler Components diagram for Ideal Vanguard S 190-1200Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

5   SPRING PIN 8 X 28 190-1200 (VIA0009)
Ideal part no. 171818
£12.01
6   DOOR PIVOT PIN 190-1200 (12755)
Ideal part no. 171518
£26.16
7   DOOR SCREW 190-300 (12754)
Ideal part no. 171517
£25.32
9   HEXAGONAL NUT M20 190-600 (12756)
Ideal part no. 171519
£16.30
10   DOOR ASSEMBLY 500-600 (19020)
Ideal part no. 171727
£2,294.66
11   SIGHT GLASS GASKET - GAM0030
Ideal part no. 079857
£15.79
12   BOILER BODY SIGHT GLASS - VES0020
Ideal part no. 079856
£24.91
13 Part number 079858, SIGHT GLASS CIRCLIP - ACM0101 SIGHT GLASS CIRCLIP - ACM0101
Ideal part no. 079858
£11.74
14   BURNER PLATE GASKET 280 SQ (GIN0009)
Ideal part no. 171783
£22.33
20   M12 FORM A WASHER
Ideal part no. 002288
£2.22
21   M12 HEX NUT MS ZP DES SPEC 0250
Ideal part no. 000544
£2.22
26   M8 FORM A WASHER ZP DES SPEC 0250
Ideal part no. 003381
£2.44
27   OBSOLETE M8 HEX NUT BRASS
Ideal part no. 002232
