NU-WAY
NOR 150 MOD - (Burner 1)
Appliance Code: NOR 150 MOD

Appliance Diagram


Burner 1 diagram for Nu-Way NOR 150 ModClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number L06068L, FLAME TUBE 11 X 6 LONG XS9415 FLAME TUBE 11 X 6 LONG XS9415
Nu-Way part no. L06068L		 £125,00
2 Part number L04033X, DIFFUSER 9.00 X3 A2-248/1 DIFFUSER 9.00 X3 A2-248/1
Nu-Way part no. L04033X		 £145,14
3 Part number U90324W, NUWAY ELECTRODE FOR CL8 CH8 3 NOZZLE PAIR NUWAY ELECTRODE FOR CL8 CH8 3 NOZZLE PAIR
Nu-Way part no. U90324W		 £65,30
3 Part number U90325X, NUWAY ELECTRODE' FOR CL8-CH8 4-5 NOZZ PAIR NUWAY ELECTRODE' FOR CL8-CH8 4-5 NOZZ PAIR
Nu-Way part no. U90325X		 £74,72
4 Part number G05022W, DOWTY U SECTION SEAL U105 DOWTY U SECTION SEAL U105
Nu-Way part no. G05022W		 £16,10
4 Part number G05071F, SEAL SET FOR EHF BURNER OIL LANCE SEAL SET FOR EHF BURNER OIL LANCE
Nu-Way part no. G05071F		 £59,72
4 Part number G05072G, FLUIDICS W1 NOZZLE O-RING 86000000 FLUIDICS W1 NOZZLE O-RING 86000000
Nu-Way part no. G05072G		 £3,83
4   CH8 ELECTRIC INN ASSY TO SPEC
Nu-Way part no. U90045S		 £1 621,63
5 Part number U90400G, HT LEADS FOR A, P, SB. PAIR (1200mm) HT LEADS FOR A, P, SB. PAIR (1200MM)
Nu-Way part no. U90400G		 £70,80
6   BURNER MOTOR 11KW 380-420/3/50 2850 TEFC IE3
Nu-Way part no. A19003Y		 £971,28
6   15KW (20HP) 415-3-50HZ 2850RPM IE3
Nu-Way part no. A21001Q		 £1 080,63
7 Part number D16002R, FAN 16 X 4.0 X 2.75IN E10959 ITEM1 FAN 16 X 4.0 X 2.75IN E10959 ITEM1
Nu-Way part no. D16002R		 £250,31
7 Part number D17002J, FAN 17 X 3.5 X 2.75IN E10959 ITEM3 FAN 17 X 3.5 X 2.75IN E10959 ITEM3
Nu-Way part no. D17002J		 £254,57
8 Part number G01007C, TAPERLOCK ADAPTER 1615A FENNER TAPERLOCK ADAPTER 1615A FENNER
Nu-Way part no. G01007C		 £79,65
8 Part number G02027Y, TAPERLOCK BUSH 1615 42mm FENNER TAPERLOCK BUSH 1615 42MM FENNER
Nu-Way part no. G02027Y		 £33,15
9 Part number T99119H, PRE-HEATER TANK BATTERY 9KW PRE-HEATER TANK BATTERY 9KW
Nu-Way part no. T99119H		 £1 671,32
9 Part number T99120E, PRE-HEATER TANK BATTERY 12KW PRE-HEATER TANK BATTERY 12KW
Nu-Way part no. T99120E		 £1 722,30
10 Part number G09066N, GASKET 7.5-9KW HTR TANK A2-688 GASKET 7.5-9KW HTR TANK A2-688
Nu-Way part no. G09066N		 £6,96
11 Part number C40028R, JOHNSON THERMOSTAT ACS E571 0 - 160C 5/16DIA STEM JOHNSON THERMOSTAT ACS E571 0 - 160C 5/16DIA STEM
Nu-Way part no. C40028R		 £314,54
11 Part number C40032D, JOHNSON THERMOSTAT ACS C587 70 -130 C JOHNSON THERMOSTAT ACS C587 70 -130 C
Nu-Way part no. C40032D		 £249,63
11 Part number C40033E, JOHNSON THERMOSTAT ACS B592 80 - 140C JOHNSON THERMOSTAT ACS B592 80 - 140C
Nu-Way part no. C40033E		 £230,01
11 Part number C40046K, ACS/C371CW3 7IN C/W POCKET&WT KIT **USE C40-066P** ACS/C371CW3 7IN C/W POCKET&WT KIT **USE C40-066P**
Nu-Way part no. C40046K		 £352,63
11 Part number C40088N, JOHNSON THERMOSTAT ACS/E518 T/STAT 50-250 C JOHNSON THERMOSTAT ACS/E518 T/STAT 50-250 C
Nu-Way part no. C40088N		 £335,34
11 Part number C40066P, OBSOLETE SUNVIC TK3501 THERMOSTAT 20-90DEG OBSOLETE SUNVIC TK3501 THERMOSTAT 20-90DEG
Nu-Way part no. C40066P
12 Part number E03028S, OIL FILTER ELEMENT A4-511 REF:F928 OIL FILTER ELEMENT A4-511 REF:F928
Nu-Way part no. E03028S		 £88,65
12 Part number G09019P, GASKET HOT OIL FILTER E10547 GASKET HOT OIL FILTER E10547
Nu-Way part no. G09019P		 £2,96
13 Part number G24002V, THERMOCOUPLE 0-160DEG C/F 6.3mm DIA THERMOCOUPLE 0-160DEG C/F 6.3MM DIA
Nu-Way part no. G24002V		 £80,19
14 Part number G04005D, P/GAUGE 50mm DIA X .125BSP 0-600 PSI GLYCERINE FILLED P/GAUGE 50MM DIA X .125BSP 0-600 PSI GLYCERINE FILLED
Nu-Way part no. G04005D		 £16,02
15 Part number G03018G, NUWAY COUPLING QUICK RELEASE 1/2INBSP VITON SEALS NUWAY COUPLING QUICK RELEASE 1/2INBSP VITON SEALS
Nu-Way part no. G03018G		 £33,41
16 Part number B16027Q, LUCIFER COIL 481044A7 220V 50HZ 14 WATTS LUCIFER COIL 481044A7 220V 50HZ 14 WATTS
Nu-Way part no. B16027Q		 £73,50
16 Part number C52004A, SOLENOID TYPE 7308/240/50/ 7308-20 SOLENOID TYPE 7308/240/50/ 7308-20
Nu-Way part no. C52004A		 £212,30
16 Part number E01003Y, LUCIFER SOLENOID VALVE 122-K-8363 NORMALLY OPEN LUCIFER SOLENOID VALVE 122-K-8363 NORMALLY OPEN
Nu-Way part no. E01003Y		 £192,71
16 Part number E01004Z, LUCIFER SOLENOID VALVE 121-K-63 N/C 1/4INCH 220V 50HZ LUCIFER SOLENOID VALVE 121-K-63 N/C 1/4INCH 220V 50HZ
Nu-Way part no. E01004Z		 £249,00
17   OBSOLETE
Nu-Way part no. E09100J
18 Part number E02030X, SUNTEC OIL PUMP T3C 10 7 SUNTEC OIL PUMP T3C 10 7
Nu-Way part no. E02030X		 £988,22
18 Part number E02069A, SUNTEC OIL PUMP SEAL T TYPE PUMP (NEW) NO:1914462 SUNTEC OIL PUMP SEAL T TYPE PUMP (NEW) NO:1914462
Nu-Way part no. E02069A		 £399,05
18 Part number E02077S, SUNTEC OIL PUMP SEAL T TYPE PUMP (OLD) NO:1914301 SUNTEC OIL PUMP SEAL T TYPE PUMP (OLD) NO:1914301
Nu-Way part no. E02077S		 £412,37
18   KSA630 PUMP 071F2003 **RSMS**
Nu-Way part no. E02115M		 £975,70
18   KSA1000 PUMP 071F200500 ^
Nu-Way part no. E02116N		 £750,86
18   SHAFT SEAL KSA400/630/1000 71F0035
Nu-Way part no. E02145T		 £116,90
19 Part number G03017X, NUWAY COUPLING RUBBER STAR XS 8738/8 NUWAY COUPLING RUBBER STAR XS 8738/8
Nu-Way part no. G03017X		 £4,19
19   PUMP COUPLING- 20MM BORE A2-1697
Nu-Way part no. Z06701E		 £168,62
19   PUMP COUPLING .946 BORE A2-1697
Nu-Way part no. Z06702F		 £53,18
19   PUMP COUPLING BODY KEYED A2-1494
Nu-Way part no. Z06716U		 £94,41
20 Part number A11002P, 1.5KW 240/380-420/3/50 2POLE FLGED D90S IE3 1.5KW 240/380-420/3/50 2POLE FLGED D90S IE3
Nu-Way part no. A11002P		 £574,20
20   BURNER MOTOR 1.5KW 240/415/3/50 460/3/60 1425 4P IE2
Nu-Way part no. A11003Q		 £352,38
21   ELECTRODYN TRANSFORMER 50 MA INTERMITTENT 240V (P76476)
Nu-Way part no. T97705U		 £198,30
21 Part number C04002H, NOW USE T97705U ELECTRODYN TRANSFORMER 50 MA INTERMITTENT 240V (P76476) NOW USE T97705U ELECTRODYN TRANSFORMER 50 MA INTERMITTENT 240V (P76476)
Nu-Way part no. C04002H
22 Part number C21106W, SIEMENS CONTROL BOX LAL1.25E OIL 220/240V SIEMENS CONTROL BOX LAL1.25E OIL 220/240V
Nu-Way part no. C21106W		 £307,25
23 Part number C31017R, SIEMENS PHOTO CELL QRB3(1) PHOTO-RESISTIVE CELL SIEMENS PHOTO CELL QRB3(1) PHOTO-RESISTIVE CELL
Nu-Way part no. C31017R		 £84,93
24 Part number C55062E, DANFOSS OVERLOAD 047H4209 (4109)4 - 6.2/6.9 - 10.7 AMP DANFOSS OVERLOAD 047H4209 (4109)4 - 6.2/6.9 - 10.7 AMP
Nu-Way part no. C55062E		 £51,99
24 Part number C55065H, DANFOSS OVERLOAD 047H4212 11-16 / 19-27 AMP DANFOSS OVERLOAD 047H4212 11-16 / 19-27 AMP
Nu-Way part no. C55065H		 £45,48
24 Part number C56044D, DANFOSS CONTACTOR CI9 037HOO2231 220/50 DANFOSS CONTACTOR CI9 037HOO2231 220/50
Nu-Way part no. C56044D		 £39,53
24 Part number C56047G, DANFOSS CONTACTOR CI12 37H403131 220/50 DANFOSS CONTACTOR CI12 37H403131 220/50
Nu-Way part no. C56047G		 £46,14
24 Part number C55060Q, DANFOSS OVERLOAD 047H4207 1.8 - 2.8 AMP (WAS 4107) DANFOSS OVERLOAD 047H4207 1.8 - 2.8 AMP (WAS 4107)
Nu-Way part no. C55060Q
24 Part number C56049J, DANFOSS CONTACTOR CI25 37H405131 220V 50HZ DANFOSS CONTACTOR CI25 37H405131 220V 50HZ
Nu-Way part no. C56049J
25   RELAY 60.128230-0040 8PIN 230 AC VOLT 50HZ
Nu-Way part no. C51028G		 £18,36
26 Part number C53027Z, DANFOSS TIMER 047H3111 SDT-240V50/60 DANFOSS TIMER 047H3111 SDT-240V50/60
Nu-Way part no. C53027Z		 £64,65
27   FUSE MD 20 AMP F320 REYROLLE
Nu-Way part no. B02013V		 £4,77
27 Part number B02049R, FUSE 5A (32X6.3mm) 414-055 CERAMIC FUSE 5A (32X6.3MM) 414-055 CERAMIC
Nu-Way part no. B02049R		 £1,83
27   FUSE F998 40AMP REYROLLE HRC CART
Nu-Way part no. B02121W		 £9,27
27   FUSE 60A CARTRIDGE F193 60AMP
Nu-Way part no. B02125S		 £9,27
28 Part number C50055N, DUNGS PRESSURE SWITCH GW 10 A6 (231112) DUNGS PRESSURE SWITCH GW 10 A6 (231112)
Nu-Way part no. C50055N		 £43,43
29 Part number A30018V, SIEMENS DAMPER MOTOR SQM10.16502 230V SIEMENS DAMPER MOTOR SQM10.16502 230V
Nu-Way part no. A30018V		 £969,05
30 Part number E11014B, HP SPILL VALVE 3/4 INCH B-GH-3/4" PRO - D2 (PAINT BLACK) HP SPILL VALVE 3/4 INCH B-GH-3/4" PRO - D2 (PAINT BLACK)
Nu-Way part no. E11014B		 £1 075,50
30 Part number G05041H, HP REPAIR KIT FOR SPILL VALVE 070H0059 HP REPAIR KIT FOR SPILL VALVE 070H0059
Nu-Way part no. G05041H		 £167,48
30   OBSOLETE O RING SEAL 24 X 30 FOR 3/4
Nu-Way part no. G05043B
31   ADJUSTING CAM SPRING STRIP A4-274
Nu-Way part no. P29007F		 £3,38
32 Part number G28025X, OPERATING CABLE TO A4-300 OPERATING CABLE TO A4-300
Nu-Way part no. G28025X		 £27,60
33 Part number E11001P, SUNTEC REGULATING VALVE TV40 011 SUNTEC REGULATING VALVE TV40 011
Nu-Way part no. E11001P		 £275,84
34   RWF32.000 C/W ARG 61.000
Nu-Way part no. C21171W		 £593,37
35   FLEXIBLE OIL LINE 0.5BORE X 78IN LONG 0.5BSP300.F
Nu-Way part no. E05020Y		 £88,52
35 Part number E05034J, FLEXIBLE OIL LINE .5BORE X 36IN .5BSP 340.F FLEXIBLE OIL LINE .5BORE X 36IN .5BSP 340.F
Nu-Way part no. E05034J		 £153,68
35 Part number E05035K, FLEXIBLE OIL LINE 0.75 BORE X 36IN 0.75BSP 340.F FLEXIBLE OIL LINE 0.75 BORE X 36IN 0.75BSP 340.F
Nu-Way part no. E05035K		 £65,48
35 Part number E05037M, FLEXIBLE OIL LINE .5BORE X 18IN .5BSP FLEXIBLE OIL LINE .5BORE X 18IN .5BSP
Nu-Way part no. E05037M		 £44,09
36 Part number E03010U, FILTER SELF CLEAN 1IN .024IN GA-V2100806 FILTER SELF CLEAN 1IN .024IN GA-V2100806
Nu-Way part no. E03010U		 £233,22
37 Part number G09031B, GASKET FLANGE E10802/3 NOVIS 21 GASKET FLANGE E10802/3 NOVIS 21
Nu-Way part no. G09031B		 £19,41
