SAUNIER DUVAL
XEON 100 - 120FF - (NO Diagram)
Appliance Code: 41-920-36

Appliance Diagram


Sorry, a diagram could not be found for this appliance.

1 Part number 800442, Gas section GAS SECTION
Saunier Duval part no. 800442		 £115.52
2 Part number 208040, NOW USE S208040 O RING-H/WELL 22.0 X 2.5 NOW USE S208040 O RING-H/WELL 22.0 X 2.5
Saunier Duval part no. 208040
2 Part number S208040, O ring O RING
Saunier Duval part no. S208040		 £6.23
3   INJECTOR
Saunier Duval part no. S205726		 £6.23
3   NOW USE S205726 INJECTOR-5.2MM
Saunier Duval part no. 205726
4 Part number 203434, PILOT BURNER-28T2A2E7218CIX PILOT BURNER-28T2A2E7218CIX
Saunier Duval part no. 203434
4 Part number S203434, Pilot burner PILOT BURNER
Saunier Duval part no. S203434
5   MICA SHIELD
Saunier Duval part no. 2000801236
6 Part number 2000800532, Fan assembly FAN ASSEMBLY
Saunier Duval part no. 2000800532		 £290.90
7 Part number 202629, NOW USE S202629 ELECTRODE - DERLITE NOW USE S202629 ELECTRODE - DERLITE
Saunier Duval part no. 202629
7 Part number S202629, Electrode DERLITE ELECTRODE DERLITE
Saunier Duval part no. S202629		 £9.05
8 Part number S800850, Control stat (2 pin) CONTROL STAT (2 PIN)
Saunier Duval part no. S800850		 £34.56
8 Part number 800850, NOW USE S800850 SPARES-CONTROL STAT NOW USE S800850 SPARES-CONTROL STAT
Saunier Duval part no. 800850
9 Part number S202201, NOW USE 0020248909 AIR PRESSURE SWITCH NOW USE 0020248909 AIR PRESSURE SWITCH
Saunier Duval part no. S202201
9 Part number 202201, NOW USE 0020248909 AIR PRESSURE SWITCH NOW USE 0020248909 AIR PRESSURE SWITCH
Saunier Duval part no. 202201
9 Part number 0020248909, AIR PRESSURE SWITCH AIR PRESSURE SWITCH
Saunier Duval part no. 0020248909		 £20.31
10 Part number 800275, Control knob + clip CONTROL KNOB + CLIP
Saunier Duval part no. 800275		 £24.78
11 Part number 2000800656, Water press switch + O ring WATER PRESS SWITCH + O RING
Saunier Duval part no. 2000800656		 £35.89
12   NOW USE S204212 O RING-5.1X1.6MM 0051-16-MN70
Saunier Duval part no. 204212
12   O RING -5.1X1.6MM
Saunier Duval part no. S204212		 £4.91
13 Part number 202015, OBSOLETE FUSE-1A 20MM 151490 OBSOLETE FUSE-1A 20MM 151490
Saunier Duval part no. 202015
13 Part number S202015, Fuse-1A 20mm FUSE-1A 20MM
Saunier Duval part no. S202015
14 Part number 900847, NOW USE S900847 P.C.B.ALTERNATIVES (INC TPO) NOW USE S900847 P.C.B.ALTERNATIVES (INC TPO)
Saunier Duval part no. 900847
14 Part number S900847, PCB (inc tpo 7 wire-2 fuse) PCB (INC TPO 7 WIRE-2 FUSE)
Saunier Duval part no. S900847		 £166.05
15 Part number 800272, O/Heat stat + heat O/HEAT STAT + HEAT
Saunier Duval part no. 800272		 £56.57
