VAILLANT
VCW 20/1 T3 WH - (Connection Parts)
Appliance Code: 47-044-03

Appliance Diagram


Connection Parts diagram for Vaillant VCW 20/1 T3 WHClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE GAS CONNECTION
Vaillant part no. 082501
1   OBSOLETE GAS CONNECTION
Vaillant part no. 082504
1   OBSOLETE GAS CONNECTION
Vaillant part no. 082505
2   OBSOLETE GAS CONNECTION
Vaillant part no. 080012
3   SCREW
Vaillant part no. 040038
4 Part number 235727, screw SCREW
Vaillant part no. 235727		 £5.13
8   OBSOLETE CONNECTION TUBE
Vaillant part no. 084704
10   OBSOLETE VENTURI
Vaillant part no. 010024
10   OBSOLETE VENTURI
Vaillant part no. 010034
10 Part number 010040, OBSOLETE venturi OBSOLETE VENTURI
Vaillant part no. 010040
11 Part number 981172, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981172		 £6.28
12 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £6.65
13   OBSOLETE FLOW SWITCH CONNECTION (SCREW FIT)
Vaillant part no. 084220
13   OBSOLETE FLOW SWITCH CONNECTION (PUSH FIT)
Vaillant part no. 084269
15 Part number 161106, Pump PUMP
Vaillant part no. 161106		 £184.19
15 Part number 161107, Pump PUMP
Vaillant part no. 161107		 £172.48
16A   OBSOLETE CONNECTION
Vaillant part no. 081024
17   OBSOLETE CONNECTION
Vaillant part no. 081011
18 Part number 150216, By-pass valve BY-PASS VALVE
Vaillant part no. 150216		 £20.64
22   OBSOLETE SCREW
Vaillant part no. 080556
25   OBSOLETE FLOW SWITCH CONDUCTION
Vaillant part no. 084219
26   OBSOLETE DOUBLE NUT
Vaillant part no. 080052
27 Part number 083742, OBSOLETE cold water tube OBSOLETE COLD WATER TUBE
Vaillant part no. 083742
29   OBSOLETE WARM WATER TUBE
Vaillant part no. 083918
30   OBSOLETE CONNECTION TUBE
Vaillant part no. 081336
31 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £6.63
32 Part number 981147, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981147		 £6.28
33 Part number 061804, heat exchanger HEAT EXCHANGER
Vaillant part no. 061804		 £117.27
34 Part number 141014, OBSOLETE flow switch OBSOLETE FLOW SWITCH
Vaillant part no. 141014
35 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £18.65
36 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £6.63
37 Part number 082741, gas shut-off valve VC221T H, 110T H VC 182 E H, VC 242 E H, VC 282 E H GAS SHUT-OFF VALVE VC221T H, 110T H VC 182 E H, VC 242 E H, VC 282 E H
Vaillant part no. 082741
37   OBSOLETE GAS SHUT-OFF VALVE
Vaillant part no. 082745
38   OBSOLETE TUBE
Vaillant part no. 137439
40 Part number 136313, OBSOLETE nipple OBSOLETE NIPPLE
Vaillant part no. 136313
41   OBSOLETE SUPPORT, CPL.
Vaillant part no. 086567
