VALOR GAS FIRE
TROPIC TREND LPG - (Appliance Overview)

Appliance Diagram


Appliance Overview diagram for Valor Gas Fire Tropic Trend LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE H/EXCHANGER & WINDOW
Valor Gas Fire part no. 0513419

2   OBSOLETE H/EXCHANGER FRONT COVER
Valor Gas Fire part no. 0513029

3   OBSOLETE TOP & BTM H/EXCHANGER GASKET
Valor Gas Fire part no. 0513039

4   GASKET-HT.EXCH. SIDES
Valor Gas Fire part no. 0513049
Temporarily unavailable
6   OBSOLETE FRAME INSPECTION WINDO
Valor Gas Fire part no. 0513069

7   OBSOLETE INNER WINDOW & GASKETS
Valor Gas Fire part no. 0513079

8   OBSOLETE SCREW M4X10
Valor Gas Fire part no. 0541089

9   OBSOLETE BURNER PACK
Valor Gas Fire part no. 0513389

10   OBSOLETE BURNER PLATE GASKET
Valor Gas Fire part no. 0513099

10   OBSOLETE SCREW
Valor Gas Fire part no. 0513349

11   WASHER
Valor Gas Fire part no. 0533589
Temporarily unavailable
12   OBSOLETE WASHER
Valor Gas Fire part no. 0516389

12   OBSOLETE M5 SPRING COIL WASHE
Valor Gas Fire part no. 0513109

13 Part number 0533249, OBSOLETE WING NUT OBSOLETE WING NUT
Valor Gas Fire part no. 0533249

13 Part number 636102, OBSOLETE NUT WING M5 SN OBSOLETE NUT WING M5 SN
Valor Gas Fire part no. 636102

14   OBSOLETE ELECT/DE
Valor Gas Fire part no. 0513119

15   OBSOLETE GASKET
Valor Gas Fire part no. 0513129

16   OBSOLETE THERMOCOUPLE ASSEMBLY
Valor Gas Fire part no. 0513139

17 Part number 0547759, OBSOLETE LOCKNUT OBSOLETE LOCKNUT
Valor Gas Fire part no. 0547759

18   OBSOLETE CAT 969 SIZE 100 INJ
Valor Gas Fire part no. 0513379

19   OBSOLETE INJECTOR CARRIER
Valor Gas Fire part no. 0513159

20   OBSOLETE LOCKNUT
Valor Gas Fire part no. 0528839

21   OBSOLETE TAP ASSEMBLY
Valor Gas Fire part no. 0513169

22   OBSOLETE INLET PIPE
Valor Gas Fire part no. 0513439

23   OBSOLETE INLET PIPE BRACKET
Valor Gas Fire part no. 0513449

24   TAPTITE M4X6MM POZI ZP SCREW
Valor Gas Fire part no. 0516349
Temporarily unavailable
25   OBSOLETE ADAPTER
Valor Gas Fire part no. 0534349

26 Part number 0504709, PIEZO GEN. PIEZO GEN.
Valor Gas Fire part no. 0504709
Temporarily unavailable
27   OBSOLETE ELECTRODE LEAD
Valor Gas Fire part no. 0513199

28   OBSOLETE INSPECTION WINDOW ASS
Valor Gas Fire part no. 0513459

30   OBSOLETE L/H SIDE BAFFLE
Valor Gas Fire part no. 0513229

33   SCREW
Valor Gas Fire part no. 0513369
Temporarily unavailable
34   OBSOLETE COOLER PLATE
Valor Gas Fire part no. 0513259

35   OBSOLETE CASE ASS
Valor Gas Fire part no. 0506909

36   OBSOLETE SPIRE FIX
Valor Gas Fire part no. 0511329

37   8X3/8 S/DR C/BSCREW
Valor Gas Fire part no. 0513479
Temporarily unavailable
38   OBSOLETE KNOB & CLIP ASSEMBLY
Valor Gas Fire part no. 0513279

39   OBSOLETE FLUE PIPE ASSEMBLY PACK
Valor Gas Fire part no. 0513289

40   OBSOLETE FLUE SEAL
Valor Gas Fire part no. 0513299

41   OBSOLETE 12X2 RD HD SLOT ZP WD/SCREW
Valor Gas Fire part no. 0549759

42   OBSOLETE FOR NO.12X2 SCREW RAWLPLUG
Valor Gas Fire part no. 0549769

43   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 0513399

44   OBSOLETE 121/2/3L INSTALL INST
Valor Gas Fire part no. 0521819

45   OBSOLETE TERMINAL GUARD
Valor Gas Fire part no. 0516539
