WORCESTER
26 CDI XTRA NG - (Electrical)
Appliance Code: 47-311-41

Appliance Diagram


Electrical diagram for Worcester 26 CDI Xtra NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 77161922060, CDI-FUSE PACK CDI-FUSE PACK
Worcester part no. 77161922060		 £6.04
Part number 87161212600, HARNESS EARTH CDI & I RANGE HARNESS EARTH CDI & I RANGE
Worcester part no. 87161212600		 £13.58
  PCB SUPPORT PILLAR TCBS-8-01
Worcester part no. 87161410760		 £2.65
Part number 87161560000, FUSE 2A SLOW BLOW 20 X 5mm FUSE 2A SLOW BLOW 20 X 5MM
Worcester part no. 87161560000		 £3.39
Part number 87161560010, FUSE 1.25A 20mm ANTI-SURGE FUSE 1.25A 20MM ANTI-SURGE
Worcester part no. 87161560010		 £2.98
Part number 87434061450, SEALING SCREW SEALING SCREW
Worcester part no. 87434061450		 £3.46
1 Part number 87483003130, P.C.B. HEATRONIC II P.C.B. HEATRONIC II
Worcester part no. 87483003130		 £201.40
2 Part number 87161423000, PRESSURE GAUGE 4 BAR DARK GREY PRESSURE GAUGE 4 BAR DARK GREY
Worcester part no. 87161423000		 £29.75
3 Part number 87161410120, FACIA MAIN BODY FACIA MAIN BODY
Worcester part no. 87161410120
4 Part number 87161411740, FACIA PANEL BOTTOM 26CDI XTRA FACIA PANEL BOTTOM 26CDI XTRA
Worcester part no. 87161411740		 £39.92
5 Part number 87161410080, FACIA INSET PLATE FACIA INSET PLATE
Worcester part no. 87161410080		 £33.92
6 Part number 87161410440, CONTROL KNOB CONTROL KNOB
Worcester part no. 87161410440		 £5.22
7 Part number 87161410210, SELECTOR KNOB SELECTOR KNOB
Worcester part no. 87161410210		 £4.98
8 Part number 87161410190, RESET BUTTON RESET BUTTON
Worcester part no. 87161410190		 £3.14
9 Part number 87161410110, FACIA LIGHT INSERT FACIA LIGHT INSERT
Worcester part no. 87161410110
10 Part number 87161408070, O-RING 1.60 X 7.10 ID EP O-RING 1.60 X 7.10 ID EP
Worcester part no. 87161408070		 £2.70
11 Part number 29124212100, SCREW ISO NO 6B X 9.5 RECESSED SCREW ISO NO 6B X 9.5 RECESSED
Worcester part no. 29124212100
12 Part number 87161202290, HARNESS IGNITION ASSEMBLY HARNESS IGNITION ASSEMBLY
Worcester part no. 87161202290
13 Part number 87472012480, TRANSFORMER - BV066-0188.0 TRANSFORMER - BV066-0188.0
Worcester part no. 87472012480		 £37.63
14 Part number 87161410070, FACIA HINGE PIN FACIA HINGE PIN
Worcester part no. 87161410070
15 Part number 87161410670, ELECTRICAL BOX COVER ELECTRICAL BOX COVER
Worcester part no. 87161410670
16   PANEL FASTENER
Worcester part no. 87161410450
17 Part number 87161411510, POTENTIOMETER ADJUSTER - BLACK POTENTIOMETER ADJUSTER - BLACK
Worcester part no. 87161411510		 £4.33
18 Part number 87161203460, FACIA PLATE ASSEMBLY FACIA PLATE ASSEMBLY
Worcester part no. 87161203460		 £22.99
19 Part number 87161200480, HARNESS - MAIN OF/RSF HARNESS - MAIN OF/RSF
Worcester part no. 87161200480
