ANDREWS
L32/143 (NEW MODELS) - (Controls)
Appliance Code: L32/143 NEW MODELS

Appliance Diagram


Controls diagram for Andrews L32/143 (New Models)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

12   CTRL BOX & WIRING ASSY 32/143
Andrews part no. Z129
£2,488.25
44   GAS CONTROL VALVE HARNESS
Andrews part no. Z248
£73.63
45   THERMOSTAT HARNESS
Andrews part no. Z249
£52.45
46   POWER SWITCH HARNESS
Andrews part no. Z251
£34.59
47   PRIMARY T'FORMER WIRE HARNESS
Andrews part no. Z252
£26.53
48   SECONDARY T'FORMER WIRE HARNES
Andrews part no. Z253
£34.41
49   DISPLAY COVER HARNESS
Andrews part no. Z254
£28.88
50   DISPLAY CONTROL HARNESS
Andrews part no. Z255
£30.68
51   WATER TIGHT BUSHING
Andrews part no. Z256
£15.13
52   MAIN POWER ON/OFF SWITCH
Andrews part no. Z143
£16.94
53   SNAP BUSH TOP
Andrews part no. Z257
£1.00
54   CONTROL PANEL
Andrews part no. Z258
£68.93
55   TERMINAL BLOCK
Andrews part no. Z259
£76.33
56   TERMINAL STRIP
Andrews part no. Z260
£15.38
57   TERMINAL
Andrews part no. Z261
£2.34
58   TRANSFORMER 230/24V AC
Andrews part no. E888
£83.05
59   CONTROL BOARD (T-STAT) 32/143
Andrews part no. Z138
£528.32
60   BOTTOM PLUG
Andrews part no. Z262
£1.00
61   SNAP BUSH BOTTOM
Andrews part no. Z263
£2.92
62   STRAIN RELIEF BUSHING
Andrews part no. Z264
£1.00
63   CONTROL BOX COVER
Andrews part no. Z265
£260.70
64   CONTROL DISPLAY AUTO
Andrews part no. Z140
£229.52
65   SCREWS 8-18 X 0.75
Andrews part no. Z266
£2.25
66   POTENTIOSTAT POWER ANODE
Andrews part no. E889
£292.30
67   POWER ANODE CONTROL HARNESS
Andrews part no. Z268
£42.81
68   ALARM MODULE
Andrews part no. Z116
£101.65
69   ALARM MODULE HARNESS
Andrews part no. Z270
£21.63
70   NOISE HARNESS
Andrews part no. Z271
£67.58
