ARISTON
500_ST6 - (EXPLODED VIEW)

Appliance Diagram



EXPLODED VIEW diagram for Ariston 500_ST6Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 926106, PLUG D:50 PLUG D:50
Ariston part no. 926106
£1.32
2 Part number 919010, OBSOLETE ANODE (D:17 L:600 M5) OBSOLETE ANODE (D:17 L:600 M5)
Ariston part no. 919010

3 Part number 926068, KNOB (REGULATION) KNOB (REGULATION)
Ariston part no. 926068
£3.47
4 Part number 926048, NOW USE 926159 PLASTIC COVER NOW USE 926159 PLASTIC COVER
Ariston part no. 926048

4 Part number 926159, PLASTIC COVER PLASTIC COVER
Ariston part no. 926159
£36.96
5 Part number 925197, THERMOSTAT BRACKET THERMOSTAT BRACKET
Ariston part no. 925197
£10.38
6 Part number 921001, THERMOSTAT 30A THERMOSTAT 30A
Ariston part no. 921001
£137.20
7 Part number 816518, HEATING ELEMENT 6000W 230V HEATING ELEMENT 6000W 230V
Ariston part no. 816518
£90.01
8 Part number 924002, FLANGE GASKET WITH 6 HOLES FLANGE GASKET WITH 6 HOLES
Ariston part no. 924002
£11.43
9 Part number 935044, WIRING (ELEMENT) WIRING (ELEMENT)
Ariston part no. 935044
£13.91
10 Part number 926168, FOOT (COMPLETE) FOOT (COMPLETE)
Ariston part no. 926168
£7.13
11 Part number 919014, OBSOLETE 3/4 CAP + ANODE OBSOLETE 3/4 CAP + ANODE
Ariston part no. 919014

301 Part number 1919027, OBSOLETE  I Magnesium anode 21.3x290 M8 OBSOLETE I MAGNESIUM ANODE 21.3X290 M8
Ariston part no. 1919027
