ARISTON
COMBI A 30 MFFI (28/06/2013) - (Burner TO 03/06)
Appliance Code: 47-116-45 2013

Appliance Diagram


Burner TO 03/06 diagram for Ariston Combi A 30 MFFI (28/06/2013)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

101 Part number 61313763, EXCHANGER 30KW (TO 03/06) EXCHANGER 30KW (TO 03/06)
Ariston part no. 61313763
£865.14
102 Part number 61313614, BURNER DOOR ASSY (TO 03/06) BURNER DOOR ASSY (TO 03/06)
Ariston part no. 61313614
£241.66
103 Part number 65103360, PANEL (INSULATION - FRONT) PANEL (INSULATION - FRONT)
Ariston part no. 65103360
£23.35
104   NOW USE 60000672-01 DOOR GASKET
Ariston part no. 60000672

104   DOOR GASKET
Ariston part no. 60000672-01
£26.95
110 Part number 61317432, IGNITION ELECTRODE IGNITION ELECTRODE
Ariston part no. 61317432
£29.74
111 Part number 61317433, IONISATION ELECTRODE IONISATION ELECTRODE
Ariston part no. 61317433
£29.83
112 Part number 61314753, GASKET D:85-66.5-2.5 (TO 08/11) GASKET D:85-66.5-2.5 (TO 08/11)
Ariston part no. 61314753
£8.11
113 Part number 65102070, CONDENSATE TRAP (LOWER) CONDENSATE TRAP (LOWER)
Ariston part no. 65102070
£8.81
114 Part number 65102548, CONDENSATE TRAP (UPPER) CONDENSATE TRAP (UPPER)
Ariston part no. 65102548
£7.03
117   DUCT FIRST SECTION (TO 03/06)
Ariston part no. 61315368
£127.56
118 Part number 65102575, CLIPS CLIPS
Ariston part no. 65102575
£5.45
121 Part number 990695, O-RING (3175 EPDM D=44.9) O-RING (3175 EPDM D=44.9)
Ariston part no. 990695
£3.38
122 Part number 61308782, SCREW D: 5-14 SCREW D: 5-14
Ariston part no. 61308782
£0.66
124 Part number 61311628, TUBE PVC D:21 L:500 TUBE PVC D:21 L:500
Ariston part no. 61311628
£35.15
125 Part number 65103361, PANEL (INSULATION - REAR) PANEL (INSULATION - REAR)
Ariston part no. 65103361
£18.68
127   SIDE COVER SUPPORT
Ariston part no. 61314826
£21.56
128   CONNECTION (TO 03/06)
Ariston part no. 61315409
£219.29
129 Part number 61316557, STRAP STRAP
Ariston part no. 61316557
£2.95
131 Part number 61000229, STRAP STRAP
Ariston part no. 61000229
£4.59
137 Part number 60000289-01, BURNER 30KW BURNER 30KW
Ariston part no. 60000289-01
£107.73
202   FLUE CONNECTION (TO 03/06)
Ariston part no. 61315286
£23.68
203 Part number 61310088, GASKET D:66-58.4-9 (TO 03/06) GASKET D:66-58.4-9 (TO 03/06)
Ariston part no. 61310088
£9.90
204 Part number 998636, GASKET (FLUE TEST POINT) (TO 03/06) GASKET (FLUE TEST POINT) (TO 03/06)
Ariston part no. 998636
£5.17
205 Part number 61306029, GASKET D:66.6 (TO 03/06) GASKET D:66.6 (TO 03/06)
Ariston part no. 61306029
£12.93
212 Part number 61300262, GASKET (TO 03/06) GASKET (TO 03/06)
Ariston part no. 61300262
£4.90
213 Part number 61306698, PLUG KIT (TO 03/06) PLUG KIT (TO 03/06)
Ariston part no. 61306698
£8.27
222 Part number 60000756, EXCHANGER SUPPORT EXCHANGER SUPPORT
Ariston part no. 60000756
£115.60
231 Part number 61306030, GASKET D:129.4 (TO 03/06) GASKET D:129.4 (TO 03/06)
Ariston part no. 61306030
£33.62
303   TOP PANEL BOX (TO 03/06)
Ariston part no. 61315153
£38.43
305   RIGHT CONTROL PANEL
Ariston part no. 61312643
£14.57
309   BASE - BOX
Ariston part no. 61315523
£20.87
314 Part number 61010109, GROMMET GROMMET
Ariston part no. 61010109
£3.87
316 Part number 991821, AIR RETURN COVER AIR RETURN COVER
Ariston part no. 991821
£3.20
317   CONTROL PANEL
Ariston part no. 61315324
£74.97
321 Part number 61313042, CASE CASE
Ariston part no. 61313042
£236.71
322   WALL HOOK
Ariston part no. 61312611
£3.22
325 Part number 61400236, FOAM SEAL 20x15 L: 1.7M FOAM SEAL 20X15 L: 1.7M
Ariston part no. 61400236
£38.64
326   FOAM SEAL 10X2 L: 800MM
Ariston part no. 61400237
£2.25
327 Part number 61311907, EXPANSION VESSEL 5L EXPANSION VESSEL 5L
Ariston part no. 61311907
£139.81
328   FOAM SEAL 15X10 L: 1M
Ariston part no. 61400393
£2.91
