ARISTON
GENUS 27 BFFI UK EDITION 3 - (Exploded View)
Appliance Code: 47-116-11D

Appliance Diagram


Exploded View diagram for Ariston Genus 27 BFFI UK Edition 3Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 230511, NOW USE 230514 PLUG NOW USE 230514 PLUG
Ariston part no. 230511
0 Part number 291095, 21X1045 M8 6 ELEMENT HOSE ANODE 21X1045 M8 6 ELEMENT HOSE ANODE
Ariston part no. 291095		 £52.99
0   ANODE PLUG
Ariston part no. 230514		 £11.71
1   OBSOLETE PIVOT (CASING PANEL)
Ariston part no. 570603
2   CASE PANELS SUPPORT ARC
Ariston part no. 997104		 £13.65
4   OBSOLETE CASE PANEL SUPPORT (L/H + R/H)
Ariston part no. 573106
5   CONTROL PANEL BRACKET HOLDER (L/H)
Ariston part no. 573117		 £37.94
6   OBSOLETE COVER PLATE (UNDERSIDE)
Ariston part no. 573185
7 Part number 573435, MAIN EXCHANGER MAIN EXCHANGER
Ariston part no. 573435		 £286.74
8 Part number 573520, GASKET 3/4" GASKET 3/4"
Ariston part no. 573520		 £0.94
9   OBSOLETE BURNER 15 RAMP (NATURAL GAS)
Ariston part no. 572625
9   OBSOLETE BURNER 15 RAMP (LPG)
Ariston part no. 572626
10   OBSOLETE BURNER SUPPORT
Ariston part no. 573124
11 Part number 569413, GASKET 37X26X2 GASKET 37X26X2
Ariston part no. 569413		 £1.49
12   LOCK NUT (BRASS) 3/4
Ariston part no. 569446		 £3.15
13   OBSOLETE PIPE (GAS VALVE/BURNER)
Ariston part no. 572738
14 Part number 569254, GASKET (GAS VALVE) GASKET (GAS VALVE)
Ariston part no. 569254		 £1.51
15 Part number 570732, NOW USE 573457 GAS VALVE (SIT TANDEM) NOW USE 573457 GAS VALVE (SIT TANDEM)
Ariston part no. 570732
15 Part number 573457, Gas valve (TANDEM) GAS VALVE (TANDEM)
Ariston part no. 573457		 £180.91
16   CLAMP
Ariston part no. 573022		 £1.43
17   GAS VALVE CABLE
Ariston part no. 999177		 £21.97
18   OBSOLETE PIPE (GAS INLET)
Ariston part no. 573057
19   LOCK NUT 3/4
Ariston part no. 573523		 £0.66
20   OBSOLETE PIPE (MOTORISED VALVE TO CYLINDER)
Ariston part no. 570581
21 Part number 573455, MOTORISED VALVE BODY MOTORISED VALVE BODY
Ariston part no. 573455		 £186.17
22   OBSOLETE PIPE (MOTORISED VALVE OUTLET)
Ariston part no. 573090
24 Part number 570605, NOW USE 995903 PUMP PRESSURE SWITCH NOW USE 995903 PUMP PRESSURE SWITCH
Ariston part no. 570605
24 Part number 995903, LOW PRESSURE SWITCH LOW PRESSURE SWITCH
Ariston part no. 995903		 £15.96
25 Part number 569390, GASKET 1/4 GASKET 1/4
Ariston part no. 569390		 £1.16
26   OBSOLETE PIPE (MOTORISED VALVE INLET)
Ariston part no. 570576
27   PIPE (CYLINDER DISCHARGE)
Ariston part no. 997100		 £21.85
28 Part number 573530, LOCK NUT 1/2 LOCK NUT 1/2
Ariston part no. 573530		 £1.49
29 Part number 997101, HOSE (EXPANSION RELIEF TO DISCHARGE) HOSE (EXPANSION RELIEF TO DISCHARGE)
Ariston part no. 997101		 £10.13
30 Part number 573139, EXPANSION RELIEF VALVE 6 BAR EXPANSION RELIEF VALVE 6 BAR
Ariston part no. 573139		 £17.60
31   GASKET (30X22X2)
Ariston part no. 569415		 £1.11
32 Part number 573528, GASKET 1/2" GASKET 1/2"
Ariston part no. 573528		 £1.13
33 Part number 573015, TEMPERATURE PROBE (D.H.W.) TEMPERATURE PROBE (D.H.W.)
Ariston part no. 573015		 £20.21
34   NOW USE 990483 SPRING (D.H.W. PROBE)
Ariston part no. 570542
34   SPRING (D.H.W. PROBE)
Ariston part no. 990483		 £3.93
35 Part number 573521, GASKET 3/8" GASKET 3/8"
Ariston part no. 573521		 £0.94
36   PIPE (EXPANSION VESSEL C.H.)
Ariston part no. 570587		 £13.60
38   CABLE (POWER SUPPLY)
Ariston part no. 998012		 £18.76
39   RESET BUTTON
Ariston part no. 571982		 £10.76
40 Part number 571983, SUMMER/WINTER SELECTOR KIT SUMMER/WINTER SELECTOR KIT
Ariston part no. 571983		 £7.44
41   INSPECTION COVER (L.H.)
Ariston part no. 571627		 £2.90
42 Part number 571984, CONTROL KNOB KIT CONTROL KNOB KIT
Ariston part no. 571984		 £6.49
43   OBSOLETE SURROUND (PRESSURE GAUGE)
Ariston part no. 572384
44   INSPECTION COVER (R.H.)
Ariston part no. 571623		 £3.20
45 Part number 571985, ON/OFF PUSH BUTTON KIT ON/OFF PUSH BUTTON KIT
Ariston part no. 571985
45 Part number 573303, ON/OFF PUSH BUTTON KIT ON/OFF PUSH BUTTON KIT
Ariston part no. 573303		 £6.72
46   POWER INDICATOR L.E.D. LENS
Ariston part no. 571550		 £6.79
47   OBSOLETE FLUE L.E.D. COVER (GREEN)
Ariston part no. 572658
48   CONTROL PANEL (FRONT)
Ariston part no. 995402		 £11.26
49 Part number 569538, TIME CLOCK (DIGITAL) TIME CLOCK (DIGITAL)
Ariston part no. 569538		 £72.66
50   OBSOLETE CABLE (TIME CLOCK)
Ariston part no. 573101
51 Part number 569711, NYLON BUSH (10MM) NYLON BUSH (10MM)
Ariston part no. 569711		 £3.21
52 Part number 952930, PRINTED CIRCUIT BOARD (EA FFI) PRINTED CIRCUIT BOARD (EA FFI)
Ariston part no. 952930		 £138.82
54 Part number 571562, CABLE CLAMP CABLE CLAMP
Ariston part no. 571562		 £2.67
55 Part number 571558, CONTROL PANEL ROTOR CONTROL PANEL ROTOR
Ariston part no. 571558		 £0.79
56   CABLE HOLDER
Ariston part no. 569458		 £6.09
58   CABLE HOLDER COVER (R.H.)
Ariston part no. 571967		 £5.12
59 Part number 998181, NOW USE 998723 LOW VOLTAGE WIRING NOW USE 998723 LOW VOLTAGE WIRING
Ariston part no. 998181
59 Part number 998723, LOW VOLTAGE WIRING LOW VOLTAGE WIRING
Ariston part no. 998723		 £31.66
60   OBSOLETE CABLE (MOTORISED VALVE/PUMP/GAS VALVE)
Ariston part no. 573195
61 Part number 569434, COLLAR (VENTURI) COLLAR (VENTURI)
Ariston part no. 569434		 £6.01
62 Part number 572382, VENTURI VENTURI
Ariston part no. 572382		 £54.16
63   SILICONE PIPE (NEGATIVE SIGNAL)
Ariston part no. 571819		 £7.83
64 Part number 571652, NOW USE 571652-01 AIR PRESSURE SWITCH NOW USE 571652-01 AIR PRESSURE SWITCH
Ariston part no. 571652
64 Part number 571652-01, AIR PRESSURE SWITCH 140 Pa AIR PRESSURE SWITCH 140 PA
Ariston part no. 571652-01		 £45.54
65 Part number 571575, NOW USE 573576 SILICONE PIPE (POSITIVE SIGNAL) NOW USE 573576 SILICONE PIPE (POSITIVE SIGNAL)
Ariston part no. 571575
66 Part number 573329, AIR INTAKE COVER AIR INTAKE COVER
Ariston part no. 573329		 £6.22
67 Part number 997203, SUPPORT PLATE SUPPORT PLATE
Ariston part no. 997203		 £6.35
68   CABLE (FAN/AIR PRESSURE SWITCH)
Ariston part no. 573193		 £31.80
69 Part number 573114, PANEL (FRONT - SEALED CHAMBER) PANEL (FRONT - SEALED CHAMBER)
Ariston part no. 573114		 £70.46
70   CABLE CLAMP
Ariston part no. 570561		 £2.81
71   OBSOLETE COVER (SEALED CHAMBER)
Ariston part no. 573103
72   FLUE (COAXIAL TURRET)
Ariston part no. 571166		 £19.73
73 Part number 573447, GASKET NEOPRENE D:126-95 (4 trous D:5) GASKET NEOPRENE D:126-95 (4 TROUS D:5)
Ariston part no. 573447		 £9.74
74   OBSOLETE PANEL (SEALED CHAMBER - REAR)
Ariston part no. 572856
76   OBSOLETE SPARK GENERATOR SUPPORT BRACKET
Ariston part no. 573493
77 Part number 573023, SPARK GENERATOR SPARK GENERATOR
Ariston part no. 573023		 £15.96
78 Part number 570772, CABLE HOLDER CABLE HOLDER
Ariston part no. 570772		 £1.16
79 Part number 569561, ELECTRODE (IGNITION L.H.) ELECTRODE (IGNITION L.H.)
Ariston part no. 569561		 £7.34
80   OBSOLETE CONTROL PANEL BRACKET HOLDER (R/H)
Ariston part no. 573118
81   CABLE (IGNITION ELECTRODE)
Ariston part no. 573440		 £2.92
82 Part number 569560, ELECTRODE (IGNITION R.H.) ELECTRODE (IGNITION R.H.)
Ariston part no. 569560		 £5.87
83 Part number 573441, ELECTRODE (DETECTION) ELECTRODE (DETECTION)
Ariston part no. 573441		 £8.78
84   PANEL (INSULATION - SIDE)
Ariston part no. 998136		 £10.04
85   PANEL (INSULATION - REAR)
Ariston part no. 998148		 £10.06
86 Part number 573566, SIGHT GLASS HOLDER SIGHT GLASS HOLDER
Ariston part no. 573566		 £7.26
87 Part number 573567, SIGHT GLASS SIGHT GLASS
Ariston part no. 573567		 £7.39
88 Part number 569442, SIGHT GLASS - GASKET SIGHT GLASS - GASKET
Ariston part no. 569442		 £1.53
89   FAN SEAL (SILICONE)
Ariston part no. 573446
90 Part number 573434, FAN FAN
Ariston part no. 573434		 £134.52
91   SUPPORT PLATE (FAN)
Ariston part no. 573049		 £23.83
92   OBSOLETE FLUE HOOD
Ariston part no. 570516
93   PANEL (INSULATION - FRONT)
Ariston part no. 998133		 £11.09
94   OBSOLETE COMBUSTION CHAMBER
Ariston part no. 570515
95 Part number 571657, CABLE (DETECTION ELECTRODE/P.C.B.) CABLE (DETECTION ELECTRODE/P.C.B.)
Ariston part no. 571657		 £19.90
96   OBSOLETE PANEL (COMBUSTION CHAMBER FRONT)
Ariston part no. 570553
97   NOW USE 572972 AIR DIFFUSER
Ariston part no. 573113
97   AIR DIFFUSER
Ariston part no. 572972		 £7.07
98   OBSOLETE CABLE HOLDER COVER (L.H.)
Ariston part no. 571968
99   OBSOLETE TERMINAL BOARD (THREE POLE)
Ariston part no. 573091
100 Part number 569720, BLIND GROMMET BLIND GROMMET
Ariston part no. 569720		 £2.44
101   CYLINDER 60 L
Ariston part no. 999607		 £1,039.18
102 Part number 573456, NOW USE 65101718 EXPANSION VESSEL (C.H.) NOW USE 65101718 EXPANSION VESSEL (C.H.)
Ariston part no. 573456
102 Part number 65101718, 8 L. STANDARDISED EXPANSION VESSEL 8 L. STANDARDISED EXPANSION VESSEL
Ariston part no. 65101718		 £80.59
103 Part number 953083, P.C.B. (EB C-MI/FFI) P.C.B. (EB C-MI/FFI)
Ariston part no. 953083		 £198.03
103 Part number 953082, NOW USE 953083 PRINTED CIRCUIT BOARD (EB C MI/FFI) NOW USE 953083 PRINTED CIRCUIT BOARD (EB C MI/FFI)
Ariston part no. 953082
104 Part number 952610, CABLE (P.C.B.) CABLE (P.C.B.)
Ariston part no. 952610		 £11.69
105   CABLE (AIR PRESSURE SWITCH/P.C.B.)
Ariston part no. 572998		 £5.21
106   TEMPERATURE L.E.D. LENS BANK
Ariston part no. 571551		 £3.44
107 Part number 571649, PRESSURE GAUGE PRESSURE GAUGE
Ariston part no. 571649		 £16.59
108   CABLE (FAN/P.C.B.)
Ariston part no. 573192		 £9.14
109 Part number 570571, 1/2 BRASS CAP 1/2 BRASS CAP
Ariston part no. 570571		 £10.04
110 Part number 573531, NIPPLE (1/2 BRASS) NIPPLE (1/2 BRASS)
Ariston part no. 573531		 £12.92
111   PIPE (SECONDARY RETURN)
Ariston part no. 573187		 £13.37
112   GASKET 1/2 NOW IN PACK OF 25
Ariston part no. 999408		 £10.53
113 Part number 573496, PIPE (COLD WATER INLET) PIPE (COLD WATER INLET)
Ariston part no. 573496		 £15.14
114 Part number 997099, PIPE (D.H.W. EXPANSION VESSEL) PIPE (D.H.W. EXPANSION VESSEL)
Ariston part no. 997099		 £14.96
115 Part number 573115, PIPE (D.H.W. OUTLET) PIPE (D.H.W. OUTLET)
Ariston part no. 573115		 £12.56
116 Part number 573140, NOW USE 969046 TEMPERATURE/PRESSURE RELIEF VALVE(7 BAR) NOW USE 969046 TEMPERATURE/PRESSURE RELIEF VALVE(7 BAR)
Ariston part no. 573140
116 Part number 969046, TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08) TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08)
Ariston part no. 969046		 £76.84
117   OBSOLETE PIPE (MAIN FLOW SWITCH - POSITIVE)
Ariston part no. 572718
118 Part number 998122, EXPANSION VESSEL 4L EXPANSION VESSEL 4L
Ariston part no. 998122		 £171.34
119 Part number 570959, NOW USE 999419 SUPPORT BRACKET USE CODE 999419 NOW USE 999419 SUPPORT BRACKET USE CODE 999419
Ariston part no. 570959
119 Part number 999419, SUPPORT BRACKET (D.H.W. VESSEL) SUPPORT BRACKET (D.H.W. VESSEL)
Ariston part no. 999419		 £5.94
120   TEMPERATURE PROBE
Ariston part no. 998458-01		 £7.34
120 Part number 998458, NOW USE 998458-01 TEMPERATURE PROBE NOW USE 998458-01 TEMPERATURE PROBE
Ariston part no. 998458
121 Part number 571648, THERMOSTAT (OVERHEAT) THERMOSTAT (OVERHEAT)
Ariston part no. 571648		 £8.86
122   OBSOLETE PIPE (C.H. FLOW)
Ariston part no. 572717
123   PIPE (RETURN - MAIN EXCHANGER)
Ariston part no. 570584		 £22.45
124 Part number 570585, PIPE (FLOW - MAIN EXCHANGER) PIPE (FLOW - MAIN EXCHANGER)
Ariston part no. 570585		 £26.42
125 Part number 564254, NOW USE 571639 AUTO AIR VENT NOW USE 571639 AUTO AIR VENT
Ariston part no. 564254
125 Part number 571639, AUTOMATIC AIR RELEASE VALVE AUTOMATIC AIR RELEASE VALVE
Ariston part no. 571639		 £11.91
126 Part number 998564, AIR VALVE FITTING AIR VALVE FITTING
Ariston part no. 998564		 £2.65
127   PIPE (PUMP TO MAIN HEAT EXCHANGER)
Ariston part no. 572716		 £19.41
128 Part number 570248, BURNER JET (NG 1.25) BURNER JET (NG 1.25)
Ariston part no. 570248		 £1.55
128 Part number 570251, BURNER JET (L.P.G. 0.72) BURNER JET (L.P.G. 0.72)
Ariston part no. 570251		 £4.47
129 Part number 572138, BURNER JET WASHER BURNER JET WASHER
Ariston part no. 572138		 £0.87
130 Part number 569387, GASKET 1 GASKET 1
Ariston part no. 569387		 £3.18
131 Part number 573123, NOW USE 996613 OVERSIZE CIRCULATOR WITH DEAERATOR NOW USE 996613 OVERSIZE CIRCULATOR WITH DEAERATOR
Ariston part no. 573123
131 Part number 996613, KIT FOR VERT. 1 PUMP ATTACHMENTS+JOLLY KIT FOR VERT. 1 PUMP ATTACHMENTS+JOLLY
Ariston part no. 996613		 £273.54
132   OBSOLETE PIPE (MAIN FLOW SWITCH - NEGATIVE)
Ariston part no. 572719
133   HYDRAULIC GROUP
Ariston part no. 572715		 £75.71
134 Part number 573576, COMPENSATION TUBE COMPENSATION TUBE
Ariston part no. 573576		 £7.22
135 Part number 573727, DRAIN VALVE DRAIN VALVE
Ariston part no. 573727		 £7.39
136   COVER (MOTORISED VALVE)
Ariston part no. 572858		 £7.26
137   DRAINAGE PIPE
Ariston part no. 573190		 £11.49
138 Part number 569292, SAFETY VALVE (3 BAR). SAFETY VALVE (3 BAR).
Ariston part no. 569292		 £16.20
139 Part number 65100519, MAIN FLOW SWITCH KIT MAIN FLOW SWITCH KIT
Ariston part no. 65100519		 £47.05
139 Part number 998099, NOW USE 65100519 MAIN CIRCUIT FLOW SWITCH NOW USE 65100519 MAIN CIRCUIT FLOW SWITCH
Ariston part no. 998099
140 Part number 571547, DIAPHRAGM (MAIN FLOW SWITCH) DIAPHRAGM (MAIN FLOW SWITCH)
Ariston part no. 571547		 £6.52
141   BY-BASS BODY
Ariston part no. 572728		 £58.33
301   OBSOLETE CASE PANEL (L.H. SIDE)
Ariston part no. 573141
302   OBSOLETE PANEL (FRONT CASE)
Ariston part no. 570599
303   CASE PANEL (R.H. SIDE)
Ariston part no. 573142		 £16.25
304   OBSOLETE CASE DOOR (CONTROL PANEL)
Ariston part no. 570557
305   OBSOLETE LOCK NUT (M6)
Ariston part no. 573149
306   OBSOLETE BUSH
Ariston part no. 573068
307   OBSOLETE BOLT (M6 X 16)
Ariston part no. 573147
331 Part number 570711, MOTOR (3-WAY VALVE) MOTOR (3-WAY VALVE)
Ariston part no. 570711		 £121.61
361 Part number 569281, BURNER JET FULL KIT (NG) BURNER JET FULL KIT (NG)
Ariston part no. 569281		 £23.27
362 Part number 569282, BURNER JET FULL KIT (LPG) BURNER JET FULL KIT (LPG)
Ariston part no. 569282		 £28.87


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
