ARISTON
GENUS 30 MFFI UK EDITION2 - (Exploded View)
Appliance Code: 47-116-20

Appliance Diagram


Exploded View diagram for Ariston Genus 30 MFFI UK EDITION2Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 573294, EXPANSION VESSEL EXPANSION VESSEL
Ariston part no. 573294		 £63.13
2   NOW USE 999679 EXPANSION VESSEL INSERT
Ariston part no. 573310
2   EXPANSION VESSEL INSERT
Ariston part no. 999679		 £2.58
3 Part number 573244, LOCK NUT 3/8" LOCK NUT 3/8"
Ariston part no. 573244		 £6.00
4 Part number 574302, CASING SUPPORT BRACKET (PLASTIC) (QTY 4) CASING SUPPORT BRACKET (PLASTIC) (QTY 4)
Ariston part no. 574302		 £7.39
5   CASING SUPPORT BRACKET
Ariston part no. 572984		 £1.76
7 Part number 570772, CABLE HOLDER CABLE HOLDER
Ariston part no. 570772		 £1.16
9 Part number 998042, SUPPORT BRACKET (L/H) SUPPORT BRACKET (L/H)
Ariston part no. 998042		 £2.53
10 Part number 998041, SUPPORT BRACKET (R/H) SUPPORT BRACKET (R/H)
Ariston part no. 998041		 £2.53
11 Part number 573520, GASKET 3/4" GASKET 3/4"
Ariston part no. 573520		 £0.94
12   PIPE (MAIN EXCHANGER - 3 WAY GROUP)
Ariston part no. 997200		 £17.22
13   FIXING SPRING
Ariston part no. 998043		 £6.07
14 Part number 997224, MOUNTING BRACKET (OVERHEAT THERMOSTAT) MOUNTING BRACKET (OVERHEAT THERMOSTAT)
Ariston part no. 997224		 £6.58
15 Part number 996065, OVERHEAT THERMOSTAT OVERHEAT THERMOSTAT
Ariston part no. 996065		 £11.03
15 Part number 997206, NOW USE 996065 THERMOSTAT (OVERHEAT) NOW USE 996065 THERMOSTAT (OVERHEAT)
Ariston part no. 997206
16 Part number 573809, PIPE CLIP PIPE CLIP
Ariston part no. 573809		 £4.92
17 Part number 998069, 3-WAY VALVE 3-WAY VALVE
Ariston part no. 998069		 £227.41
18 Part number 571547, DIAPHRAGM (MAIN FLOW SWITCH) DIAPHRAGM (MAIN FLOW SWITCH)
Ariston part no. 571547		 £6.52
19 Part number 998099, NOW USE 65100519 MAIN CIRCUIT FLOW SWITCH NOW USE 65100519 MAIN CIRCUIT FLOW SWITCH
Ariston part no. 998099
19 Part number 65100519, MAIN FLOW SWITCH KIT MAIN FLOW SWITCH KIT
Ariston part no. 65100519		 £47.05
20   TEMPERATURE PROBE
Ariston part no. 998458-01		 £7.34
20 Part number 569236, NOW USE 998458-01 TEMPERATURE PROBE NOW USE 998458-01 TEMPERATURE PROBE
Ariston part no. 569236
20 Part number 998458, NOW USE 998458-01 TEMPERATURE PROBE NOW USE 998458-01 TEMPERATURE PROBE
Ariston part no. 998458
21 Part number 573824, BRACKET (M/FLOW MICROSWITCH) BRACKET (M/FLOW MICROSWITCH)
Ariston part no. 573824		 £1.32
22 Part number 998060, MICROSWITCH (C.H./D.H.W.) MICROSWITCH (C.H./D.H.W.)
Ariston part no. 998060		 £27.49
23 Part number 571838, PIPE FIXING CLIP PIPE FIXING CLIP
Ariston part no. 571838		 £0.95
24 Part number 998072, RETURN GROUP RETURN GROUP
Ariston part no. 998072		 £189.80
25 Part number 573528, GASKET 1/2" GASKET 1/2"
Ariston part no. 573528		 £1.13
26 Part number 573727, DRAIN VALVE DRAIN VALVE
Ariston part no. 573727		 £7.39
27 Part number 573172, PRESSURE RELIEF VALVE (1/2" 3 BAR) PRESSURE RELIEF VALVE (1/2" 3 BAR)
Ariston part no. 573172		 £18.28
28   PIPE (EXPANSION VESSEL)
Ariston part no. 573311		 £12.55
29 Part number 571965, O-RING O-RING
Ariston part no. 571965		 £0.80
30   PIPE (GAS INLET)
Ariston part no. 997202		 £5.98
31   CABLE (POWER SUPPLY)
Ariston part no. 998012		 £18.76
32 Part number 571649, PRESSURE GAUGE PRESSURE GAUGE
Ariston part no. 571649		 £16.59
33 Part number 573300, RESET BUTTON RESET BUTTON
Ariston part no. 573300		 £6.59
34 Part number 997180, CABLE (TIME CLOCK) CABLE (TIME CLOCK)
Ariston part no. 997180		 £8.52
35 Part number 997208, NOW USE 997207 TIME CLOCK NOW USE 997207 TIME CLOCK
Ariston part no. 997208
35 Part number 997207, TIME CLOCK TIME CLOCK
Ariston part no. 997207		 £100.90
36   COVER (WITH TIME CLOCK INSERT)
Ariston part no. 997205		 £4.01
37   COVER (TIME CLOCK)
Ariston part no. 997142		 £2.91
38 Part number 573302, SUMMER/WINTER SELECTOR KIT SUMMER/WINTER SELECTOR KIT
Ariston part no. 573302		 £6.54
39   COVER (PRESSURE GAUGE)
Ariston part no. 572948		 £2.90
40 Part number 573301, CONTROL KNOB KIT CONTROL KNOB KIT
Ariston part no. 573301		 £6.66
41   INSPECTION COVER (R.H.)
Ariston part no. 571628		 £6.73
42 Part number 573303, ON/OFF PUSH BUTTON KIT ON/OFF PUSH BUTTON KIT
Ariston part no. 573303		 £6.72
43   POWER INDICATOR L.E.D. LENS
Ariston part no. 571550		 £6.79
44   FLUE L.E.D. COVER (WHITE)
Ariston part no. 572659		 £5.75
45   OBSOLETE CONTROL PANEL COVER
Ariston part no. 998790
46   TEMPERATURE L.E.D. LENS BANK
Ariston part no. 571551		 £3.44
47 Part number 953045, PRINTED CIRCUIT BOARD (E C-MI/FFI) PRINTED CIRCUIT BOARD (E C-MI/FFI)
Ariston part no. 953045		 £295.15
48 Part number 569711, NYLON BUSH (10MM) NYLON BUSH (10MM)
Ariston part no. 569711		 £3.21
49 Part number 952981, P.C.B. (EI A-FFI) (RH) P.C.B. (EI A-FFI) (RH)
Ariston part no. 952981		 £156.40
50 Part number 952610, CABLE (P.C.B.) CABLE (P.C.B.)
Ariston part no. 952610		 £11.69
52 Part number 571562, CABLE CLAMP CABLE CLAMP
Ariston part no. 571562		 £2.67
53   CABLE HOLDER
Ariston part no. 569458		 £6.09
54 Part number 573534, CABLE HOLDER CABLE HOLDER
Ariston part no. 573534		 £1.17
56   CABLE HOLDER COVER (R.H.)
Ariston part no. 569713		 £7.13
57 Part number 574272, HIGH VOLTAGE WIRING HIGH VOLTAGE WIRING
Ariston part no. 574272		 £26.25
58   LOW VOLTAGE WIRING
Ariston part no. 998048		 £21.97
59 Part number 572990, FAN FAN
Ariston part no. 572990		 £164.56
60 Part number 573343, GASKET (FAN) GASKET (FAN)
Ariston part no. 573343		 £6.80
61 Part number 573326, FLUE INTAKE PLUG FLUE INTAKE PLUG
Ariston part no. 573326		 £2.53
62 Part number 998113, RESTRICTOR (D= 45) RESTRICTOR (D= 45)
Ariston part no. 998113		 £2.59
63 Part number 573333, FLUE (EXHAUST MANIFOLD / HEADER) FLUE (EXHAUST MANIFOLD / HEADER)
Ariston part no. 573333		 £166.54
64   PANEL (COMBUSTION CHAMBER - SIDE)
Ariston part no. 573247		 £15.50
65 Part number 570717, SPRING (FASTENING) SPRING (FASTENING)
Ariston part no. 570717		 £4.21
67   COVER PLATE
Ariston part no. 573330		 £6.54
68 Part number 573865, NOW USE 65101484 FLUE GASKET NOW USE 65101484 FLUE GASKET
Ariston part no. 573865
68 Part number 65101484, FLUE GASKET FLUE GASKET
Ariston part no. 65101484		 £10.68
69 Part number 573337, GASKET (FLUE MANIFOLD) GASKET (FLUE MANIFOLD)
Ariston part no. 573337		 £4.82
70 Part number 573329, AIR INTAKE COVER AIR INTAKE COVER
Ariston part no. 573329		 £6.22
71 Part number 997203, SUPPORT PLATE SUPPORT PLATE
Ariston part no. 997203		 £6.35
72   CABLE CLAMP
Ariston part no. 998108		 £1.43
73 Part number 571575, NOW USE 573576 SILICONE PIPE (POSITIVE SIGNAL) NOW USE 573576 SILICONE PIPE (POSITIVE SIGNAL)
Ariston part no. 571575
74 Part number 571651, NOW USE 571651-01 AIR PRESSURE SWITCH NOW USE 571651-01 AIR PRESSURE SWITCH
Ariston part no. 571651
74 Part number 571651-01, AIR PRESSURE SWITCH 75 Pa AIR PRESSURE SWITCH 75 PA
Ariston part no. 571651-01		 £42.29
75 Part number 569662, SILICONE PIPE SILICONE PIPE
Ariston part no. 569662		 £6.34
76 Part number 573327, Y PIECE (AIR PRESSURE) Y PIECE (AIR PRESSURE)
Ariston part no. 573327		 £6.24
77 Part number 573344, PANEL (COMBUSTION CHAMBER - FRONT) PANEL (COMBUSTION CHAMBER - FRONT)
Ariston part no. 573344		 £43.25
78 Part number 998075, NOW USE 65105371 SIGHT GLASS NOW USE 65105371 SIGHT GLASS
Ariston part no. 998075
78 Part number 65105371, SIGHT GLASS - GASKET SIGHT GLASS - GASKET
Ariston part no. 65105371		 £6.02
79 Part number 65105371, SIGHT GLASS - GASKET SIGHT GLASS - GASKET
Ariston part no. 65105371		 £6.02
79 Part number 998076, NOW USE 65105371 GASKET (SIGHT GLASS) NOW USE 65105371 GASKET (SIGHT GLASS)
Ariston part no. 998076
80 Part number 998130, INSULATION PANEL - REAR INSULATION PANEL - REAR
Ariston part no. 998130		 £10.14
81   PANEL - L/H COMBUSTION CHAMBER
Ariston part no. 573243		 £4.42
82 Part number 998128, INSULATION PANEL - SIDE INSULATION PANEL - SIDE
Ariston part no. 998128		 £8.50
83 Part number 572906, PIPE (MAIN EXCHANGER - PUMP) PIPE (MAIN EXCHANGER - PUMP)
Ariston part no. 572906		 £20.43
84 Part number 564254, NOW USE 571639 AUTO AIR VENT NOW USE 571639 AUTO AIR VENT
Ariston part no. 564254
84 Part number 571639, AUTOMATIC AIR RELEASE VALVE AUTOMATIC AIR RELEASE VALVE
Ariston part no. 571639		 £11.91
85 Part number 569387, GASKET 1 GASKET 1
Ariston part no. 569387		 £3.18
86 Part number 573521, GASKET 3/8" GASKET 3/8"
Ariston part no. 573521		 £0.94
87 Part number 998064, SPRING (BY-PASS PIPE) SPRING (BY-PASS PIPE)
Ariston part no. 998064		 £3.20
88 Part number 998077, O-RING O-RING
Ariston part no. 998077		 £1.53
89 Part number 998065, BY-PASS PIPE BY-PASS PIPE
Ariston part no. 998065		 £8.47
90 Part number 998483, DHW HEAT EXCHANGER DHW HEAT EXCHANGER
Ariston part no. 998483		 £82.30
91 Part number 573825, O-RING 4075 3,53 X 18,64 O-RING 4075 3,53 X 18,64
Ariston part no. 573825		 £2.97
92 Part number 573086, PIPE (MAIN FLOW SWITCH-POSITIVE SIGNAL) PIPE (MAIN FLOW SWITCH-POSITIVE SIGNAL)
Ariston part no. 573086		 £15.47
93 Part number 571807, O-RING (20-18) O-RING (20-18)
Ariston part no. 571807		 £1.09
94 Part number 573087, PIPE (MAIN FLOW SWITCH - NEGATIVE SIGNAL PIPE (MAIN FLOW SWITCH - NEGATIVE SIGNAL
Ariston part no. 573087		 £10.49
95   OBSOLETE PIPE (SAFETY VALVE)
Ariston part no. 998019
96   OBSOLETE HIGH VOLTAGE CABLE (GAS VALVE)
Ariston part no. 998035
96   OBSOLETE HIGH VOLTAGE CABLE (GAS VALVE)
Ariston part no. 996133
97   CLAMP
Ariston part no. 573022		 £1.43
98 Part number 573023, SPARK GENERATOR SPARK GENERATOR
Ariston part no. 573023		 £15.96
99 Part number 996613, KIT FOR VERT. 1 PUMP ATTACHMENTS+JOLLY KIT FOR VERT. 1 PUMP ATTACHMENTS+JOLLY
Ariston part no. 996613		 £273.54
99 Part number 997151, NOW USE 996613 PUMP (GOLD 60-V-CLF-H3) NOW USE 996613 PUMP (GOLD 60-V-CLF-H3)
Ariston part no. 997151
100   SPARK GENERATOR SUPPORT
Ariston part no. 573285		 £5.08
101 Part number 570732, NOW USE 573457 GAS VALVE (SIT TANDEM) NOW USE 573457 GAS VALVE (SIT TANDEM)
Ariston part no. 570732
101 Part number 573457, Gas valve (TANDEM) GAS VALVE (TANDEM)
Ariston part no. 573457		 £180.91
102   PIPE (GAS VALVE/BURNER)
Ariston part no. 573289		 £7.63
103 Part number 569443, SILICONE SEAL SILICONE SEAL
Ariston part no. 569443		 £6.30
104 Part number 572138, BURNER JET WASHER BURNER JET WASHER
Ariston part no. 572138		 £0.87
105 Part number 998434, BURNER JET (L.P.G. 0.77) BURNER JET (L.P.G. 0.77)
Ariston part no. 998434		 £1.49
105 Part number 998433, BURNER JET (NG 1.30) BURNER JET (NG 1.30)
Ariston part no. 998433		 £1.60
106 Part number 573325, RIVET RIVET
Ariston part no. 573325		 £0.98
107 Part number 571662, CABLE (IGNITION ELECTRODE) CABLE (IGNITION ELECTRODE)
Ariston part no. 571662		 £6.28
108 Part number 573576, COMPENSATION TUBE COMPENSATION TUBE
Ariston part no. 573576		 £7.22
109 Part number 571657, CABLE (DETECTION ELECTRODE/P.C.B.) CABLE (DETECTION ELECTRODE/P.C.B.)
Ariston part no. 571657		 £19.90
110 Part number 571787, CONNECTOR BLOCK CONNECTOR BLOCK
Ariston part no. 571787		 £1.45
111 Part number 569720, BLIND GROMMET BLIND GROMMET
Ariston part no. 569720		 £2.44
112   CABLE HOLDER COVER (L.H.)
Ariston part no. 569714		 £2.61
113 Part number 569390, GASKET 1/4 GASKET 1/4
Ariston part no. 569390		 £1.16
114 Part number 573441, ELECTRODE (DETECTION) ELECTRODE (DETECTION)
Ariston part no. 573441		 £8.78
115 Part number 569560, ELECTRODE (IGNITION R.H.) ELECTRODE (IGNITION R.H.)
Ariston part no. 569560		 £5.87
116 Part number 569561, ELECTRODE (IGNITION L.H.) ELECTRODE (IGNITION L.H.)
Ariston part no. 569561		 £7.34
117   BURNER 15 RAMP (NATURAL GAS) 30KW
Ariston part no. 998110		 £105.28
117   BURNER 15 RAMP (LPG) 30KW
Ariston part no. 998111		 £105.28
118 Part number 998147, IGNITION ELECTRODE CABLE RUBBER IGNITION ELECTRODE CABLE RUBBER
Ariston part no. 998147		 £4.28
119 Part number 998139, MAIN HEAT EXCHANGER MAIN HEAT EXCHANGER
Ariston part no. 998139		 £257.27
119 Part number 998138, MAIN HEAT EXCHANGER MAIN HEAT EXCHANGER
Ariston part no. 998138		 £205.94
120   PANEL - FRONT COMBUSTION CHAMBER
Ariston part no. 572648		 £5.98
121   PANEL (R/H - COMBUSTION CHAMBER)
Ariston part no. 573242		 £3.39
122 Part number 998129, INSULATION PANEL - FRONT INSULATION PANEL - FRONT
Ariston part no. 998129		 £8.12
123   FLUE HOOD
Ariston part no. 998103		 £39.99
124   OBSOLETE CABLE(FAN/PCB/AIR PRESS.SWITCH
Ariston part no. 998107
125 Part number 998106, CABLE (FAN/AIR PRESSURE SWITCH) CABLE (FAN/AIR PRESSURE SWITCH)
Ariston part no. 998106		 £14.40
126   FIXING PLATE - FAN
Ariston part no. 573465		 £15.42
127 Part number 573314, VENTURI (EXHAUST/MANIFOLD HEADER) VENTURI (EXHAUST/MANIFOLD HEADER)
Ariston part no. 573314		 £6.91
301 Part number 571993, FRONT PANEL RUNNER KIT FRONT PANEL RUNNER KIT
Ariston part no. 571993		 £55.76
302   CASE PANEL (L.H. SIDE)
Ariston part no. 573012		 £20.73
303   OBSOLETE CASING PANEL (FRONT)
Ariston part no. 997226
304   OBSOLETE BOTTOM COVER
Ariston part no. 998066
305   OBSOLETE WARNING PLATE LID
Ariston part no. 997166
306   CASE PANEL (R.H. SIDE)
Ariston part no. 573011		 £30.02
511 Part number 998407, ISOLATING VALVE 3/4 (C.H. FLOW) ISOLATING VALVE 3/4 (C.H. FLOW)
Ariston part no. 998407		 £34.38
514 Part number 998406, UNION 1/2 (D.H.W. OUTLET) UNION 1/2 (D.H.W. OUTLET)
Ariston part no. 998406		 £12.47
515   DOUBLE CHECK VALVE
Ariston part no. 998080		 £18.89
516 Part number 998427, FLEXIBLE PIPE FLEXIBLE PIPE
Ariston part no. 998427		 £7.73
517 Part number 997741, OBSOLETE ISOLATING VALVE 1/2 (D.C.W. INLET) OBSOLETE ISOLATING VALVE 1/2 (D.C.W. INLET)
Ariston part no. 997741
519   ISOLATING VALVE 3/4 (C.H. RETURN)
Ariston part no. 997742		 £43.11
520   FLOW-RETURN PIPE (D=18)
Ariston part no. 998418		 £2.72
521   FLOW-RETURN PIPE (D=14)
Ariston part no. 998417		 £2.66
522   PIPE (GAS INLET)
Ariston part no. 997700		 £2.98
523 Part number 571000, ISOLATING VALVE - GAS INLET ISOLATING VALVE - GAS INLET
Ariston part no. 571000		 £16.29
571   BURNER GN
Ariston part no. 998152		 £5.54
572   BURNER JET (FULL KIT - LPG) (15 PCS)
Ariston part no. 998432		 £16.55


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
