ARISTON
PRIMO ITD 250 NEW (07/2007 TO 07/2011) - (Exploded View)
Appliance Code: 3060160

Appliance Diagram


Exploded View diagram for Ariston Primo ITD 250 New (07/2007 To 07/2011)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 65101884, HEATING ELEMENT+TH INSULATOR+ANODE HEATING ELEMENT+TH INSULATOR+ANODE
Ariston part no. 65101884
£44.60
3 Part number 65110976, THERMOSTAT TBS L:450 THERMOSTAT TBS L:450
Ariston part no. 65110976
£22.60
3 Part number 691216, THERMOSTAT L:300 THERMOSTAT L:300
Ariston part no. 691216
£14.26
7 Part number 60000100, THERMOSTAT TUBE THERMOSTAT TUBE
Ariston part no. 60000100
£85.09
22 Part number 60000225, SAFETY DEVICE PACK SAFETY DEVICE PACK
Ariston part no. 60000225
£155.27
22 Part number 969046, TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08) TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08)
Ariston part no. 969046
£76.84
33 Part number 924087, HEATING ELEMENT GASKET HEATING ELEMENT GASKET
Ariston part no. 924087
£15.16
38 Part number 935185, CUT-OUT THERMOSTAT INDIRECT CUT-OUT THERMOSTAT INDIRECT
Ariston part no. 935185
£36.21
51 Part number 992146, LEG HT 100 LEG HT 100
Ariston part no. 992146
£10.95
55 Part number 935184, REGULATION THERMOSTAT INDIRECT REGULATION THERMOSTAT INDIRECT
Ariston part no. 935184
£32.79
56 Part number 60001652, INDIRECT THERMOSTAT KIT + DUCT 70- INDIRECT THERMOSTAT KIT + DUCT 70-
Ariston part no. 60001652
£56.56
57 Part number 60000224, TWO-WAY VALVE TWO-WAY VALVE
Ariston part no. 60000224
£179.66
70 Part number 60000227, EXPANSION VESSEL 18L EXPANSION VESSEL 18L
Ariston part no. 60000227
£125.68
