BAXI
BOSTON 80 RS - (Optional Extras)
Appliance Code: 41-077-70

Appliance Diagram


Optional Extras diagram for Baxi Boston 80 RSClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE PANEL - TOP 110000 41-077-66 364-243
Baxi part no. 110000
2 Part number 112000, STUD-FOREST-FAST-SRV-1762-17-0 STUD-FOREST-FAST-SRV-1762-17-0
Baxi part no. 112000		 £2,50
3 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452		 £3,22
4   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440		 £3,11
5   OBSOLETE PANEL SIDE RH ASSY FS BOILERS
Baxi part no. 110001
6 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012		 £3,22
7 Part number 062325, CLIP-CABLE-GT CLIP-CABLE-GT
Baxi part no. 062325
8   OBSOLETE PANEL SIDE ASSY FS BOILERS
Baxi part no. 110002
9   OBSOLETE FRONT PANEL
Baxi part no. 110003
10   OBSOLETE BOX-COM-FS-801-701-601-RS
Baxi part no. 110004
11   OBSOLETE SCOOP CENTRAL - FS 60/70/80 RS
Baxi part no. 110071
12   OBSOLETE INSUL-SIDE-UPP-3 SECT.BLR.
Baxi part no. 112084
13   OBSOLETE PLATE INSULATION SIDE
Baxi part no. 110008
14   SCR-SET-M5X16MM-PAN HD PZ ZNPD
Baxi part no. 062708		 £2,35
15   OBSOLETE BRACKET OUTER CASE FIXING
Baxi part no. 110064
16 Part number 062683, SCR-ST-NO8x1/4 FLHD-POZI-ZPD B SCR-ST-NO8X1/4 FLHD-POZI-ZPD B
Baxi part no. 062683		 £2,53
18   NUT-FULL HEX-4MM-ZINC PLTD
Baxi part no. 062439		 £3,11
20   OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD
Baxi part no. 062451
22   OBSOLETE INSUL-FRONT-3-SECTION-BOILER
Baxi part no. 112064
23   OBSOLETE SUPPORT-INSUL-FRONT-ASSY-3-SEC
Baxi part no. 226686
24 Part number 062571, SCR-ST-No8x1/2PAN.HD PZ ZNPD A SCR-ST-NO8X1/2PAN.HD PZ ZNPD A
Baxi part no. 062571		 £3,22
25   OBSOLETE INSUL-REAR-RS-FS-BOILERS
Baxi part no. 112006
26   WASHER-RETAINING-SPECIAL-ST/S
Baxi part no. 110011		 £15,01
27 Part number 062583, SCR-TF-M5x10mm PN HD PZ S ZNPD SCR-TF-M5X10MM PN HD PZ S ZNPD
Baxi part no. 062583		 £3,22
28   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319
29 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320		 £2,48
30 Part number 062531, SCR-TF-M5x8mm-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531		 £3,22
31   OBSOLETE PANEL INSPECTION.COMB.BOX - ALL FS
Baxi part no. 110014
32   OBSOLETE SEAL-PANEL-INSP-9.5MM X 395MM-DI
Baxi part no. 112056
34   OBSOLETE GROMMET-SEAL-BOILER
Baxi part no. 112008
36   OBSOLETE SEAL-PANEL-DOOR-9.5MM X 240MM-DI
Baxi part no. 112057
37   OBSOLETE AIR BOX-ASSY-F.S. BOILERS
Baxi part no. 110018
38   OBSOLETE MACHINE SCREW M6 X 20 RECESSED PAN HEAD -
Baxi part no. 062696
39   OBSOLETE TERMINAL - STANDARD FLUE - COLOURED
Baxi part no. 230736
40 Part number 226685, OBSOLETE TESTED BOILER ASSY-3 SECTION OBSOLETE TESTED BOILER ASSY-3 SECTION
Baxi part no. 226685
41   OBSOLETE BOILER SECTION - LEFT HAND 111002 41-077-6
Baxi part no. 111002
42   OBSOLETE BOILER SECTION - CENTRE 111004 41-077-64
Baxi part no. 111004
43   OBSOLETE SECTION-RH-ASSY-FS BLR-3 SECT.
Baxi part no. 110005
44 Part number 112009, GASKET-FS-BOILER GASKET-FS-BOILER
Baxi part no. 112009
46 Part number 042889, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889
46 Part number 042889BAX, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889BAX
47   OBSOLETE SPREADER-WATER-3 SECTION-FSB
Baxi part no. 112020
48 Part number 110040, OBSOLETE ROPE GASKET OBSOLETE ROPE GASKET
Baxi part no. 110040
48 Part number 112058, OBSOLETE SEAL-BOILER-END-8.0mm x 46mm-DIA OBSOLETE SEAL-BOILER-END-8.0MM X 46MM-DIA
Baxi part no. 112058
49   OBSOLETE PANEL-DOOR-ASSY-FS-801-RS
Baxi part no. 110023
50   OBSOLETE PANEL-DOOR-ASSY-FS-701-RS
Baxi part no. 110024
51   OBSOLETE PANEL-DOOR-ASSY-FS-601-RS
Baxi part no. 110025
52   NUT-WING-M6-ZN-PD
Baxi part no. 112028
53   OBSOLETE KIT-SIGHT-WINDOW-WM532-381RS
Baxi part no. 100134
54 Part number 112012, OBSOLETE BURNER-BOILER-3-SECTION-AEROMT OBSOLETE BURNER-BOILER-3-SECTION-AEROMT
Baxi part no. 112012
56 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Baxi part no. 635506
56 Part number 112031, M 5 NUT M 5 NUT
Baxi part no. 112031
58   OBSOLETE INJECTOR-BURNER-FS-701-RS
Baxi part no. 112022
60   OBSOLETE KIT-PIPE-BNR-FEED-TWIN-FSB
Baxi part no. 110144
60   OBSOLETE O RING-24MM ID X 4MM SECTION
Baxi part no. 112082
61 Part number 062623, NOW USE V4600C1086 VALVE-CONT-MULTI-H/WELL NOW USE V4600C1086 VALVE-CONT-MULTI-H/WELL
Baxi part no. 062623
61 Part number V4600C1086, GAS VALVE TRADELINE NG GAS VALVE TRADELINE NG
Baxi part no. V4600C1086		 £114,05
61 Part number V4600C1029, NOW USE V4600C1086 HONEYWELL GAS VALVE NOW USE V4600C1086 HONEYWELL GAS VALVE
Baxi part no. V4600C1029
62   OBSOLETE COVER-ELECTRICAL-PLASTIC
Baxi part no. 112044
63   OBSOLETE SCR-SET-M4X16MM-PAN-HD-POZ-ZNP
Baxi part no. 112043
64   OBSOLETE KIT-PIPE-INLET-FS-BOILER
Baxi part no. 110143
65   OBSOLETE TAP-SERV-STR-SIRAL-REF-0073853
Baxi part no. 112081
66   OBSOLETE SHIELD-HEAT-PROT.-IGN-MNTG-FS
Baxi part no. 110030
67   OBSOLETE BURNER PILOT H/WELL Q359A 1058
Baxi part no. 082211
67   OBSOLETE PILOT BURNER/BRKT ASSY
Baxi part no. 402841
68 Part number 102024, ELECTRODE-PILOT-IGNITION ELECTRODE-PILOT-IGNITION
Baxi part no. 102024		 £7,24
69 Part number 042740, LEAD-ELECTRODE-675 LEAD-ELECTRODE-675
Baxi part no. 042740
70 Part number 112011, OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A
Baxi part no. 112011
70 Part number 402560, OBSOLETE PILOT INJECTOR (STD) OBSOLETE PILOT INJECTOR (STD)
Baxi part no. 402560
71 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532		 £3,11
72 Part number 102005, THERM-18/24HWELL-Q309A2721 STD THERM-18/24HWELL-Q309A2721 STD
Baxi part no. 102005		 £19,74
74   OBSOLETE PIPE-PIL-FEED-NUTS-OLIVE.T-BNR
Baxi part no. 110007
75 Part number 040456, KIT-PIEZO IGN-BERM 552 KIT-PIEZO IGN-BERM 552
Baxi part no. 040456
76   OBSOLETE GRIP-CABLE-HEYCO-SR-5-M3
Baxi part no. 102197
77   OBSOLETE PLUG 3 PIN LEADS FS BOILER
Baxi part no. 110031
78   OBSOLETE FACIA-CONTROL-GREY
Baxi part no. 231246
79   OBSOLETE KIT-BEZEL-BROWN-BOSTON
Baxi part no. 231247
80 Part number 112025, OBSOLETE THERMOSTAT RANCO OBSOLETE THERMOSTAT RANCO
Baxi part no. 112025
81   OBSOLETE KNOB T/STAT BROWN-BOSTON
Baxi part no. 231212
82   OBSOLETE SUPPORT TERMINAL
Baxi part no. 110034
83   OBSOLETE WASHER-PLAIN-4MM-ZINC. PLTD
Baxi part no. 062446
84   OBSOLETE CLAMP-CABLE-PLASTIC
Baxi part no. 112048
85   OBSOLETE TAPPING SCREW ISO NO.4AB X 19 RECESSED PAN
Baxi part no. 062716
87   OBSOLETE ASSY-3 PIN SOCKET & LEADS-FSB
Baxi part no. 226690
88   OBSOLETE WASHER-ANTI-LOSS
Baxi part no. 112030
89   OBSOLETE CAPACITOR ASSY-FS-BOILERS
Baxi part no. 110039
