BAXI
GASFLAME WL SUPER - (Appliance Overview)
Appliance Code: 32-077-28

Appliance Diagram


Appliance Overview diagram for Baxi Gasflame WL SuperClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE OUTER CASE ONLY-GAS FL WL SUPER
Baxi part no. 090174

2   OBSOLETE BEZEL-KNOB ASSY-WL SUPER
Baxi part no. 090175

3 Part number 062595, BUTTON-INDIC-UTD.CARR 70270-06 BUTTON-INDIC-UTD.CARR 70270-06
Baxi part no. 062595

4 Part number 228954, SWITCH-ON/OFF SWITCH-ON/OFF
Baxi part no. 228954

5   OBSOLETE SHIELD-HEAT-BEZEL-GAS FL WS
Baxi part no. 090142

6 Part number 062325, CLIP-CABLE-GT CLIP-CABLE-GT
Baxi part no. 062325

7   SCR-NO 8X14TPIX1/2 HARDTWIN-WD
Baxi part no. 042244
£2.18
8   OBSOLETE DISTANCE PIECE SIDE GAS FL WL
Baxi part no. 090120

9   OBSOLETE LOUVRE-ASSY-LFE SUPER
Baxi part no. 090121

10   OBSOLETE CAP LOUVRE END RH
Baxi part no. 092096

11   OBSOLETE CAP LOUVRE END LH
Baxi part no. 092097

12   OBSOLETE CHANNEL-CASE TOP-GAS FL WS
Baxi part no. 090122

13   OBSOLETE WOOD SCREW NO.8 X 1/2IN. TWINFAST RECESSED
Baxi part no. 062755

14   OBSOLETE CANOPY-GAS FLAME WL/LFE5 SUPER
Baxi part no. 092109

15   OBSOLETE SHIELD HEAT CANOPY LFE
Baxi part no. 223348

16   SCR-ST-NO8X3/8 FL.PZ.CH.BLK.AB
Baxi part no. 062731
£2.47
17   OBSOLETE BRKT-HEARTH LOC-RH GAS FL WS
Baxi part no. 090133

18   BRKT-HEARTH LOC-LH GAS FL WS
Baxi part no. 090132
£2.99
19   OBSOLETE LABEL - USERS CAUTION
Baxi part no. 045418

20   OBSOLETE PAPERCLIP - BRASS
Baxi part no. 042934

21   OBSOLETE PANEL-HEARTH-BER LFE 3
Baxi part no. 092119

22 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548
£3.01
23   OBSOLETE KIT-REFLECTOR LAMPS LOWER
Baxi part no. 225694

24   OBSOLETE BOX-ELECTRIC ASSY-GAS FL WS
Baxi part no. 090144

25 Part number 042260POT, LAMP HOLDER LAMP HOLDER
Baxi part no. 042260POT

25 Part number 042260, OBSOLETE LAMP HOLDER WITH RIM OBSOLETE LAMP HOLDER WITH RIM
Baxi part no. 042260

26 Part number 5134533, OBSOLETE PLUG & SOCKET 3 PIN OBSOLETE PLUG & SOCKET 3 PIN
Baxi part no. 5134533

26 Part number 042971, OBSOLETE PLUG - 3-PIN OBSOLETE PLUG - 3-PIN
Baxi part no. 042971

27   RIVET-SNAP-NYLON
Baxi part no. 062758
£2.43
28 Part number 062560, SCR-TF-M4 x 6mm PAN POZI ZN P SCR-TF-M4 X 6MM PAN POZI ZN P
Baxi part no. 062560
£3.12
29   OBSOLETE KIT-WIRES-GAS FL WL-SUPER
Baxi part no. 090181

30 Part number 043215, OBSOLETE RESISTOR-207ohms-SUPER MODELS OBSOLETE RESISTOR-207OHMS-SUPER MODELS
Baxi part no. 043215

30   OBSOLETE RESISTOR-208 OHMS
Baxi part no. 226266

31 Part number 042261, LAMP-60 WATT-RED LAMP-60 WATT-RED
Baxi part no. 042261

34   OBSOLETE BRKT-CASE FIXING.GAS FLAME WS
Baxi part no. 090125

35   OBSOLETE REFLECTOR-ASSY-LFE RANGE
Baxi part no. 090156

36   OBSOLETE COVER-PANEL HEARTH GAS FL.WS
Baxi part no. 092100

37   OBSOLETE TRIM - PANEL - HEARTH
Baxi part no. 092098

38   OBSOLETE TRIM-HEARTH-OUTER LH-GAS FL WS
Baxi part no. 092099

40   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010
£2.04
41   OBSOLETE TRIM-HEARTH-OUTER RH GAS FL WS
Baxi part no. 092101

42   OBSOLETE TRIM HEARTH-RH-GAS FLAME WS
Baxi part no. 090138

43   NUT-FLAT-NO8-LEWIS SPR-401/11
Baxi part no. 042870
£2.25
44   OBSOLETE STRAP-LOWER-GAS FL WS
Baxi part no. 090127

45   OBSOLETE DIFFUSER-LIGHT-GAS FL WS
Baxi part no. 090128

47 Part number 040971, OBSOLETE BRKT CLIP RETAINING ASSY S2&C3 OBSOLETE BRKT CLIP RETAINING ASSY S2&C3
Baxi part no. 040971

48   OBSOLETE PLATE-COVER ASSY GAS FLAME WL
Baxi part no. 090160

49 Part number 062593, OBSOLETE CLIP-MALE-TERRY 487-605 OBSOLETE CLIP-MALE-TERRY 487-605
Baxi part no. 062593

50 Part number 062699, SCR-ST-No6x3/8 PAN HD PZ ZP SCR-ST-NO6X3/8 PAN HD PZ ZP
Baxi part no. 062699
£3.12
51   CLIP-CABLE.RICHCO.WHC250N
Baxi part no. 043219
£1.63
52   OBSOLETE HEAT EXCH ASSY GAS FLAME
Baxi part no. 090083

53   TRIM - HEAT EXCHANGER - G.F.
Baxi part no. 040934

55   OBSOLETE STRIP - SEAL RETAINING
Baxi part no. 040978

56   BRKT-BURNER SUPP.ASSY-BER.GF
Baxi part no. 040985
£2.68
57   OBSOLETE GASKET HEAT EXCHANGER
Baxi part no. 229308

58 Part number 043111, SEAL-GLASS FRAME-GF SEAL-GLASS FRAME-GF
Baxi part no. 043111

59   OBSOLETE CHANNEL GLASS FRAME SUPPORT
Baxi part no. 225195

60 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
61   SCR-ST-NO8X1/2 PAN POZI S/S A
Baxi part no. 062725

63   SCR-SET-M5X12MM-HX.HD.SLT ZNPD
Baxi part no. 062729
£2.03
64   OBSOLETE PLATE-BACK-ASSY-G.F.
Baxi part no. 040938

65   OBSOLETE DEFLECTOR-HEAT-GAS FL WS
Baxi part no. 090153

66   OBSOLETE TAPPING SCREW ISO NO. 8AB X 19 RECESSED PA
Baxi part no. 062748

67   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447
£2.36
68   OBSOLETE HEAT SHIELD - WALL
Baxi part no. 090155

73   OBSOLETE FRAME - MOUNTING.- G.F
Baxi part no. 220466

74 Part number 040004, BRACKET SPINDLE SUPPORT LFE3 BRACKET SPINDLE SUPPORT LFE3
Baxi part no. 040004
£4.39
75   OBSOLETE BRKT-PIPE-INLET FEED.GAS FLAME
Baxi part no. 090089

76 Part number 062571, SCR-ST-No8x1/2PAN.HD PZ ZNPD A SCR-ST-NO8X1/2PAN.HD PZ ZNPD A
Baxi part no. 062571
£3.12
77   OBSOLETE PLATE-BACKING-BER LFE 3
Baxi part no. 090130

78 Part number 062531, SCR-TF-M5x8MM-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531
£3.12
79   BRKT-GAS TAP MOUNT-BER LFE 3
Baxi part no. 090131
£10.62
80 Part number 227313, CAP-PROTECTION CAP-PROTECTION
Baxi part no. 227313
£1.87
80   SCR-SET-M8X35MM-HEX.HD.BLK
Baxi part no. 062749
£2.33
81   OBSOLETE FULL NUT M8 HEXAGON - STEEL GRADE 8. BS369
Baxi part no. 062723

82 Part number 040955, SPARES Assy Frame/Glass GF SPARES ASSY FRAME/GLASS GF
Baxi part no. 040955
£168.60
83   REFLECTOR-LAMPS-UPPER.-G.F.
Baxi part no. 040944
£7.37
83   SCR-ST-NO8X3/8-FL.HD POZ B
Baxi part no. 062648
£2.78
86   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319

87 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320
£2.41
88 Part number 062549, SCR-ST-No8x1/2 POZI FLANGE SCR-ST-NO8X1/2 POZI FLANGE
Baxi part no. 062549
£3.12
89 Part number 090159, KNOB-GAS TAP CONTROL ASSY LFE3 KNOB-GAS TAP CONTROL ASSY LFE3
Baxi part no. 090159
£12.85
90 Part number 092104, OBSOLETE SPINDLE-EXTENSION-BER LFE 3 OBSOLETE SPINDLE-EXTENSION-BER LFE 3
Baxi part no. 092104

91 Part number 092124, PIN-SPLIT-2.5O x 15mm PIN-SPLIT-2.5O X 15MM
Baxi part no. 092124

92   OBSOLETE ELBOW-INLET-GAS FLAME WS
Baxi part no. 092110

93   OBSOLETE PIPE-INLET FEED ASSY-GAS FL WL
Baxi part no. 092117

94 Part number 092132, OBSOLETE FFD/GAS TAP-GAS FLAME SUPER OBSOLETE FFD/GAS TAP-GAS FLAME SUPER
Baxi part no. 092132

95 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941

96 Part number 082462, MAGNETIC UNIT-BRAZILIA 8000 C MAGNETIC UNIT-BRAZILIA 8000 C
Baxi part no. 082462

97   PIPE BRNR FEED
Baxi part no. 090146

97   PIPE-BURNER FEED FRNT-GAS F WS
Baxi part no. 092106

98   PIPE-BURNER FEED REAR-GAS F WS
Baxi part no. 092107
£4.27
98   OBSOLETE PIPE BRNR FEED REAR.N&O WS
Baxi part no. 090147

99   OBSOLETE INJECTOR-FIRE-CAT 18/230
Baxi part no. 092133

100 Part number 043210, BURNER-TYPE 2-BER GF SUPER-NG BURNER-TYPE 2-BER GF SUPER-NG
Baxi part no. 043210

103 Part number 092136, THERMOCOUPLE-SITx400mm-INC.NUT THERMOCOUPLE-SITX400MM-INC.NUT
Baxi part no. 092136

104 Part number 092137, ELECTRODE-GAS FLAME SUPER ELECTRODE-GAS FLAME SUPER
Baxi part no. 092137

106 Part number 043206, OBSOLETE COAL BED-TYPE 2-NG OBSOLETE COAL BED-TYPE 2-NG
Baxi part no. 043206

107   OBSOLETE FITTERS INSTRUCTIONS
Baxi part no. DUMMY
