SOLO 3 PFL 80 SYSTEM - (Appliance Overview)
Appliance Code: 41-075-31

Appliance Diagram


Appliance Overview diagram for Baxi Solo 3 PFL 80 SystemClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   KIT - SOLO PF3 DUPLEX FLUE
Baxi part no. 247654		 £277.02
0   OBSOLETE 250MM EXTENSION KIT
Baxi part no. 246113
0   OBSOLETE 500MM EXTENSION KIT
Baxi part no. 246114
0 Part number 246115, 1000MM EXTENSION KIT 1000MM EXTENSION KIT
Baxi part no. 246115		 £113.35
1 Part number 248592, OBSOLETE PACKED PF3 SYSTEM-OUTER CASE OBSOLETE PACKED PF3 SYSTEM-OUTER CASE
Baxi part no. 248592
3   OBSOLETE ASSY PANEL DOOR OUTER CASE
Baxi part no. 245433
9 Part number 246174, OBSOLETE MAGNET OBSOLETE MAGNET
Baxi part no. 246174
10 Part number 245775, KIT-DOOR-PAIR OF HINGES-BAHAMA KIT-DOOR-PAIR OF HINGES-BAHAMA
Baxi part no. 245775		 £17.42
11 Part number 225310BAX, SCR-ST-No6x1/4in FLHD POZI AB SCR-ST-NO6X1/4IN FLHD POZI AB
Baxi part no. 225310BAX		 £3.03
12 Part number 243302, COMB BOX ASSY PF3 LARGE COMB BOX ASSY PF3 LARGE
Baxi part no. 243302		 £123.91
13   COM BOX DOOR ASSEMBLY - LARGE
Baxi part no. 244174		 £18.55
14 Part number 224183, WINDOW-VIEWING.WM40/4RS WINDOW-VIEWING.WM40/4RS
Baxi part no. 224183
15 Part number 231394, GROMMET SAMPLING PIPE GROMMET SAMPLING PIPE
Baxi part no. 231394
16 Part number 230652, INSULATION SIDE LH - PF MK 2 INSULATION SIDE LH - PF MK 2
Baxi part no. 230652
17 Part number 230653, INSULATION SIDE RH - PF MK 2 INSULATION SIDE RH - PF MK 2
Baxi part no. 230653		 £17.09
18 Part number 230817, Retainer Insulation RETAINER INSULATION
Baxi part no. 230817		 £1.98
19 Part number 230759, LATCH TOGGLE COMB BOX-PF MK 2 LATCH TOGGLE COMB BOX-PF MK 2
Baxi part no. 230759
20 Part number 230760, LATCH TOGGLE DOOR - PF MK 2 LATCH TOGGLE DOOR - PF MK 2
Baxi part no. 230760
21 Part number 246056, NOW USE 231453 R CLIP NOW USE 231453 R CLIP
Baxi part no. 246056
21 Part number 231453, R - CLIP R - CLIP
Baxi part no. 231453		 £9.71
22   OBSOLETE GROMMET
Baxi part no. 231141BAX
23 Part number 230673, MANIFOLD - PF MK 2 MANIFOLD - PF MK 2
Baxi part no. 230673		 £109.24
24 Part number 230684, GASKET MANIFOLD TO VALVE GASKET MANIFOLD TO VALVE
Baxi part no. 230684		 £3.16
24 Part number 246175, KIT-MANIFOLD BLOCK GAS KIT-MANIFOLD BLOCK GAS
Baxi part no. 246175		 £220.57
25 Part number 230979, GASKET-MANIFOLD TO COMB.BOX GASKET-MANIFOLD TO COMB.BOX
Baxi part no. 230979		 £4.44
26 Part number 236142, PILOT KIT-PF2 PILOT KIT-PF2
Baxi part no. 236142		 £30.24
27   OBSOLETE KIT BURNER INJECTOR
Baxi part no. 246161
27 Part number 246162, OBSOLETE KIT-BURNER INJECTOR-B34-PF 70 OBSOLETE KIT-BURNER INJECTOR-B34-PF 70
Baxi part no. 246162
27   OBSOLETE INJECTOR EXT.ASSY - B34
Baxi part no. 244997
28 Part number 246179, OBSOLETE KIT-MANIFOLD GAS OBSOLETE KIT-MANIFOLD GAS
Baxi part no. 246179
29   OBSOLETE BRACKET MOUNTING VALVE
Baxi part no. 243999
29   OBSOLETE KIT BRACKET MOUNTING VALVE
Baxi part no. 246180
30   OBSOLETE KIT-PIPE GAS MANIFOLD-60/70/80
Baxi part no. 246164
31   OBSOLETE KIT-PIPE PILOT-60/70/80
Baxi part no. 246165
32 Part number 245122, VALVE SOFTLITE KIT INC GASKETS VALVE SOFTLITE KIT INC GASKETS
Baxi part no. 245122		 £136.16
33   OBSOLETE O RING-24MM ID X 4MM SECTION
Baxi part no. 112082
33   OBSOLETE KIT - PIPE FEED GAS
Baxi part no. 246183
34   COVER VALVE - PF 2/3
Baxi part no. 231185		 £17.79
35 Part number 231438BAX, SCR SET M4x30mm POZI PAN STEEL SCR SET M4X30MM POZI PAN STEEL
Baxi part no. 231438BAX		 £2.26
36   BAFFLE TOP HEAT EXCHANGER
Baxi part no. 242887		 £7.67
36   NOW USE 242887 KIT BAFFLE TOP LARGE
Baxi part no. 246048
37   OBSOLETE SHIELD ELECTRICAL
Baxi part no. 246167
38 Part number 246046, KIT - HEAT EXCHANGER - LARGE KIT - HEAT EXCHANGER - LARGE
Baxi part no. 246046		 £469.28
39 Part number 230654, INSULATION HEADER LH - PF MK 2 INSULATION HEADER LH - PF MK 2
Baxi part no. 230654		 £16.01
40 Part number 230970, OBSOLETE SEAL H OBSOLETE SEAL H
Baxi part no. 230970
41 Part number 230655, INSULATION HEADER RH INSULATION HEADER RH
Baxi part no. 230655
42 Part number 230877, PLATE RETAINING HEAT EXCHANGER PLATE RETAINING HEAT EXCHANGER
Baxi part no. 230877		 £27.81
43   OBSOLETE ADAPTER RETENTION
Baxi part no. 244101
44 Part number 231016, Burner Large (Tested) BURNER LARGE (TESTED)
Baxi part no. 231016		 £49.81
45   OBSOLETE SCREW SET M5 X 25MM HEX
Baxi part no. 244798
47 Part number 62532, NOW USE 062532 SCR-TF-M4x8mm-PAN POZI ZN PD NOW USE 062532 SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 62532
47 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532		 £2.93
49   OBSOLETE KIT-AIR BOX/WALL MTG ASSY-SMALL
Baxi part no. 246186
50 Part number 231026, PLATE BLANKING PLATE BLANKING
Baxi part no. 231026		 £17.45
51 Part number 231322BAX, SEAL BLANKING PLATE.PF MK2 SEAL BLANKING PLATE.PF MK2
Baxi part no. 231322BAX		 £4.44
52 Part number 230875, Retainer Turret RETAINER TURRET
Baxi part no. 230875		 £5.81
53 Part number 230955, SEAL - FAN TO TURRET - PF MK 2 SEAL - FAN TO TURRET - PF MK 2
Baxi part no. 230955		 £15.98
54 Part number 230326, TURRET-PF MK 2 & 3 TURRET-PF MK 2 & 3
Baxi part no. 230326		 £20.52
55 Part number 226823, Assy Blanking Cap 70/PF ASSY BLANKING CAP 70/PF
Baxi part no. 226823		 £9.05
56 Part number 225941, O RING-WM.PF O RING-WM.PF
Baxi part no. 225941
57 Part number 231458, CAP & SCOOP ASSY CAP & SCOOP ASSY
Baxi part no. 231458		 £13.30
58 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548		 £2.93
58 Part number 62548, NOW USE 062548 SCR-ST-No 8x3/8in POZI FL.HD A NOW USE 062548 SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 62548
59   OBSOLETE KIT - FIXING NUTS
Baxi part no. 246187
60 Part number 240838, VALVE-ANGLED-GAS-G3/4in VALVE-ANGLED-GAS-G3/4IN
Baxi part no. 240838		 £18.23
61 Part number 240806, VALVE-ANGLED-WATER-G3/4in VALVE-ANGLED-WATER-G3/4IN
Baxi part no. 240806		 £58.34
62 Part number 240805, OBSOLETE VALVE-ANGLED-WATER-G1/2in OBSOLETE VALVE-ANGLED-WATER-G1/2IN
Baxi part no. 240805
65 Part number 246188, KIT - FIBRE WASHERS KIT - FIBRE WASHERS
Baxi part no. 246188
66   OBSOLETE KIT-WALL PLATE ASSY-LARGE
Baxi part no. 246169
68   OBSOLETE KIT HINGE BOSS
Baxi part no. 244748
69   OBSOLETE BRACKET TRANSIT FRONT - 50PF3
Baxi part no. 245023
69   OBSOLETE KIT TRANSIT BRACKET LARGE
Baxi part no. 246170
70 Part number 240388, TANK EXPANSION TANK EXPANSION
Baxi part no. 240388		 £120.61
71 Part number 244540, THERMISTOR THERMISTOR
Baxi part no. 244540		 £18.51
72 Part number 5106746, KIT-SOLO PF OVERHEAT STAT KIT-SOLO PF OVERHEAT STAT
Baxi part no. 5106746		 £30.35
73 Part number 240396, VENT AUTO VENT AUTO
Baxi part no. 240396		 £24.33
74   OBSOLETE KIT PIPE FLOW BOILER SMALL
Baxi part no. 246171
75   OBSOLETE PIPE RETURN BOILER
Baxi part no. 246172
76 Part number 244741, NOW USE 243342 KIT PIPE VENT AUTO NOW USE 243342 KIT PIPE VENT AUTO
Baxi part no. 244741
76 Part number 243342, PIPE VENT AUTO PIPE VENT AUTO
Baxi part no. 243342		 £7.60
77 Part number 5000721, VALVE PRESSURE RELIEF. VALVE PRESSURE RELIEF.
Baxi part no. 5000721		 £21.72
77 Part number 241567, NOW USE 5000721 SAFETY VALVE (PRV) NOW USE 5000721 SAFETY VALVE (PRV)
Baxi part no. 241567
78 Part number 243351, PIPE CONNECTION PIPE CONNECTION
Baxi part no. 243351		 £31.15
78 Part number 246193, NOW USE 243351 PIPE CONNECTION NOW USE 243351 PIPE CONNECTION
Baxi part no. 246193
79 Part number 240395, NOW USE 5113411 PUMP NOW USE 5113411 PUMP
Baxi part no. 240395
79 Part number 5113411, PUMP HEAD REPLACEMENT INC SEAL PUMP HEAD REPLACEMENT INC SEAL
Baxi part no. 5113411
80 Part number 242369, MANIFOLD PUMP VALVE MANIFOLD PUMP VALVE
Baxi part no. 242369		 £64.91
80 Part number 244742, NOW USE 242369 MANIFOLD PUMP NOW USE 242369 MANIFOLD PUMP
Baxi part no. 244742
81   OBSOLETE KIT BRACKET PUMP LOWER
Baxi part no. 244743
82 Part number 244663, SCREW M6 x 45MM SET PAN POZI SCREW M6 X 45MM SET PAN POZI
Baxi part no. 244663		 £2.33
83 Part number 062441, NUT-FULL HEX-6MM ZINC PLTD NUT-FULL HEX-6MM ZINC PLTD
Baxi part no. 062441		 £2.93
83 Part number 62441, NOW USE 062441 NUT-FULL HEX-6MM ZINC PLTD NOW USE 062441 NUT-FULL HEX-6MM ZINC PLTD
Baxi part no. 62441
85 Part number 230259, COVER CONTROL BOX PF M COVER CONTROL BOX PF M
Baxi part no. 230259		 £13.23
85 Part number 231249BAX, COVER - PROTECTION - PF MK2 COVER - PROTECTION - PF MK2
Baxi part no. 231249BAX		 £7.67
86 Part number 230981, KNOB - THERMOSTAT KNOB - THERMOSTAT
Baxi part no. 230981		 £9.23
87 Part number 231252BAX, CONTROL POTENTIOMETER & LEADS CONTROL POTENTIOMETER & LEADS
Baxi part no. 231252BAX		 £35.88
88 Part number 231711BAX, ELECTS CONTL BOARD (KIT)-PF2 ELECTS CONTL BOARD (KIT)-PF2
Baxi part no. 231711BAX		 £255.62
89 Part number 230258BAX, BOX CONTROLS - PF 2/3 BOX CONTROLS - PF 2/3
Baxi part no. 230258BAX		 £18.57
90   OBSOLETE BRACKET MOUNTING ELECTRICAL
Baxi part no. 243987
90   OBSOLETE KIT BRACKET MOUNTING ELECTRICS
Baxi part no. 246194
91 Part number 231405, SCR-ST No 6x1/2-PAN-POZI-PL SCR-ST NO 6X1/2-PAN-POZI-PL
Baxi part no. 231405		 £3.07
92   OBSOLETE FACIA - UK - PF3 (SYSTEM)
Baxi part no. 244310
93 Part number 241190, PRESSURE GUAGE - SPARES PRESSURE GUAGE - SPARES
Baxi part no. 241190		 £35.03
97 Part number 246052, KIT - FAN - LARGE KIT - FAN - LARGE
Baxi part no. 246052		 £323.96
99 Part number 246061, NOW USE 244430 RESTRICTOR NOW USE 244430 RESTRICTOR
Baxi part no. 246061
99 Part number 244428, PLATE RESTRICTOR FAN PLATE RESTRICTOR FAN
Baxi part no. 244428
99 Part number 5114472, SHORT SIDE FLUE COMBUSTION KIT SHORT SIDE FLUE COMBUSTION KIT
Baxi part no. 5114472
99 Part number 244430, Plate Restrictor Fan PF70 PLATE RESTRICTOR FAN PF70
Baxi part no. 244430		 £3.51
100 Part number 246197, KIT - PIPES PRESSURE SWITCH KIT - PIPES PRESSURE SWITCH
Baxi part no. 246197
101 Part number 720954201, PRESSURE SWITCH SOLO 60 PF PRESSURE SWITCH SOLO 60 PF
Baxi part no. 720954201		 £54.80
101 Part number 5111609, NOW USE 720954201 KIT - PRESSURE SWITCH 60 PF3 NOW USE 720954201 KIT - PRESSURE SWITCH 60 PF3
Baxi part no. 5111609
102 Part number 244113, OBSOLETE GASKET FAN OBSOLETE GASKET FAN
Baxi part no. 244113
103   OBSOLETE BOX MOUNTING FAN
Baxi part no. 243739
104   OBSOLETE FRONT INSULATION ASSY - LARGE
Baxi part no. 244173
105 Part number 231093BAX, INSULATION FRONT LARGE-PF MK 2 INSULATION FRONT LARGE-PF MK 2
Baxi part no. 231093BAX
106   OBSOLETE KIT - INSULATION FASTENER
Baxi part no. 246198
107   NOW USE 244026 KIT BRACKET MOUNTING P/SWITCH
Baxi part no. 246199
107   BRKT MOUNTING SWITCH PRESSURE
Baxi part no. 244026		 £3.88
108 Part number 230842, SAMPLING PIPE - SOLO PF MK 2 SAMPLING PIPE - SOLO PF MK 2
Baxi part no. 230842		 £10.12
109 Part number 112066, CLIP-RETAIN-BRIERLY-SPRG-11157 CLIP-RETAIN-BRIERLY-SPRG-11157
Baxi part no. 112066		 £11.80
111 Part number 244812, HARNESS WIRING BOILER ASSY HARNESS WIRING BOILER ASSY
Baxi part no. 244812		 £45.85
112 Part number 244813, HARNESS WIRING VALVE HARNESS WIRING VALVE
Baxi part no. 244813		 £11.67
114   WALL LINER/INTERNAL FIXING
Baxi part no. 236441BAX		 £26.66
115 Part number 226260, O RING-SEAL-INTERNAL FIX.KIT O RING-SEAL-INTERNAL FIX.KIT
Baxi part no. 226260		 £4.95
116 Part number 244082, OBSOLETE PF MK3 FLUE KIT ASSY 9in-15in OBSOLETE PF MK3 FLUE KIT ASSY 9IN-15IN
Baxi part no. 244082
118   OBSOLETE KIT SECURITY
Baxi part no. 245068
119 Part number 231099BAX, O RING AIR DUCT - PF MK 2 O RING AIR DUCT - PF MK 2
Baxi part no. 231099BAX		 £12.53
119 Part number 246069, NOW USE 231099BAX O RING AIR DUCT NOW USE 231099BAX O RING AIR DUCT
Baxi part no. 246069
120 Part number 246070, OBSOLETE FLUE OBSOLETE FLUE
Baxi part no. 246070
121 Part number 231402, FUSE-4AMP-QUICK BLOW-PF MK2 FUSE-4AMP-QUICK BLOW-PF MK2
Baxi part no. 231402		 £2.97
122 Part number 245277, OBSOLETE LEAD ELECTRODE OBSOLETE LEAD ELECTRODE
Baxi part no. 245277
123 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532		 £2.93


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
