CHAFFOTEAUX
BRITONY COMBI SE 100 - (Flue)
Appliance Code: 47-980-17

Appliance Diagram


Flue diagram for Chaffoteaux Britony Combi SE 100Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 61013091, PROGRAMMER CABLE PROGRAMMER CABLE
Chaffoteaux part no. 61013091
£10.49
102 Part number 60081722, COMBUSTION CHAMBER LINING KIT COMBUSTION CHAMBER LINING KIT
Chaffoteaux part no. 60081722

103 Part number 61010050, CLIP CLIP
Chaffoteaux part no. 61010050
£3.87
104 Part number 61303566, OVERHEAT THERMOSTAT 105C OVERHEAT THERMOSTAT 105C
Chaffoteaux part no. 61303566
£6.16
105 Part number 61002811, CROSS LIGHTING STRIP CROSS LIGHTING STRIP
Chaffoteaux part no. 61002811
£5.69
106 Part number 61010648, TAPPING SCREW CBLSX D: 6.3-13 TAPPING SCREW CBLSX D: 6.3-13
Chaffoteaux part no. 61010648
£0.44
107 Part number 61010753, BURNER HEAD BURNER HEAD
Chaffoteaux part no. 61010753
£119.86
109   GRILLE
Chaffoteaux part no. 61010223
£23.24
110 Part number 61002801, IGNITION ELECTRODE IGNITION ELECTRODE
Chaffoteaux part no. 61002801
£41.99
111 Part number 61002802, IONISATION ELECTRODE IONISATION ELECTRODE
Chaffoteaux part no. 61002802
£21.20
113 Part number 61011136, HEAT EXCHANGER HEAT EXCHANGER
Chaffoteaux part no. 61011136
£324.77
114 Part number 60081721, COMBUSTION CHAMBER ASSY COMBUSTION CHAMBER ASSY
Chaffoteaux part no. 60081721
£170.30
115 Part number 61010125, TAPPING SCREW CBLSX D: 4.2-9.5 TAPPING SCREW CBLSX D: 4.2-9.5
Chaffoteaux part no. 61010125
£0.42
116   DEFLECTOR
Chaffoteaux part no. 61011642
£5.54
117   MANIFOLD 16 INJ.
Chaffoteaux part no. 61011305
£21.38
117   MANIFOLD 16 INJ.
Chaffoteaux part no. 61011312
£17.47
118 Part number 61010128, TAPPING SCREW CBLSX D: 4.2-25 TAPPING SCREW CBLSX D: 4.2-25
Chaffoteaux part no. 61010128
£0.47
119 Part number 61010131, SCREW HX M 5-12 SCREW HX M 5-12
Chaffoteaux part no. 61010131
£0.42
120 Part number 60057488, SPIRE CLIP SPIRE CLIP
Chaffoteaux part no. 60057488
£0.78
201 Part number 61017600, SCREW CLX M 5-20 SCREW CLX M 5-20
Chaffoteaux part no. 61017600
£1.40
202   FLUE CONNECTION
Chaffoteaux part no. 61306695
£128.04
204 Part number 61310050, VENTURI VENTURI
Chaffoteaux part no. 61310050
£14.46
205 Part number 61303825, GASKET GASKET
Chaffoteaux part no. 61303825
£5.58
206 Part number 61304721, FAN ASSY 1V 30FF FAN ASSY 1V 30FF
Chaffoteaux part no. 61304721
£146.23
212 Part number 61300262, GASKET (TO 03/06) GASKET (TO 03/06)
Chaffoteaux part no. 61300262
£4.90
213 Part number 61306698, PLUG KIT (TO 03/06) PLUG KIT (TO 03/06)
Chaffoteaux part no. 61306698
£8.27
214 Part number 60081265, SILICONE TUBE D: 9x3 L: 1.30M SILICONE TUBE D: 9X3 L: 1.30M
Chaffoteaux part no. 60081265
£9.37
216 Part number 61307335, NOW USE 61307335-01 AIR PRESSURE SWITCH 28KW NOW USE 61307335-01 AIR PRESSURE SWITCH 28KW
Chaffoteaux part no. 61307335

216 Part number 61307335-01, AIR PRESSURE SWITCH 167 Pa AIR PRESSURE SWITCH 167 PA
Chaffoteaux part no. 61307335-01
£45.50
221   HOOD
Chaffoteaux part no. 61304713
£47.75
227 Part number 61010847, TAPPING SCREW CBLSX D:4.2-12.5 TAPPING SCREW CBLSX D:4.2-12.5
Chaffoteaux part no. 61010847
£0.81
230 Part number 61300258, GASKET (/ Flue bend turret) GASKET (/ FLUE BEND TURRET)
Chaffoteaux part no. 61300258
£2.73
303   TOP PANEL BOX
Chaffoteaux part no. 61305438
£21.47
304 Part number 60081273, FOAM SEAL 12.5x5 L: 2.5M FOAM SEAL 12.5X5 L: 2.5M
Chaffoteaux part no. 60081273
£23.36
305   CASE
Chaffoteaux part no. 61010106
£80.41
306 Part number 60079486, TAPPING SCREW CBLZ D: 4.2-13 TAPPING SCREW CBLZ D: 4.2-13
Chaffoteaux part no. 60079486
£0.44
309   BASE - BOX
Chaffoteaux part no. 61010588
£60.80
311   CASE COVER
Chaffoteaux part no. 60081851
£56.39
313 Part number 61003114, TAPPING SCREW CBLZ D: 4.2-19 TAPPING SCREW CBLZ D: 4.2-19
Chaffoteaux part no. 61003114
£0.55
314 Part number 61010109, GROMMET GROMMET
Chaffoteaux part no. 61010109
£3.87
315 Part number 60039017, GROMMET GROMMET
Chaffoteaux part no. 60039017
£1.98
316   GROMMET - DOUBLE
Chaffoteaux part no. 60042707
£2.97
317   DEFLECTOR
Chaffoteaux part no. 61012601
£10.26
318   DEFLECTOR
Chaffoteaux part no. 61012602
£8.00
401   GAS VALVE LPG
Chaffoteaux part no. 61015342
£153.36
401 Part number 61015341, OBSOLETE GAS VALVE NAT OBSOLETE GAS VALVE NAT
Chaffoteaux part no. 61015341

405 Part number 60081835, BURNER BASE KIT BURNER BASE KIT
Chaffoteaux part no. 60081835
£59.71
406 Part number 61010071, GASKET (/Manifold) GASKET (/MANIFOLD)
Chaffoteaux part no. 61010071
£1.86
409   VALVE D: 2.00
Chaffoteaux part no. 61014420-09
£10.82
409   VALVE D: 2.90
Chaffoteaux part no. 61014420-05
£8.98
410 Part number 60081273-04, FOAM SEAL 12x7 L: 5M FOAM SEAL 12X7 L: 5M
Chaffoteaux part no. 60081273-04
£45.08
412   GAS SECTION GASKETS KIT
Chaffoteaux part no. 60081837
£17.87
431   RESTRICTOR
Chaffoteaux part no. 61013017
£9.35
432 Part number 61013018, GASKET (/Solenoid valve) GASKET (/SOLENOID VALVE)
Chaffoteaux part no. 61013018
£2.63
433   O-RING D: 6-1
Chaffoteaux part no. 60021061-36
£0.40
434 Part number 60021061-41, O-RING D: 14.1-1.6 O-RING D: 14.1-1.6
Chaffoteaux part no. 60021061-41
£0.78
435 Part number 60021061-42, O-RING D: 17.1-1.6 O-RING D: 17.1-1.6
Chaffoteaux part no. 60021061-42
£0.44
437   RESTRICTOR D: 6.7
Chaffoteaux part no. 61013016-01
£2.87
438   SCREW CLXS M 5-45
Chaffoteaux part no. 61014414
£1.16
442   SCREW CBLXS M 4-20
Chaffoteaux part no. 61014415
£1.19
445 Part number 60081368, SOLENOID PISTONS KIT SOLENOID PISTONS KIT
Chaffoteaux part no. 60081368
£47.59
449 Part number 61016378, PRESSURE TEST POINT SCREW PRESSURE TEST POINT SCREW
Chaffoteaux part no. 61016378
£0.55
501   HEAT EXCHANGER TUBE
Chaffoteaux part no. 61302004
£14.42
502   CLIP
Chaffoteaux part no. 61010012-02
£0.66
504 Part number 60024164-51, O-RING D: 17-4 O-RING D: 17-4
Chaffoteaux part no. 60024164-51
£1.18
505 Part number 61302410, MOTOR (3-WAY VALVE) MOTOR (3-WAY VALVE)
Chaffoteaux part no. 61302410
£155.00
506 Part number 61002490, PLUG PLUG
Chaffoteaux part no. 61002490
£1.21
507 Part number 60024164-18, O-RING D: 13.6-2.7 O-RING D: 13.6-2.7
Chaffoteaux part no. 60024164-18
£0.44
508 Part number 61016207, PIN PIN
Chaffoteaux part no. 61016207
£1.65
509 Part number 61302411, VALVE VALVE
Chaffoteaux part no. 61302411
£42.62
510 Part number 61000733, THERMISTOR TEMP. SENSOR THERMISTOR TEMP. SENSOR
Chaffoteaux part no. 61000733
£28.04
511 Part number 61002083, TEMPERATURE SENSOR CLIP TEMPERATURE SENSOR CLIP
Chaffoteaux part no. 61002083
£1.08
514 Part number 61302409, NOW USE 61302409-01 WATER / WATER HEAT EXCHANGER 16 NOW USE 61302409-01 WATER / WATER HEAT EXCHANGER 16
Chaffoteaux part no. 61302409

514 Part number 61302409-01, SANITARY HEAT EXCHANGER (16 P.) SANITARY HEAT EXCHANGER (16 P.)
Chaffoteaux part no. 61302409-01
£112.94
516 Part number 61010609, CLIP CLIP
Chaffoteaux part no. 61010609
£0.80
518 Part number 61301956, LEFT HAND HYDRAULIC BLOCK LEFT HAND HYDRAULIC BLOCK
Chaffoteaux part no. 61301956
£17.17
520 Part number 61301998, FLEXIBLE PIPE FLEXIBLE PIPE
Chaffoteaux part no. 61301998
£10.11
521   SCREW CBLXS M 5-12 (TO 03/06)
Chaffoteaux part no. 61301928
£1.40
522 Part number 61010005, CLIP CLIP
Chaffoteaux part no. 61010005
£1.53
523 Part number 60024164-22, O-RING D: 18.4-2.7 O-RING D: 18.4-2.7
Chaffoteaux part no. 60024164-22
£0.47
524 Part number 61009834-49, O-RING D: 15.6-1.78 O-RING D: 15.6-1.78
Chaffoteaux part no. 61009834-49
£1.49
526 Part number 61009834-14, O-RING 8.9X2.7 O-RING 8.9X2.7
Chaffoteaux part no. 61009834-14
£0.50
535 Part number 60081980, PRESSURE RELIEF VALVE KIT PRESSURE RELIEF VALVE KIT
Chaffoteaux part no. 60081980
£64.72
545 Part number 60081977, DIAPHRAGM DIAPHRAGM
Chaffoteaux part no. 60081977
£15.54
546 Part number 60024164-54, O-RING D: 2.9-1.78 O-RING D: 2.9-1.78
Chaffoteaux part no. 60024164-54
£0.46
547 Part number 60037309, GAS FILTER GAS FILTER
Chaffoteaux part no. 60037309

551   GAS TUBE
Chaffoteaux part no. 61302005
£10.80
552 Part number 61301782, DIAPHRAGM DIAPHRAGM
Chaffoteaux part no. 61301782
£7.25
553 Part number 61301924, WATER FILTER WATER FILTER
Chaffoteaux part no. 61301924
£3.03
554 Part number 61003495, PRESSURE SENSOR 0.8 B PRESSURE SENSOR 0.8 B
Chaffoteaux part no. 61003495
£53.16
558 Part number 61306995, PUMP LEAD (2 SPEEDS) PUMP LEAD (2 SPEEDS)
Chaffoteaux part no. 61306995
£15.06
559 Part number 61304618, GASKET KIT GASKET KIT
Chaffoteaux part no. 61304618
£4.09
560 Part number 61304608, AIR SEPARATOR HEAD ASSEMBLY AIR SEPARATOR HEAD ASSEMBLY
Chaffoteaux part no. 61304608
£23.62
561 Part number 61301936, RIGHT HAND HYDRAULIC BLOCK RIGHT HAND HYDRAULIC BLOCK
Chaffoteaux part no. 61301936
£30.73
562 Part number 61016752, PLUG PLUG
Chaffoteaux part no. 61016752
£3.28
563 Part number 61002406, CLIP CLIP
Chaffoteaux part no. 61002406
£1.40
564 Part number 61009834-30, O-RING D: 24.6-3.6 O-RING D: 24.6-3.6
Chaffoteaux part no. 61009834-30
£0.90
567 Part number 60030898-03, CLIP CLIP
Chaffoteaux part no. 60030898-03
£1.00
569 Part number 61002249, LIP SEAL x1 LIP SEAL X1
Chaffoteaux part no. 61002249
£1.88
570 Part number 61305707, TUBE : PUMP TO HEAT EXCHANGER TUBE : PUMP TO HEAT EXCHANGER
Chaffoteaux part no. 61305707
£31.19
571 Part number 61009833-37, O-RING D: 16-1.9 O-RING D: 16-1.9
Chaffoteaux part no. 61009833-37
£0.60
572 Part number 61303461, PUMP + AIR SEPARATOR 15/60 PUMP + AIR SEPARATOR 15/60
Chaffoteaux part no. 61303461
£273.54
572 Part number 61301964, NOW USE 65119656-01 PUMP + AIR SEPARATOR 15/50 NOW USE 65119656-01 PUMP + AIR SEPARATOR 15/50
Chaffoteaux part no. 61301964

572   PUMP HEAD UPMO 60PH
Chaffoteaux part no. 65119656-01
£273.54
573 Part number 61000652-10, CAPACITOR CAPACITOR
Chaffoteaux part no. 61000652-10
£23.72
575 Part number 61301960, BY-PASS BY-PASS
Chaffoteaux part no. 61301960
£6.83
578 Part number 60024164-10, O-RING D: 5.7-1.9 O-RING D: 5.7-1.9
Chaffoteaux part no. 60024164-10
£0.44
583 Part number 61301900, CLIP CLIP
Chaffoteaux part no. 61301900
£1.85
584 Part number 61012886, NUT NUT
Chaffoteaux part no. 61012886
£39.11
585   CLIP
Chaffoteaux part no. 61303463
£1.56
586   OBSOLETE PLUG
Chaffoteaux part no. 61304522

589   NUT M 5
Chaffoteaux part no. 61016604
£1.31
590 Part number 61301904, MICRO SWITCH MICRO SWITCH
Chaffoteaux part no. 61301904
£6.85
592 Part number 61305290, WATER CONTROL 10L/MN WATER CONTROL 10L/MN
Chaffoteaux part no. 61305290
£32.67
593 Part number 60024164-58, O-RING D: 20.1-1.6 O-RING D: 20.1-1.6
Chaffoteaux part no. 60024164-58
£0.58
594 Part number 61017288-10, FLOW REGULATORE 10L/MN (WHITE) FLOW REGULATORE 10L/MN (WHITE)
Chaffoteaux part no. 61017288-10
£3.66
595 Part number 60024164-32, O-RING D: 25-2.4 O-RING D: 25-2.4
Chaffoteaux part no. 60024164-32
£0.65
596   PIN
Chaffoteaux part no. 61308332
£4.54
597 Part number 60081985, GASKETS SET - HYDRAULIC BLOC GASKETS SET - HYDRAULIC BLOC
Chaffoteaux part no. 60081985
£38.45
602 Part number 61020510, SCREW FX90 L:16 SCREW FX90 L:16
Chaffoteaux part no. 61020510
£0.44
605   CONNECTOR
Chaffoteaux part no. 61302101
£3.20
607 Part number 61303159, PRESSURE GAUGE PRESSURE GAUGE
Chaffoteaux part no. 61303159
£28.30
609   CONNECTOR COVER
Chaffoteaux part no. 61302248
£3.64
610   FAN CABLE
Chaffoteaux part no. 61302017
£72.82
611 Part number 61305711, WIRE ASSEMBLY WIRE ASSEMBLY
Chaffoteaux part no. 61305711
£76.21
612 Part number 61002725, CONNECTION STRIP CONNECTION STRIP
Chaffoteaux part no. 61002725
£0.97
613   TAPPING SCREW TCBL D:4 L:10
Chaffoteaux part no. 61020509
£0.42
614 Part number 61302237, BASE - BOX BASE - BOX
Chaffoteaux part no. 61302237
£36.46
615 Part number 61308723, NOW USE 60000571 PRINTED CIRCUIT BOARD NOW USE 60000571 PRINTED CIRCUIT BOARD
Chaffoteaux part no. 61308723

615 Part number 60000571, PRINTED CIRCUIT BOARD PRINTED CIRCUIT BOARD
Chaffoteaux part no. 60000571
£236.80
617   ELECTRICAL BOX COVER
Chaffoteaux part no. 61303266
£11.27
618   PLUG
Chaffoteaux part no. 61011316
£1.07
620 Part number 61009834-10, O-RING 5.7X1.9 O-RING 5.7X1.9
Chaffoteaux part no. 61009834-10
£0.50
621   TRANSMITTER OF LEDS
Chaffoteaux part no. 61302245
£3.18
622 Part number 61302246, IGNITION PUSH ROD IGNITION PUSH ROD
Chaffoteaux part no. 61302246
£1.72
627 Part number 61003456, FUSE 250V 2A FUSE 250V 2A
Chaffoteaux part no. 61003456
£1.20
627 Part number 61003635, FUSE 250V 1.25A - TEMPORISED FUSE 250V 1.25A - TEMPORISED
Chaffoteaux part no. 61003635
£1.20
636 Part number 60081979, KNOBS SET KNOBS SET
Chaffoteaux part no. 60081979
£7.11
637   HOLE PLATE (WITHOUT HOLE)
Chaffoteaux part no. 61303634
£3.35
637   HOLE PLATE (WITH HOLE)
Chaffoteaux part no. 61303633
£3.98
642   BLACK SHUNT
Chaffoteaux part no. 61400030
£1.66
644   CONNECTING TERMINAL
Chaffoteaux part no. 61308032
£2.43
644   NOW USE 61308032 FEEDER
Chaffoteaux part no. 61308031

644   FEEDER
Chaffoteaux part no. 61302102
£8.42
701   TOP STAY PLATE
Chaffoteaux part no. 61010029
£5.69
703 Part number 60056676-06, EXPANSION VESSEL 7L EXPANSION VESSEL 7L
Chaffoteaux part no. 60056676-06
£142.17
704   OBSOLETE CHASSIS
Chaffoteaux part no. 61010028

706   TAPPING SCREW CBLSX D: 6.3-19
Chaffoteaux part no. 61014516
£0.54
709 Part number 60081824, FLEXIBLE PIPE KIT FLEXIBLE PIPE KIT
Chaffoteaux part no. 60081824
£13.38
802   OBSOLETE CASE (FOR PROG.)
Chaffoteaux part no. 61304631

813 Part number 61015797, SPACER SPACER
Chaffoteaux part no. 61015797
£4.03
902 Part number 61303534, WATER FLOW & RETURN SERVI. TAP WATER FLOW & RETURN SERVI. TAP
Chaffoteaux part no. 61303534
£24.56
903   HOT WATE CONNECTION
Chaffoteaux part no. 61303532
£11.50
904   GAS SERVICE TAP
Chaffoteaux part no. 61303533
£23.95
905 Part number 61303535, COLD WATER TAP COLD WATER TAP
Chaffoteaux part no. 61303535
£21.06
906 Part number 61312121, WATER RETURN SERVICE TAP WATER RETURN SERVICE TAP
Chaffoteaux part no. 61312121
£31.31
907   HOOKING BRACKET
Chaffoteaux part no. 61012457
£7.16
908   WASHER D: 14.2-7.2-1.2
Chaffoteaux part no. 60005369-03
£0.41
909   WOOD SCREW
Chaffoteaux part no. 60025617-03
£0.79
921 Part number 60024164-15, O-RING D: 10.5-2.7 O-RING D: 10.5-2.7
Chaffoteaux part no. 60024164-15
£0.44
922   OBSOLETE WASHER 24.0 X 18.2 X 1.5
Chaffoteaux part no. 0022835.01

923   CONNECTION
Chaffoteaux part no. 61301965
£7.97
924   CONNECTION
Chaffoteaux part no. 61302474
£7.85
925   CONNECTION
Chaffoteaux part no. 61303071
£7.88
926 Part number 61302332, PIN PIN
Chaffoteaux part no. 61302332
£2.65
928   HYDRAULIC PLATE
Chaffoteaux part no. 61301793
£4.81
938 Part number 60061855-19, SHEET GASKET D: 24-17-1.5 SHEET GASKET D: 24-17-1.5
Chaffoteaux part no. 60061855-19
£0.69
939 Part number 60039803, WATER FILTER WATER FILTER
Chaffoteaux part no. 60039803
£2.65
940 Part number 60061855-14, WASHER D: 18.4-12.2-1.5 WASHER D: 18.4-12.2-1.5
Chaffoteaux part no. 60061855-14
£0.60
944   OBSOLETE TAP KIT
Chaffoteaux part no. 61312370

945   GASKETS SET
Chaffoteaux part no. 61304273
£7.53
1013   STRAP & SLEEVE D:100 L:75
Chaffoteaux part no. 61310308
£14.91
1014   FLUE DUCT SECOND SECTION
Chaffoteaux part no. 61306700
£27.30
1016   OBSOLETE SEALING RING
Chaffoteaux part no. 0062079.00

1017 Part number 60062181, SLEEVE JOINT SLEEVE JOINT
Chaffoteaux part no. 60062181
£42.57
1023   OBSOLETE VERTICAL ADAPTER
Chaffoteaux part no. 61305982

5020   OBSOLETE SLEEVE
Chaffoteaux part no. 61018789

5030   OBSOLETE ASSEMBLING JIG CALYDRA COMFORT
Chaffoteaux part no. 61309247

5053   D.H.W. EXPANSION VESSEL KIT
Chaffoteaux part no. 61305469
£67.82



Heating spares made simple this website is secured by Geotrust
