CHAFFOTEAUX
CHALLENGER 50 OF - (Burner)
Appliance Code: 41-980-76

Appliance Diagram


Burner diagram for Chaffoteaux Challenger 50 OfClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

101   OBSOLETE CHASSIS CHALLENGER 30-50 OF
Chaffoteaux part no. 60063443-06

102   OBSOLETE NUT
Chaffoteaux part no. 0047509.00

103   OBSOLETE OLIVE 22MM
Chaffoteaux part no. 0047508.00

104   OBSOLETE LOCK NUT
Chaffoteaux part no. 60049269

105   OBSOLETE FLOW AND RETURN CONNECTIONS
Chaffoteaux part no. 0066833.08

106 Part number 60061855-01, SHEET GASKET D: 24-18.2-1.5 SHEET GASKET D: 24-18.2-1.5
Chaffoteaux part no. 60061855-01
£0.79
107   OBSOLETE WALL MOUNTING BRACKET
Chaffoteaux part no. 0021720.10

108   WOOD SCREW
Chaffoteaux part no. 60025617-03
£0.79
109   WASHER D: 14.2-7.2-1.2
Chaffoteaux part no. 60005369-03
£0.41
111 Part number 61010648, TAPPING SCREW CBLSX D: 6.3-13 TAPPING SCREW CBLSX D: 6.3-13
Chaffoteaux part no. 61010648
£0.44
112 Part number 60004806-03, TRAPPED NUT M 6 TRAPPED NUT M 6
Chaffoteaux part no. 60004806-03
£0.53
113   OBSOLETE CABLE CLAMP
Chaffoteaux part no. 60027834

114 Part number 60037309, GAS FILTER GAS FILTER
Chaffoteaux part no. 60037309

115 Part number 60081288, GAS SERVICE TAP KIT GAS SERVICE TAP KIT
Chaffoteaux part no. 60081288
£93.40
116   OBSOLETE GRILL
Chaffoteaux part no. 0070343.00

117   SPIRE CLIP
Chaffoteaux part no. 60063603
£1.08
118   OBSOLETE NUT H M 6-1
Chaffoteaux part no. 60009521-03

119 Part number 60013183-03, STAR WASHER D: 6 STAR WASHER D: 6
Chaffoteaux part no. 60013183-03
£0.44
120 Part number 60005799-13, SCREW HS M 6-12 SCREW HS M 6-12
Chaffoteaux part no. 60005799-13
£0.55
121   SCREW
Chaffoteaux part no. 60069622
£0.30
202   OBSOLETE COMBUSTION LINING
Chaffoteaux part no. 0081380.00

203   OBSOLETE COMBUSTION CHAMBER ASSY
Chaffoteaux part no. 60063221

204 Part number 61010125, TAPPING SCREW CBLSX D: 4.2-9.5 TAPPING SCREW CBLSX D: 4.2-9.5
Chaffoteaux part no. 61010125
£0.42
205   OBSOLETE
Chaffoteaux part no. 0032308.00

206 Part number 60024164-05, O-RING D: 3.4-1.9 O-RING D: 3.4-1.9
Chaffoteaux part no. 60024164-05
£0.42
302   OBSOLETE FLUE ADAPTER
Chaffoteaux part no. 0064088.00

303   OBSOLETE TAPPING SCREW CBLZ D: 4.8-9.5
Chaffoteaux part no. 60039551-03

501   OBSOLETE GAS SECTION ASSY - CHALLENGER
Chaffoteaux part no. 0063343.00

502 Part number 60081267, SOLENOID VALVES KIT SOLENOID VALVES KIT
Chaffoteaux part no. 60081267
£60.51
504   OBSOLETE BURNER BASE KIT
Chaffoteaux part no. 60081386

505   ADJUSTING SCREW KIT
Chaffoteaux part no. 60081009
£9.34
506 Part number 60081032, GAS SECTION GASKETS KIT GAS SECTION GASKETS KIT
Chaffoteaux part no. 60081032
£13.17
507   PILOT KIT
Chaffoteaux part no. 60081383
£38.31
508 Part number 60065964, THERMOCOUPLE THERMOCOUPLE
Chaffoteaux part no. 60065964
£67.01
509 Part number 60034346, THERMO-ELECTRIC VALVE THERMO-ELECTRIC VALVE
Chaffoteaux part no. 60034346
£12.80
510   NUT M 24-1
Chaffoteaux part no. 60060351
£3.92
511   ELECTRODE & LEAD ASSY
Chaffoteaux part no. 60063404
£9.93
512 Part number 60024184-06, O-RING D: 3.4-1.9 O-RING D: 3.4-1.9
Chaffoteaux part no. 60024184-06
£0.66
513 Part number 60026646, PILOT INJECTOR D: 0.3 PILOT INJECTOR D: 0.3
Chaffoteaux part no. 60026646
£7.83
514   PRESSURE TEST POINT SCREW
Chaffoteaux part no. 60019445
£1.24
515   IGNITION PUSH ROD KIT
Chaffoteaux part no. 60081187
£155.01
518   FLAME SUPERVISION KIT
Chaffoteaux part no. 60081619
£50.07
519   OVERHEAT THERMOSTAT 105C
Chaffoteaux part no. 60065962
£83.49
520 Part number 61010131, SCREW HX M 5-12 SCREW HX M 5-12
Chaffoteaux part no. 61010131
£0.42
523   SCREW M 3-20
Chaffoteaux part no. 60065454
£0.70
524   OBSOLETE GAS INLET BEND OF
Chaffoteaux part no. 0065587.08

526 Part number 60031527-03, SCREW M 6-10 SCREW M 6-10
Chaffoteaux part no. 60031527-03
£0.74
528   OBSOLETE SPLIT GROMMET
Chaffoteaux part no. 0062939.00

529   PILOT PROTECTION
Chaffoteaux part no. 60069200
£3.06
530 Part number 60063402, RETAINING PLATE RETAINING PLATE
Chaffoteaux part no. 60063402
£2.46
531 Part number 60063866, PLATE CLAMP PLATE CLAMP
Chaffoteaux part no. 60063866
£2.09
532 Part number 60075010, SCREW M 3-8 SCREW M 3-8
Chaffoteaux part no. 60075010
£0.47
534 Part number 60057750, SCREW CBLZ M 4-8 SCREW CBLZ M 4-8
Chaffoteaux part no. 60057750
£0.42
601   OBSOLETE BURNER HEAD ASSY 50 OF
Chaffoteaux part no. 0066308.00

701   OBSOLETE MANIFOLD ASSY
Chaffoteaux part no. 0066323.00

702   GASKET (/BASE)
Chaffoteaux part no. 60069802
£1.49
703   NOW USE 60037227-03 SPRING WASHER
Chaffoteaux part no. 0037227.03

703   SPRING WASHER D: 5
Chaffoteaux part no. 60037227-03
£0.87
704 Part number 61010128, TAPPING SCREW CBLSX D: 4.2-25 TAPPING SCREW CBLSX D: 4.2-25
Chaffoteaux part no. 61010128
£0.47
801   OBSOLETE ELECTRICAL BOX ASSEMBLY
Chaffoteaux part no. 60066007

802   GROMMET
Chaffoteaux part no. 60064089
£0.85
803   COVER
Chaffoteaux part no. 60063385
£6.95
804   PRINTED CIRCUIT BOARD
Chaffoteaux part no. 60063176
£258.50
805   OBSOLETE EARTH CABLE ASSY
Chaffoteaux part no. 0064746.00

807   OBSOLETE IGNITION MICROSWITCH CABLE
Chaffoteaux part no. 60064747

808   OBSOLETE LEAD
Chaffoteaux part no. 60064748

809   OBSOLETE CABLE ASSY
Chaffoteaux part no. 0064749.00

810   SCREW HS M 6-25
Chaffoteaux part no. 60010942-13
£1.43
820 Part number 60045234, FUSE 220V 630mA FUSE 220V 630MA
Chaffoteaux part no. 60045234
£2.11
822   GROMMET
Chaffoteaux part no. 60027838
£0.75
824 Part number 60064153, THERMISTOR TEMPERATURE SENSOR THERMISTOR TEMPERATURE SENSOR
Chaffoteaux part no. 60064153
£16.22
825   NUT M 14-0.75
Chaffoteaux part no. 60064552
£2.87
901   OBSOLETE FRONT CASE
Chaffoteaux part no. 0063383.06

903   OBSOLETE SCREW M6 X 20 WASTE OUT
Chaffoteaux part no. 0065622.01

906   HINGE REPAIR KIT
Chaffoteaux part no. 60081570
£39.71
907   OBSOLETE DOOR ASSY 50 OF
Chaffoteaux part no. 0064148.00

908   KNOBS SET
Chaffoteaux part no. 60081381
£3.51
