FERROLI
DOMINA 80 N (05-01) - (Gas Line)
Appliance Code: 47-267-27

Appliance Diagram


Gas Line diagram for Ferroli Domina 80 N (05-01)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

4 Part number 37402710, COMBUSTION CHAMBER COMBUSTION CHAMBER
Ferroli part no. 37402710		 £43.30
6   PANEL - ROOM SEALED
Ferroli part no. 39804840		 £57.57
10   ROOM SEALED COMPARTMENT
Ferroli part no. 32118250		 £47.02
11 Part number 39811330, SIGHT GLASS - C/W SEAL SIGHT GLASS - C/W SEAL
Ferroli part no. 39811330		 £8.42
12 Part number 39806950, BURNER - MAIN MF03-MF03.1 (12 HEAD) BURNER - MAIN MF03-MF03.1 (12 HEAD)
Ferroli part no. 39806950		 £94.60
16   INJECTOR - MAIN (0.77-LPG)
Ferroli part no. 34009651		 £1.42
16 Part number 39805760, INJECTOR KIT (12) - MAIN 1.30 (NG) INJECTOR KIT (12) - MAIN 1.30 (NG)
Ferroli part no. 39805760		 £10.55
26 Part number 35006150, NOW USE 39838830 PLUG - (12mm) NOW USE 39838830 PLUG - (12MM)
Ferroli part no. 35006150
26 Part number 39838830, PLUG - (12mm) PLUG - (12MM)
Ferroli part no. 39838830		 £10.93
36 Part number 35101150, FROLI 35101150 AIR PRESSURE TEST POINT FROLI 35101150 AIR PRESSURE TEST POINT
Ferroli part no. 35101150
37 Part number 39805600, NOW USE 39809790 TEST POINT - FAN NOW USE 39809790 TEST POINT - FAN
Ferroli part no. 39805600
37 Part number 39809790, VENTURI - KIT (SHORT) c/w TEST POINT VENTURI - KIT (SHORT) C/W TEST POINT
Ferroli part no. 39809790		 £5.66
38 Part number 39805611, VENTURI - FAN ASSEMBLY (LONG) VENTURI - FAN ASSEMBLY (LONG)
Ferroli part no. 39805611		 £4.42
39 Part number 35101430, NOW USE 39820930 TEST POINT - SMOKE HOOD NOW USE 39820930 TEST POINT - SMOKE HOOD
Ferroli part no. 35101430
39   TEST POINT - SMOKE HOOD
Ferroli part no. 39820930		 £6.18
41   GASKET - GAS VALVE FLANGE E50
Ferroli part no. 35101560		 £0.82
42 Part number 39820620, GASKET KIT - (5) ROOM SEALED GASKET KIT - (5) ROOM SEALED
Ferroli part no. 39820620		 £42.68
44   NOW USE 39821970 SIGHT GLASS - 50MM X 30MM X 3.3MM
Ferroli part no. 35315250
44   SIGHT GLASS - 50MM X 30MM X 3.3MM
Ferroli part no. 39821970		 £16.13
45 Part number 39804950, INSULATION KIT - MODENA 80E / FERROLI F24E/D INSULATION KIT - MODENA 80E / FERROLI F24E/D
Ferroli part no. 39804950		 £31.86
45 Part number 35320590, NOW USE 39804950 INSULATION - SIDE NOW USE 39804950 INSULATION - SIDE
Ferroli part no. 35320590
46 Part number 35321320, NOW USE 39804950 INSULATION - REAR NOW USE 39804950 INSULATION - REAR
Ferroli part no. 35321320
46 Part number 39804950, INSULATION KIT - MODENA 80E / FERROLI F24E/D INSULATION KIT - MODENA 80E / FERROLI F24E/D
Ferroli part no. 39804950		 £31.86
50 Part number 39805631, AIR PRESSURE SWITCH AIR PRESSURE SWITCH
Ferroli part no. 39805631		 £42.20
50 Part number 39805630, NOW USE 39805631 AIR PRESSURE SWITCH NOW USE 39805631 AIR PRESSURE SWITCH
Ferroli part no. 39805630
58   TUBE - SILICONE (230MM X 4MM) CLEAR
Ferroli part no. 36506220		 £3.52
63 Part number 39806880, FAN ASSEMBLY - 24Kw TP FAN ASSEMBLY - 24KW TP
Ferroli part no. 39806880		 £210.41
65 Part number 39805670, ELECTRODE - FLAME SENSING ELECTRODE - FLAME SENSING
Ferroli part no. 39805670		 £5.91
66 Part number 39807470, ELECTRODE - IGNITION ELECTRODE - IGNITION
Ferroli part no. 39807470		 £6.75
68 Part number 39808000, GAS VALVE - ( VK4105G ) GAS VALVE - ( VK4105G )
Ferroli part no. 39808000		 £224.21
70 Part number 39804900, PANEL - COMBUSTION CHAMBER PANEL - COMBUSTION CHAMBER
Ferroli part no. 39804900		 £25.57
72 Part number 37515140, NOW USE 39830540 SMOKE BOX NOW USE 39830540 SMOKE BOX
Ferroli part no. 37515140
72 Part number 39830540, SMOKE BOX SMOKE BOX
Ferroli part no. 39830540		 £114.10
74   MANIFOLD - (12 HEAD)
Ferroli part no. 38408990		 £35.77
78   PIPE - GAS VALVE TO MANIFOLD
Ferroli part no. 38414160		 £7.32
