GLOWWORM
COORDINATE GL FIRE ONLY 1986 AVA - (Appliance Overview)
Appliance Code: 37-315-04

Appliance Diagram


Appliance Overview diagram for Glowworm Coordinate GL Fire Only 1986 AVAClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE USER INSTR- 81BKDPA4135/AGW21
Glowworm part no. 206646
1   OBSOLETE FITTER INSTR161BKDPA4115/AGW21
Glowworm part no. 206645
1   OBSOLETE CASING ASSY - SPARES CO-G
Glowworm part no. 427572
2   OBSOLETE HEAT EXCHANGER
Glowworm part no. 2000800763
3   OBSOLETE AIR GUIDE FNT ANG(NPF)G5GLSGLG
Glowworm part no. 421528
4   SCREW -M5X10MM
Glowworm part no. SK6214		 £6.23
5 Part number SK6219, Nut NUT
Glowworm part no. SK6219		 £6.23
6   RADIANT SPACER (NPF) CTGLG+
Glowworm part no. 423011
6   RADIANT SPACER
Glowworm part no. S423011
7 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330		 £6.23
8   H/E FRONT TRIM (DE-BURR)CTGLG+
Glowworm part no. 423071
8   FRONT TRIM-HEAT EXCHANGER
Glowworm part no. S423071
9   OBSOLETE BURNER ALTERNATIVES
Glowworm part no. 900604
10 Part number 203626, OBSOLETE G/TAP WITH ELBOW-JC/A/856 OBSOLETE G/TAP WITH ELBOW-JC/A/856
Glowworm part no. 203626
11   OBSOLETE PIEZO UNIT-SPARE-JC/SA/1963 QC
Glowworm part no. 202708
12   NUT - LOCK M15
Glowworm part no. SK8833
13   OBSOLETE INJECTOR-BRAY 16 130
Glowworm part no. 203032
14 Part number 203058, OBSOLETE INJECTOR-BRAY 28 240 OBSOLETE INJECTOR-BRAY 28 240
Glowworm part no. 203058
15   ELECTRODE
Glowworm part no. 202607
15 Part number S202607, ELECTRODE ELECTRODE
Glowworm part no. S202607
16 Part number SK6361, Shake proof washer (M4) SHAKE PROOF WASHER (M4)
Glowworm part no. SK6361		 £6.23
17 Part number SK6218, Nut - M4 NUT - M4
Glowworm part no. SK6218		 £6.23
18 Part number SWW4613, Ignition lead IGNITION LEAD
Glowworm part no. SWW4613
19   OBSOLETE CLIP-IGNITION LEAD
Glowworm part no. 208289
20   SILENCER ASSY--PH CTGLG+
Glowworm part no. 423029
20   SILENCER
Glowworm part no. S423029
21   SCREW ( M4X16MM )
Glowworm part no. S208283		 £6.23
21   NOW USE S208283 SCREW-M4X16MM+5DG MS PN
Glowworm part no. 208283
22   OBSOLETE REAR PANEL ASSY-PNTD GLSGLG+
Glowworm part no. 427026
23   OBSOLETE CONNECTING ROD
Glowworm part no. 204711
24 Part number SK5148, Split pin -3/32 dia X 3/4 SPLIT PIN -3/32 DIA X 3/4
Glowworm part no. SK5148
25   OBSOLETE BEZEL
Glowworm part no. 204628
26   NOW USE S208377 SCREW-NO.6 X 1/2 REC
Glowworm part no. 208377
26   SCREW ( NO.6 X 1/2 )
Glowworm part no. S208377		 £5.58
27   WASHER - SEAL 1/2X3/16X1/16
Glowworm part no. S69953
27   WASHER-SEAL 1/2X3/16X1/16 BSW
Glowworm part no. 69953
28   OBSOLETE CASING TOP TRIM (DE-BURR) GLG+
Glowworm part no. 427509
29   SCREW (NO 8X1/2)
Glowworm part no. SK7688
30   OBSOLETE CONV APERT ASSY-PNTD
Glowworm part no. 427612
31   OBSOLETE FRONT PANEL ASSY-SPARE
Glowworm part no. 427540
32 Part number SFF0652, Screw, no6 x 3/8 SCREW, NO6 X 3/8
Glowworm part no. SFF0652		 £6.23
33 Part number SK6296, Washer WASHER
Glowworm part no. SK6296
35 Part number SK6262, Shake proof washer (M5) SHAKE PROOF WASHER (M5)
Glowworm part no. SK6262		 £6.23
37   OBSOLETE REAR SURR TOP ASSY--PH GL
Glowworm part no. 427525
38   CASING LOCATION BRKT(PCF) GLG+
Glowworm part no. 427526
38   CASING LOCATION BRACKET
Glowworm part no. S427526
39   LOUVRE ASSEMBLY-REAR SIDE
Glowworm part no. S427025
39   RR SIDE LOUVRE ASY-PNTD GLSGLG
Glowworm part no. 427025
40   PLINTH GUIDE (NPF) GLSGLG
Glowworm part no. 427528
40   PLINTH GUIDE
Glowworm part no. S427528
41 Part number 427503, PLINTH ASSY--PH GLG PLINTH ASSY--PH GLG
Glowworm part no. 427503
42 Part number 2000801477, DRESS GUARD DRESS GUARD
Glowworm part no. 2000801477
42 Part number 427504, DRESS GUARD DRESS GUARD
Glowworm part no. 427504
43 Part number 203746, NOW USE S203746 RADIANT PACK(203701 PACKED) NOW USE S203746 RADIANT PACK(203701 PACKED)
Glowworm part no. 203746
43 Part number S203746, Radiant pack RADIANT PACK
Glowworm part no. S203746		 £65.66
44   OBSOLETE FLUE SPIGOT ASY (SW) GLSGLG
Glowworm part no. 427024
46 Part number 427524, CONTROL KNOB ASSY CONTROL KNOB ASSY
Glowworm part no. 427524
46 Part number S427524, Control knob CONTROL KNOB
Glowworm part no. S427524
47   CLIP
Glowworm part no. S204631
47   CLIP-CTRL KNOB-TRW 17020-07
Glowworm part no. 204631
48   OLIVE - 3/8 DIA
Glowworm part no. SK4740
49   UNION NUT 3/8 BSPF
Glowworm part no. S12248
49   UNION NUT 3/8 BSPF
Glowworm part no. 12248
50 Part number 800099, OBSOLETE SUPPLY TUBE SPARE CO-G GL&MET OBSOLETE SUPPLY TUBE SPARE CO-G GL&MET
Glowworm part no. 800099
51   OBSOLETE WASHER-1/4 X1 MS PLAIN
Glowworm part no. 208375
51   OBSOLETE WASHER-1/4 X1 MS PLAIN
Glowworm part no. S208375
52   OBSOLETE SCREW-M5X10MM+5DG MS PN
Glowworm part no. 208245
53   OBSOLETE KNOB ASSY-H/CAPPED PERSON
Glowworm part no. 409280
54   INSUL-CASING BOARD
Glowworm part no. 411932
54   INSULATION - CASING BOARD
Glowworm part no. S411932
55   OBSOLETE INSTA INSTR 201BKDPA4115/AGW21
Glowworm part no. 206865
56   OBSOLETE USER INSTR- 41BKDPA4115/AGW21
Glowworm part no. 206866
57   OBSOLETE LABEL-LIGHTG INSTRUCTION-MACLAREN
Glowworm part no. 211307
58   OBSOLETE LABEL-LIGHTG INSTRUCTION-SIT
Glowworm part no. 211313
59   OBSOLETE INLET SUPPLY TUBE ASSY(F)
Glowworm part no. 432301
60   OBSOLETE COMB CHAMB EXTENSION ASSY
Glowworm part no. 432302
61   OBSOLETE FITTINGS PACK-BBU ADAPTER KIT
Glowworm part no. 432305
62   OBSOLETE DRAUGHT DIVE FRONT ASSY
Glowworm part no. 432306
63   OBSOLETE D/DIV RR BAFFLE ASSY(SW) GLGAD
Glowworm part no. 432311
64   OBSOLETE PLINTH ASSY - 246 ADAPTER KIT
Glowworm part no. 432315
65   OBSOLETE SEAL PACK-BBU ADAPTER KIT
Glowworm part no. 432321
120   OBSOLETE THERMOCOUPLE-ORKLI TIEZ-500
Glowworm part no. 202436
120   OBSOLETE THERMOCOUPLE
Glowworm part no. S900002
121   OBSOLETE ELECTRODE - REF BE/3467/SI
Glowworm part no. 202630
122   OBSOLETE G/TAP C/W ELBOW-REF:TE.SA.2258
Glowworm part no. 203652
123   OBSOLETE BEZEL - PRINTED CO-ORD GL
Glowworm part no. 427543
124 Part number 204718, CONNECTING ROD CONNECTING ROD
Glowworm part no. 204718
124 Part number S204718, CONNECTING ROD CONNECTING ROD
Glowworm part no. S204718
125   OBSOLETE BURNER - ALTERNATIVES
Glowworm part no. 900605
127 Part number 2000800713, Supply tube with nuts & olives SUPPLY TUBE WITH NUTS & OLIVES
Glowworm part no. 2000800713
128   OBSOLETE INSTA INSTR-201BKDPA4115\AGW21
Glowworm part no. 220536
128   OBSOLETE USER INSTR- 81BKDPA4135\AGW21
Glowworm part no. 220541
129   OBSOLETE SPARES-AIR GUIDE + FEET (NEW)
Glowworm part no. 2000800716
