HEATLINE
S 30 COMPACT 2002-2007 - (05 Burner)
Appliance Code: 47-157-03

Appliance Diagram


05 Burner diagram for Heatline S 30 Compact 2002-2007Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

20   BURNER 30 KW (15 BLADES)
Glowworm part no. D001010003
£194.64
21   LPG KIT (0.76 MM INJECTOR FOR S24/S30)
Glowworm part no. D001060004
£29.23
21   NG KIT (1.20 MM INJECTOR FOR S30)
Glowworm part no. D001060094
£38.12
22   MANIFOLD - BURNER (30 KW)
Glowworm part no. D001050003
£76.24
23 Part number D003200033, Ignition Electrode - Right IGNITION ELECTRODE - RIGHT
Glowworm part no. D003200033
£14.95
24 Part number D003200034, Ignition Electrode - Left IGNITION ELECTRODE - LEFT
Glowworm part no. D003200034
£14.95
25 Part number D003200035, Ionisation Electrode IONISATION ELECTRODE
Glowworm part no. D003200035
£46.57
26   SCREW 3.9 X 13 MM (PK10)
Glowworm part no. D003200057
£6.03
27   SCREW M 5 X 10 MM (PK10)
Glowworm part no. D003200198
£6.03
28   SCREW 3.9 X 9.5 MM (PK10)
Glowworm part no. D002006877
£5.41
