IDEAL
+C30 - (Gas Management)
Appliance Code: 47-348-86

Appliance Diagram


Gas Management diagram for Ideal +C30Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

204 Part number 175561, PIPE - GAS INLET (AAV & AAB ONLY) PIPE - GAS INLET (AAV & AAB ONLY)
Ideal part no. 175561		 £20.74
204 Part number 177543, PIPE GAS INLET (ABS & ABY ONWARDS) PIPE GAS INLET (ABS & ABY ONWARDS)
Ideal part no. 177543		 £27.87
205 Part number 175562, GAS VALVE KIT (PRE ABS) GAS VALVE KIT (PRE ABS)
Ideal part no. 175562		 £191.43
205 Part number 176590, GAS VALVE KIT (LPG) (PRE ABK - BRASS WATERSET) GAS VALVE KIT (LPG) (PRE ABK - BRASS WATERSET)
Ideal part no. 176590		 £121.08
205 Part number 177544, GAS VALVE KIT (ABS & ABY ONWARDS) GAS VALVE KIT (ABS & ABY ONWARDS)
Ideal part no. 177544		 £107.86
205 Part number 177582, GAS VALVE KIT (LPG) (ABK ONWARDS) GAS VALVE KIT (LPG) (ABK ONWARDS)
Ideal part no. 177582		 £127.13
206 Part number 175563, PIPE - GAS INJECTOR (AAC & AAB ONLY) PIPE - GAS INJECTOR (AAC & AAB ONLY)
Ideal part no. 175563		 £14.82
206 Part number 177545, PIPE GAS INJECTOR (ABS & ABY ONWARDS) PIPE GAS INJECTOR (ABS & ABY ONWARDS)
Ideal part no. 177545		 £17.33
208 Part number 175611, INJECTOR 30KW INJECTOR 30KW
Ideal part no. 175611		 £26.55
211 Part number 175613, INJECTOR ASSEMBLY KIT 30KW (AAC ONLY) INJECTOR ASSEMBLY KIT 30KW (AAC ONLY)
Ideal part no. 175613		 £28.67
211 Part number 176591, INJECTOR & HOUSING KIT (LPG) INJECTOR & HOUSING KIT (LPG)
Ideal part no. 176591		 £29.62
211 Part number 177547, INJECTOR ASSEMBLY KIT 30KW (NG) (ABS ONWARDS) INJECTOR ASSEMBLY KIT 30KW (NG) (ABS ONWARDS)
Ideal part no. 177547		 £29.22
211 Part number 177549, INJECTOR & HOUSING KIT (LPG) INJECTOR & HOUSING KIT (LPG)
Ideal part no. 177549		 £28.76
214 Part number 175567, VENTURI VENTURI
Ideal part no. 175567		 £23.98
215 Part number 175569, FAN KIT FAN KIT
Ideal part no. 175569		 £159.75
216 Part number 175570, GASKET - FAN GASKET - FAN
Ideal part no. 175570		 £17.27
217 Part number 175571, BURNER KIT BURNER KIT
Ideal part no. 175571		 £103.04
221 Part number 175896, SUMP KIT XN, XO ONWARDS SUMP KIT XN, XO ONWARDS
Ideal part no. 175896		 £53.03
223 Part number 175576, FLUE MANIFOLD FLUE MANIFOLD
Ideal part no. 175576		 £36.96
224 Part number 175578, FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ) FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175578		 £38.93
224 Part number 176986, FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 176986		 £40.89
227 Part number 175581, CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ) CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175581		 £7.87
227 Part number 175983, CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 175983		 £6.68
228 Part number 175582, HOSE - CONDENSATE INTERNAL HOSE - CONDENSATE INTERNAL
Ideal part no. 175582		 £8.95
231 Part number 175586, CONDENSATE OUTLET CONNECTION CONDENSATE OUTLET CONNECTION
Ideal part no. 175586		 £7.28
