IDEAL
CLASSIC COMBI 280 - (Burner Control Ass 2)
Appliance Code: 47-415-08

Appliance Diagram


Burner Control Ass 2 diagram for Ideal Classic Combi 280Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE CTRL CSG POD ASSY COMBI 280
Ideal part no. 075238
0 Part number 079662, MANIFOLD GASKET SET MANIFOLD GASKET SET
Ideal part no. 079662		 £19.03
0   OBSOLETE GAS COCK ASSY CLASSIC NF/RS
Ideal part no. 079946
0   OBSOLETE AIR DUCT SLG PLT AS PTD CL2
Ideal part no. 110886
0   AIR DUCT SLG PLT GASKET CL2
Ideal part no. 110887		 £3.17
0   OBSOLETE NIPPLE
Ideal part no. 113053
2   OBSOLETE INTERPANEL ASS:COMBI
Ideal part no. 005819
3   OBSOLETE FLUEWAY BAFFLES
Ideal part no. 079597
4   OBSOLETE HOOK BOLTS C/W FIXINGS 50/80NF
Ideal part no. 079583
5   OBSOLETE R H FLOW PIPE CLASSIC NF
Ideal part no. 137463
6   OBSOLETE RETURN PIPE ASS CLASSIC 80NF
Ideal part no. 137468
7   OBSOLETE COLL HD ASS NF270/280 CLASS
Ideal part no. 111965
8 Part number 111962, OBSOLETE COMB CHBR ASS NF270/280 RS260 OBSOLETE COMB CHBR ASS NF270/280 RS260
Ideal part no. 111962
9   OBSOLETE COMB CHAM INSUL CLASSIC RS 60
Ideal part no. 079935
10   OBSOLETE SIGHT GLASS ASSY - BNR BOX
Ideal part no. 079333
11 Part number 111075, GAS VALVE VR4601PA2020 COMBI280 GAS VALVE VR4601PA2020 COMBI280
Ideal part no. 111075		 £369.46
12   OBSOLETE GAS M/FOLD ASSY CLASSIC 2 RS/NF
Ideal part no. 079588
13   OBSOLETE BNR AEROMATIC NF270/280 RS260
Ideal part no. 111709
14   OBSOLETE AIR BOX C/W GSKT RS/NF CLASSIC
Ideal part no. 079589
15   OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 2400
Ideal part no. 004444
16 Part number 004982, NOW USE 171434 INJECTOR PILOT 45900421-002 56/42A NOW USE 171434 INJECTOR PILOT 45900421-002 56/42A
Ideal part no. 004982
16 Part number 171434, PILOT BURNER INJECTOR CLA FF30-80 PILOT BURNER INJECTOR CLA FF30-80
Ideal part no. 171434		 £12.01
17   OBSOLETE P/BNR HEAD Q359A1124 NF CL/SIC
Ideal part no. 079599
18 Part number 137330, PILOT SHIELD CLASSIC/ELAN PILOT SHIELD CLASSIC/ELAN
Ideal part no. 137330
19 Part number 111881, IGN/DETN ELECTRODE AND LEAD CL2 NOW USE 171442 IGN/DETN ELECTRODE AND LEAD CL2 NOW USE 171442
Ideal part no. 111881
19 Part number 171442, IGNITION ELECTRODE KIT CLA FF IGNITION ELECTRODE KIT CLA FF
Ideal part no. 171442		 £26.01
20   OBSOLETE CTRL BOX ASS:COMBI 280
Ideal part no. 112221
21   OBSOLETE ROTARY ON/OFF SWITCH:COMBI
Ideal part no. 005823
22 Part number 079601, NOW USE 171504 T/STAT KNOB ASSY CLASSIC NOW USE 171504 T/STAT KNOB ASSY CLASSIC
Ideal part no. 079601
22 Part number 171504, POTENTIOMETER KNOB & CAP KIT CLA FF POTENTIOMETER KNOB & CAP KIT CLA FF
Ideal part no. 171504		 £7.89
23   OBSOLETE GAS VALVE PLUG+LEAD ASSY CL2
Ideal part no. 112292
24   MAINS SOCKET-BULGIN PX0580/63
Ideal part no. 004555		 £2.97
25 Part number 079716, NOW USE PART NO 173799 PCB 25D BOARD NOW USE PART NO 173799 PCB 25D BOARD
Ideal part no. 079716
25 Part number 173799, PCB 25E PCB 25E
Ideal part no. 173799		 £156.84
26 Part number 112686, PRESS SWITCH ASSEMBLY COMBI 280 PRESS SWITCH ASSEMBLY COMBI 280
Ideal part no. 112686		 £31.24
27 Part number 111947, FAN ASSY NF200 CLASSIC FAN ASSY NF200 CLASSIC
Ideal part no. 111947		 £212.48
28   OBSOLETE FAN HARNESS CLASSIC NF/EL2-2
Ideal part no. 137660
29 Part number 113116, 3/8 IN AUTO AIR VENT 3/8 IN AUTO AIR VENT
Ideal part no. 113116		 £28.18
30 Part number 113089, PRESSURE GAUGE PRESSURE GAUGE
Ideal part no. 113089		 £96.94
31   OBSOLETE UM/WINT SWITCH HRNS COMBI 280
Ideal part no. 112622
32 Part number 079635, OBSOLETE T/STAT PRE HT ASSY COMBI OBSOLETE T/STAT PRE HT ASSY COMBI
Ideal part no. 079635		 £12.34
33 Part number 079634, OBSOLETE T/STAT H/STAT ASSY COMBI OBSOLETE T/STAT H/STAT ASSY COMBI
Ideal part no. 079634
34 Part number 079636, OBSOLETE T/STAT D.H.W ASSY COMBI OBSOLETE T/STAT D.H.W ASSY COMBI
Ideal part no. 079636		 £12.34
35 Part number 075248, 1/2IN SAFETY VALVE ASSY ALTECNI 1/2IN SAFETY VALVE ASSY ALTECNI
Ideal part no. 075248		 £33.87
36   OBSOLETE COMBI 280 MODULE CVR ASSY
Ideal part no. 079637
37   OBSOLETE PUMP INLET PIPE ASS COMBI
Ideal part no. 005593
38 Part number 137662, T/STAT POCKET CLASSIC T/STAT POCKET CLASSIC
Ideal part no. 137662		 £42.75
39 Part number 070000, DHW CALORIFIER W/WASH COMBI DHW CALORIFIER W/WASH COMBI
Ideal part no. 070000		 £191.86
40   OBSOLETE DHW FLOW PIPE ASS COMBI
Ideal part no. 005604
41 Part number 005713, FLEXIBLE HOSE COMBI FLEXIBLE HOSE COMBI
Ideal part no. 005713		 £25.03
42   OBSOLETE DIV VALVE INLET PIPE ASS COMBI
Ideal part no. 005598
43   OBSOLETE SAFETY VALVE OUTLET PIPE COMBI
Ideal part no. 005705
44   OBSOLETE FLOW SWITCH INLET PIPE ASS COMBI
Ideal part no. 005601
45 Part number 005856, OBSOLETE FLOW SWITCH S/ASS COMBI OBSOLETE FLOW SWITCH S/ASS COMBI
Ideal part no. 005856		 £122.13
46   OBSOLETE 5M DW CIRCULATING PUMP COMPLETE
Ideal part no. 171865
47   OBSOLETE PUMP O/LET PIPE ASS COMBI
Ideal part no. 005595
48 Part number 005871, OBSOLETE DIVERTER VALVE S/ASS:COMBI OBSOLETE DIVERTER VALVE S/ASS:COMBI
Ideal part no. 005871
49   OBSOLETE DIV VALVE O/LET PIPE ASS COMBI
Ideal part no. 005599
50 Part number 005803, OBSOLETE WAX STAT ASS PTD COMBI OBSOLETE WAX STAT ASS PTD COMBI
Ideal part no. 005803		 £91.44
51 Part number 113205, EXPANSION VESSEL 8 LTR S/S KIT EXPANSION VESSEL 8 LTR S/S KIT
Ideal part no. 113205		 £102.25
52   OBSOLETE DOM HOT WATER STRAINER GASCON
Ideal part no. 005810
53   OBSOLETE BOILER CASING ASSY CL COMBI280
Ideal part no. 079947
54   OBSOLETE CONTROL CASING DOOR COMBI 280
Ideal part no. 079948
55 Part number 079605, CSG SEAL PK CLASSIC NF CSG SEAL PK CLASSIC NF
Ideal part no. 079605
56   OBSOLETE WALL MOUNTING PLATE COMBI 280
Ideal part no. 079949
57   OBSOLETE H/WARE PK COMBI 280
Ideal part no. 112287
58   OBSOLETE FLOW SWITCH O/LET PIPE ASS COMBI
Ideal part no. 005603
59   OBSOLETE TERMINAL WALL PLATE (PLASTIC 15881)
Ideal part no. 131662
60 Part number 005900, OBSOLETE O/HT STAT LM7 P8511:COMBI OBSOLETE O/HT STAT LM7 P8511:COMBI
Ideal part no. 005900		 £17.09
61   OBSOLETE ELBOW ASSEMBLY NF CL2
Ideal part no. 112327
63 Part number 078753, OBSOLETE PRES SENSE PIPE.EXCEL OBSOLETE PRES SENSE PIPE.EXCEL
Ideal part no. 078753
65   OBSOLETE PROGRAMMER SINGLE CHANNEL CM2
Ideal part no. 112606
66   22MM X 90 SHORT RAD ELBOW-BRASS
Ideal part no. 100984		 £5.37
67   7/8IN SEALING WASHER
Ideal part no. 113048		 £2.24
68 Part number 013324, 3/4IN SEALING WASHER VARS 3/4IN SEALING WASHER VARS
Ideal part no. 013324		 £3.98
69 Part number 013300, 1/2 SEAL WASHER 1/2 SEAL WASHER
Ideal part no. 013300		 £2.47
70 Part number 137759, BLR SEALING PLATE ASS CLASSIC BLR SEALING PLATE ASS CLASSIC
Ideal part no. 137759
71   OBSOLETE T/STAT WIRING HRNS COMBI
Ideal part no. 005858
72   OBSOLETE MAIN HARNESS :COMBI 280
Ideal part no. 112286
73   OBSOLETE PUMP WIRING HARNESS:COMBI
Ideal part no. 005859
74   OBSOLETE MINOR WIRING HARNESS COMBI
Ideal part no. 005927
77   OBSOLETE STAND OFF BRKT LH/RH COMBI
Ideal part no. 079643
79 Part number 069929, OBSOLETE PLASTIC IMPELLER WCF690152-01 OBSOLETE PLASTIC IMPELLER WCF690152-01
Ideal part no. 069929		 £8.87
80   OBSOLETE ISO VALVE 15MM
Ideal part no. 005628
81 Part number 005627, BALL VALVE 22MM COMP B/HD CONN BALL VALVE 22MM COMP B/HD CONN
Ideal part no. 005627		 £30.30
82   OBSOLETE 3/4 BULKHEAD CONN COMBI
Ideal part no. 005771
83   BACK NUT G3/4 BRASS TUR 12
Ideal part no. 004220		 £2.89
84   OBSOLETE 15MM X 1/2 MALE TANK COUPLING
Ideal part no. 005809
85   OBSOLETE BULKHEAD WASHER COMBI
Ideal part no. 005714
86 Part number 060569, PCB 27 BOARD (414900) PCB 27 BOARD (414900)
Ideal part no. 060569		 £94.73
88   OBSOLETE 3.2 IDX6.4 OD BLUE SILICONE-REP BY 84813
Ideal part no. 112049
89   OBSOLETE PLUG-BULGIN PX0587/ASHLY C4000
Ideal part no. 003069
90   NEG PRESS SENSING PIPE CL2
Ideal part no. 111482		 £4.44
91   OBSOLETE PRESS SENSING PIPE - COMBI NF
Ideal part no. 137471
92   PRESS SENSING PIPE POSITIVE COMBI NF
Ideal part no. 137472
93   OBSOLETE 22MM PUSH-FIT ELBOW-BRASS
Ideal part no. 111649
94   OBSOLETE 1 POLE ROCK/SWITCH 100011E BLK
Ideal part no. 004882
95   OBSOLETE SD WALL MTG PLATE CL/EL/RAPIDE
Ideal part no. 026550
96   OBSOLETE WALL MTG PLT ASS COMBI 280
Ideal part no. 112278
