IDEAL
HARRIER BOILER 4 - 10 SECTIONS - (Boiler Assembly 2)
Appliance Code: HARRIER

Appliance Diagram


Boiler Assembly 2 diagram for Ideal Harrier Boiler 4 - 10 SectionsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE BNR PLT GASKET FIREFLY HARR
Ideal part no. 013792
0   OBSOLETE INSULATION COC HARRIER
Ideal part no. 013984
0   OBSOLETE TOP C O C INSL LARGE HARRIER DOMR
Ideal part no. 013985
0   OBSOLETE 2 1/2IN - 3IN NIPPLE GAUGE
Ideal part no. 017034
0   OBSOLETE PLUG-WIELAND HARRIER
Ideal part no. 004091
0   OBSOLETE M16 X 75 STUD MS
Ideal part no. 011249
0   OBSOLETE M16 X 57 STUD BRASS
Ideal part no. 011302
0   OBSOLETE MMI 810.1 MOD 43 C/BOX SATRONIC.
Ideal part no. 065138
0   OBSOLETE FIBRE WASHER 1/16 AF2000
Ideal part no. 052689
0   OBSOLETE TAPERFILL 10MM H1060210/56 (29M)
Ideal part no. 083184
0   OBSOLETE 5LB TINS NO.5 MASTIC
Ideal part no. 000418
0   OBSOLETE METRES 20MM SEALING ROPE
Ideal part no. 077380
0   OBSOLETE 5LB TIN BLACK BLR PUTTY
Ideal part no. 000759
0   OBSOLETE 2LB TINS NO3 MASTIC
Ideal part no. 000319
0   OBSOLETE 3LB TINS NO3 MASTIC
Ideal part no. 000174
0   OBSOLETE M8 FORM F WASHER
Ideal part no. 000618
0   OBSOLETE NEON AMBER LIGHT CAT 430C
Ideal part no. 003396
0   OBSOLETE NEON GREEN LIGHT CAT 430C
Ideal part no. 003397
0   OBSOLETE NEON RED LIGHT CAT 430C
Ideal part no. 003395
0   OBSOLETE M8 HEX NUT BRASS
Ideal part no. 002232
1   OBSOLETE FRT/REAR SCTN HARRIER
Ideal part no. 132849
2   OBSOLETE CENTRE SCTN HARRIER
Ideal part no. 132848
3   OBSOLETE SECTION SET NIPPLES (2-3IN )
Ideal part no. 077565
4   OBSOLETE SET OF M12 TIE RODS ONLY
Ideal part no. 079305
4   OBSOLETE SET OF M12 TIE RODS ONLY
Ideal part no. 079304
4   OBSOLETE SET OF M12 TIE RODS ONLY
Ideal part no. 079306
4   OBSOLETE SET OF M12 TIE RODS ONLY
Ideal part no. 079300
4   OBSOLETE SET OF M12 TIE RODS ONLY
Ideal part no. 079301
4   OBSOLETE SET OF M12 TIE RODS ONLY
Ideal part no. 079303
4   OBSOLETE SET OF M12 TIE RODS HARR 6 SEC
Ideal part no. 079302
5   OBSOLETE H/WARE PK-TIE ROD HARRIER
Ideal part no. 013844
6   OBSOLETE ASSEMBLY ROD SET HARRIER DOMR
Ideal part no. 079307
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079314
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079310
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079309
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079311
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079313
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079312
7   OBSOLETE BOILER BODY ASSEMBLY
Ideal part no. 079308
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079320
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079319
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079321
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079316
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079318
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079317
8   OBSOLETE FOUNDATION PLATE
Ideal part no. 079315
9   OBSOLETE FLOW ELBOW HARRIER
Ideal part no. 133505
10   OBSOLETE RETURN FLANGE HARRIER
Ideal part no. 133506
11   OBSOLETE BLANK FLANGE HARRIER
Ideal part no. 133259
12   OBSOLETE DRAIN COCK/FLANGE ASS HARRIER
Ideal part no. 134106
13   OBSOLETE FLANGE GASKET HARRIER
Ideal part no. 013790
14   OBSOLETE RUBBER GASKET HARRIER
Ideal part no. 013791
15   OBSOLETE UPPER FRT COC ASSY HARRIER
Ideal part no. 079322
16   OBSOLETE UPPER FRONT C O C INSL HARR
Ideal part no. 013785
17   OBSOLETE LWR CO COVER HARRIER
Ideal part no. 079323
18   OBSOLETE LOWER C O COVER INSL HARRIER
Ideal part no. 013784
19   OBSOLETE C/O COVER ASS-TP SMALL HARRIER
Ideal part no. 135676
20   OBSOLETE C/O COVER ASS-TP LARGE HARRIER
Ideal part no. 135677
21   OBSOLETE T BOLT MS HARRIER DOMR
Ideal part no. 133528
22   OBSOLETE SMOKE HOOD ASS HARRIER
Ideal part no. 134208
23   OBSOLETE SMOKE HOOD INSL HARRIER
Ideal part no. 013782
24   OBSOLETE SMOKE HOOD COC W/INSUL
Ideal part no. 079324
25   OBSOLETE SMOKE HOOD ADAPTER PTD HARRIER
Ideal part no. 133427
26   OBSOLETE DIST TUBE HARRIER 4
Ideal part no. 132402
26   OBSOLETE DIST TUBE HARRIER 10
Ideal part no. 132408
26   OBSOLETE DIST TUBE:HARRIER 9
Ideal part no. 132407
26   OBSOLETE DIST TUBE:HARRIER 6
Ideal part no. 132404
26   OBSOLETE DIST TUBE HARRIER 50
Ideal part no. 132403
26   OBSOLETE DIST TUBE HARRIER 8
Ideal part no. 132406
26   OBSOLETE DIST TUBE:HARRIER 7
Ideal part no. 132405
27   OBSOLETE DIST ROD ASS HARRIER DOMR 10 SCTN
Ideal part no. 133535
27   OBSOLETE DIST ROD ASS:HARRIER 9 SCTN
Ideal part no. 133534
27   OBSOLETE DIST ROD ASS:HARRIER 7 SCTN
Ideal part no. 133532
27   OBSOLETE DIST ROD ASS:HARRIER 6 SCTN
Ideal part no. 133531
27   OBSOLETE DIST ROD ASS HARRIER 8 SCTN
Ideal part no. 133533
27   OBSOLETE DIST ROD ASS HARRIER 5 SCTN
Ideal part no. 133530
27   OBSOLETE DIST ROD ASS HARRIER 4 SCTN
Ideal part no. 133529
28   OBSOLETE BNR FRT PLT ASS HARRIER
Ideal part no. 134105
29   OBSOLETE BNR FRT PLT PTD HARRIER
Ideal part no. 133428
30   OBSOLETE BURNER FRT PLATE INSL HARR
Ideal part no. 013786
31   OBSOLETE S/GLASS ASSY KIT VRY/FALC
Ideal part no. 077268
32   OBSOLETE COMB CHBR BACK PLATE W/INS HARRIER
Ideal part no. 079325
33   OBSOLETE COMBUSTION CHAMBER INSL HARR
Ideal part no. 013787
34   OBSOLETE T/STAT POCKET 100 X 15 BUCC
Ideal part no. 003295
35   OBSOLETE CONTROLS PACKAGE HARRIER A
Ideal part no. 134122
36 Part number 171107, OBSOLETE CONTROL T/STAT KIT 3 OBSOLETE CONTROL T/STAT KIT 3
Ideal part no. 171107
37 Part number 171108, OBSOLETE OVERHEAT T/STAT KIT 4 OBSOLETE OVERHEAT T/STAT KIT 4
Ideal part no. 171108
38   OBSOLETE VAPOUR PRESSURE THERMOMETER
Ideal part no. 004511
39   OBSOLETE PRESSURE GAUGE
Ideal part no. 004585
40   OBSOLETE DOUBLE POLE SWITCH SCEM
Ideal part no. 004711
43   OBSOLETE CTRL FASCIA PTD HARRIER DOMR
Ideal part no. 133481
44   OBSOLETE BURNER LEAD ASSY HARRIER
Ideal part no. 133485
45   OBSOLETE JACKET PACKAGE:HARRIER DOMR 6 SCTN
Ideal part no. 134092
45   OBSOLETE JACKET PACKAGE HARRIER DOMR 4 SCTN
Ideal part no. 134090
45   OBSOLETE JACKET PACKAGE HARRIER DOMR 5 SCTN
Ideal part no. 134091
45   OBSOLETE JACKET PACKAGE HARRIER DOMR 8 SCTN
Ideal part no. 134094
45   OBSOLETE JACKET PACKAGE:HARRIER DOMR 7 SCTN
Ideal part no. 134093
45   OBSOLETE JACKET PACKAGE HARRIER DOMR 10 SCTN
Ideal part no. 134096
45   OBSOLETE JACKET PACKAGE:HARRIER DOMR 9 SCTN
Ideal part no. 134095
46   OBSOLETE TOP INSULATION:HARRIER DOMR
Ideal part no. 013808
46   OBSOLETE TOP INSULATION HARRIER DOMR
Ideal part no. 013809
46   OBSOLETE TOP INSULATION HARRIER DOMR
Ideal part no. 013807
46   OBSOLETE TOP INSULATION:HARRIER DOMR
Ideal part no. 013805
46   OBSOLETE TOP INSULATION:HARRIER DOMR
Ideal part no. 013806
46   OBSOLETE TOP INSULATION HARRIER DOMR
Ideal part no. 013803
46   OBSOLETE TOP INSULATION HARRIER DOMR
Ideal part no. 013804
47   OBSOLETE JKT LWR FRT SUPPORT HARRIER DOMR
Ideal part no. 133452
48   OBSOLETE BACK PANEL SECR ANGLE HARRIER DOMR
Ideal part no. 133455
49   OBSOLETE JKT TOP PANEL-REAR PTD:HARR 7
Ideal part no. 133463
49   OBSOLETE JKT TOP PANEL-REAR PTD HARR 5
Ideal part no. 133459
49   OBSOLETE JKT TOP PANEL-REAR PTD HARR 4
Ideal part no. 133457
49   OBSOLETE JKT TOP PANEL-REAR PTD:HARR 6
Ideal part no. 133461
49   OBSOLETE JKT TOP PANEL-REAR PTD HARR 10
Ideal part no. 133469
49   OBSOLETE JKT TOP PANEL-REAR PTD:HARR 9
Ideal part no. 133467
49   OBSOLETE JKT TOP PANEL-REAR PTD HARR 8
Ideal part no. 133465
50   OBSOLETE UPPER JKT SUPP NUTSERT ASS HARR
Ideal part no. 133862
51   OBSOLETE TOP PANEL SUPPORT ASS HARRIER DOMR
Ideal part no. 134089
52   OBSOLETE RH SIDE JKT PNL ASS HARR 10
Ideal part no. 134181
52   OBSOLETE RH SIDE JKT PNL ASS:HARR 7 SCT
Ideal part no. 134178
52   OBSOLETE RH SIDE JKT PNL ASS:HARR 6 SCT
Ideal part no. 134177
52   OBSOLETE RH SIDE JKT PNL ASS:HARR 9 SCT
Ideal part no. 134180
52   OBSOLETE RH SIDE JKT PNL ASS HARR 8 SCT
Ideal part no. 134179
52   OBSOLETE RH SIDE JKT PNL ASS HARR 5 SCT
Ideal part no. 134176
52   OBSOLETE RH SIDE JKT PNL ASS HARR 4 SCT
Ideal part no. 134175
53   OBSOLETE LH SIDE JKT PNL ASS HARR 5 SCT
Ideal part no. 134184
53   OBSOLETE LH SIDE JKT PNL ASS HARR 4 SCT
Ideal part no. 134183
53   OBSOLETE LH SIDE JKT PNL ASS:HARR 7 SCT
Ideal part no. 134186
53   OBSOLETE LH SIDE JKT PNL ASS:HARR 6 SCT
Ideal part no. 134185
53   OBSOLETE LH SIDE JKT PNL ASS HARR 8 SCT
Ideal part no. 134187
53   OBSOLETE LH SIDE JKT PNL ASS HARR 10
Ideal part no. 134189
53   OBSOLETE LH SIDE JKT PNL ASS:HARR 9 SCT
Ideal part no. 134188
54   OBSOLETE SIDE PANEL INSL HARRIER DOMR
Ideal part no. 013797
54   OBSOLETE SIDE PANEL INSL HARRIER DOMR
Ideal part no. 013800
54   OBSOLETE SIDE PANEL INSUL:HARRIER DOMR
Ideal part no. 013801
54   OBSOLETE SIDE PANEL INSUL:HARRIER DOMR
Ideal part no. 013798
54   OBSOLETE SIDE PANEL INSUL:HARRIER DOMR
Ideal part no. 013799
54   OBSOLETE SIDE PANEL INSL HARRIER DOMR
Ideal part no. 013802
54   OBSOLETE SIDE PANEL INSL HARRIER DOMR
Ideal part no. 013796
55   OBSOLETE JKT FRT TOP PNL ASS HARRIER DOMR
Ideal part no. 134191
56   OBSOLETE RH BACK PANEL ASS HARRIER DOMR
Ideal part no. 134194
57   OBSOLETE INSUL-RH BACK PANEL HARRIER DOMR
Ideal part no. 013794
58   OBSOLETE LH BACK PANEL ASS HARRIER DOMR
Ideal part no. 134195
59   OBSOLETE INSUL-LH BACK PANEL HARRIER DOMR
Ideal part no. 013795
60   OBSOLETE LOWER FRONT PANEL ASS HARRIER DOMR
Ideal part no. 134197
61   OBSOLETE UPPER FRONT PANEL ASS HARRIER DOMR
Ideal part no. 134198
62   OBSOLETE FRT UPR JKT SUPP PNL ASS HARR
Ideal part no. 134234
63   OBSOLETE H/WARE PK-JKT HARRIER DOMR
Ideal part no. 013847
65   OBSOLETE INSULATION PACK-BOILER HARR
Ideal part no. 134104
66   OBSOLETE FLUE BRUSH 5 X 5 X 2 WIRE
Ideal part no. 017059
68   OBSOLETE FLUE BRUSH HANDLE VARIOUS
Ideal part no. 049549
69   OBSOLETE FL BRUSH HANDLE S/ASS HARR 4/5
Ideal part no. 134365
69   OBSOLETE FL BRUSH HANDL S/ASS HARR 9/10
Ideal part no. 134367
69   OBSOLETE FL BRUSH HANDLE S/ASS HARR 6/8
Ideal part no. 134366
70   OBSOLETE RAKE
Ideal part no. 017479
70   OBSOLETE RAKE FOR 5-11 SECTION BOILER
Ideal part no. 017478
71   OBSOLETE BURNER ADAPTER PLATE PTD:HARR
Ideal part no. 133371
71   OBSOLETE BURNER ADAPTER PLATE PTD:HARR
Ideal part no. 133373
71   OBSOLETE BURNER ADAPTER PLATE PTD:HARR
Ideal part no. 133372
71   OBSOLETE BURNER ADAPTER PLT PTD:HARR
Ideal part no. 133374


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
