IDEAL
HE C32 - (Boiler Exploded View)
Appliance Code: 47-348-37

Appliance Diagram


Boiler Exploded View diagram for Ideal HE C32Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   HEAT EXCHANGER 28-32KW
Ideal part no. 173855
£186.02
2 Part number 173857, FAN 28-32KW cw O RING FAN 28-32KW CW O RING
Ideal part no. 173857
£75.64
5   RECUPERATOR INCLUDING SEALS
Ideal part no. 173861
£269.76
6   BURNER 28-32KW
Ideal part no. 173863
£37.54
8   INJECTOR BURNER 28-32KW
Ideal part no. 173867
£2.02
9 Part number 173868, DETECTION ELECTRODE DETECTION ELECTRODE
Ideal part no. 173868
£7.53
10   IGNITION ELECTRODE
Ideal part no. 173869
£12.39
17 Part number 173203, VALVE-PRESSURE RELIEF CH VALVE-PRESSURE RELIEF CH
Ideal part no. 173203
£22.40
19 Part number 173878, PUMP HEAD 32KW PUMP HEAD 32KW
Ideal part no. 173878

20 Part number 173876, WATERSET CLIPS WATERSET CLIPS
Ideal part no. 173876

21 Part number 173880, AIR VENT AIR VENT
Ideal part no. 173880
£12.30
40 Part number 173901, IGNITION UNIT - NAC IGNITION UNIT - NAC
Ideal part no. 173901

41 Part number 173903, AIR PRESSURE SWITCH 28-32KW AIR PRESSURE SWITCH 28-32KW
Ideal part no. 173903
£50.98
46   PANEL - BOTTOM
Ideal part no. 173913
£8.82
50 Part number 173925, GAS VALVE GAS VALVE
Ideal part no. 173925
£82.91
51 Part number 173926, CONDENSATE - OVERHEAT SENSOR CONDENSATE - OVERHEAT SENSOR
Ideal part no. 173926

52 Part number 173927, THERMISTOR OVERHEAT THERMISTOR OVERHEAT
Ideal part no. 173927

53 Part number 173928, EXPANSION VESSEL EXPANSION VESSEL
Ideal part no. 173928
£107.52
56   INSULATION COMBUSTION CHAMBER 28-32KW
Ideal part no. 173911

57 Part number 173932, THERMISTOR-WATERSET CH & DHW THERMISTOR-WATERSET CH & DHW
Ideal part no. 173932
£28.01
58 Part number 170995, PLATE HEAT EXCHANGER KIT ISAR PLATE HEAT EXCHANGER KIT ISAR
Ideal part no. 170995
£113.34
58 Part number 173545, PLATE HEAT EXCHANGER KIT - ISAR HE35 PLATE HEAT EXCHANGER KIT - ISAR HE35
Ideal part no. 173545
£164.34
