IDEAL
I MINI 30 - (Controls)
Appliance Code: 47-348-78

Appliance Diagram


Controls diagram for Ideal I Mini 30Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

301 Part number 175626, BOX FIXINGS HINGE & SPRING KIT BOX FIXINGS HINGE & SPRING KIT
Ideal part no. 175626		 £24.48
302 Part number 175935, KIT - PRIMARY PCB (AAB ONLY) (A BCC CARD MUST BE PURCHASED WITH THIS ITEM) KIT - PRIMARY PCB (AAB ONLY) (A BCC CARD MUST BE PURCHASED WITH THIS ITEM)
Ideal part no. 175935		 £211.15
303 Part number 175588, CUI BOARD KIT CUI BOARD KIT
Ideal part no. 175588		 £92.21
306 Part number 175591, ELECTRODE - IGNITION ELECTRODE - IGNITION
Ideal part no. 175591		 £24.54
307 Part number 175592, ELECTRODE - DETECTION ELECTRODE - DETECTION
Ideal part no. 175592		 £17.81
308 Part number 175593, IGNITOR UNIT (PRE ADP) IGNITOR UNIT (PRE ADP)
Ideal part no. 175593		 £37.11
309 Part number 175594, THERMISTOR - NO FLOW THERMISTOR - NO FLOW
Ideal part no. 175594		 £11.40
312 Part number 175597, HARNESS - EARTH HT (PRE ADP) HARNESS - EARTH HT (PRE ADP)
Ideal part no. 175597		 £6.68
313 Part number 175598, IGNITION LEAD IGNITION LEAD
Ideal part no. 175598		 £17.66
314   CONTROL BOX LENS
Ideal part no. 175599		 £20.49
315 Part number 175600, HARNESS - CUI TO PRIMARY (AAO ONWARDS) HARNESS - CUI TO PRIMARY (AAO ONWARDS)
Ideal part no. 175600		 £18.31
317 Part number 177552, HARNESS MAINS VOLTAGE HARNESS MAINS VOLTAGE
Ideal part no. 177552		 £52.85
317 Part number 177898, HARNESS MAINS ErP COMBI COMBI+ CODE HARNESS MAINS ERP COMBI COMBI+ CODE
Ideal part no. 177898		 £51.19
318 Part number 175602, HARNESS - LOW VOLTAGE HARNESS - LOW VOLTAGE
Ideal part no. 175602		 £39.20
318 Part number 176430, HARNESS LOW VOLTAGE COMBI (ZH ONWARDS) HARNESS LOW VOLTAGE COMBI (ZH ONWARDS)
Ideal part no. 176430		 £37.99
318 Part number 177554, HARNESS SAFETY EXTRA LOW VOLTAGE HARNESS SAFETY EXTRA LOW VOLTAGE
Ideal part no. 177554		 £27.11
318 Part number 177900, HARNESS SELV ErP COMBI & CODE HARNESS SELV ERP COMBI & CODE
Ideal part no. 177900		 £32.29
320 Part number 175604, HARNESS - DETECTION earth lead no longer required HARNESS - DETECTION EARTH LEAD NO LONGER REQUIRED
Ideal part no. 175604		 £15.34
324   CONTROL BOX LID KIT
Ideal part no. 175623		 £30.67
325   CONTROL BOX FRONT
Ideal part no. 175559		 £63.04
328 Part number 175627, PCB FUSE PCB FUSE
Ideal part no. 175627		 £4.00
330 Part number 175902, MECHANICAL TIMER 24HR MECHANICAL TIMER 24HR
Ideal part no. 175902		 £64.53
331 Part number 175903, HARNESS - MECHANICAL TIMER HARNESS - MECHANICAL TIMER
Ideal part no. 175903		 £7.42
331 Part number 177555, HARNESS OPENTHERM ABK Onwards HARNESS OPENTHERM ABK ONWARDS
Ideal part no. 177555		 £9.56
