IDEAL
SPRINT RS 75P - (Appliance Overview)
Appliance Code: SPRINT RS 75P

Appliance Diagram

Appliance Overview diagram for Ideal Sprint RS 75P Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0	1/2 SEAL WASHER Ideal part n^o. 013300	£2.47
0	OBSOLETE SINGLE POLE SWITCH C1426 Ideal part n^o. 004348
0	OBSOLETE O RING 22.00MM I/D X 2.00MM SECTION EP Ideal part n^o. 004329
0	OBSOLETE RET PIPE SEALING WASHER SPRINT Ideal part n^o. 013515
0	OBSOLETE 22MM COMPRESSION NUT Ideal part n^o. 013091
0	OBSOLETE 22MM COMP OLIVE Ideal part n^o. 013090
0	NO 10X2 1/2IN WOOD SCREW RD HD DES 0250 Ideal part n^o. 013514	£2.47
0	OBSOLETE OVERHEAT THERMOSTAT KIT SPR80F Ideal part n^o. 134215
0	OBSOLETE GSKT SET SPR RAP RS75 (KIT) Ideal part n^o. 079475
0	OBSOLETE 22MM UNION NUT Ideal part n^o. 004905
0	OBSOLETE ORANGE LENSES SPRINT Ideal part n^o. 003938
0	OBSOLETE LH FASCIA TRIM SPRT RS 75 Ideal part n^o. 130486
0	OBSOLETE RH FASCIA TRIM SPRINT RS75 Ideal part n^o. 130487
0	3/4IN SEALING WASHER VARS Ideal part n^o. 013324	£3.98
0	OBSOLETE 22MM SEALING WASHER Ideal part n^o. 013102
0	OBSOLETE CONV KIT SPT RS75P (KIT) Ideal part n^o. 005053
1	OBSOLETE HT EXCHANGER SPRINT RS 75. Ideal part n^o. 078325
2	AUTO AIR VENT ASS SPRINT Ideal part n^o. 078345
3	OBSOLETE COLL HOOD ASSY SPRINT RS75 Ideal part n^o. 078326
4	OBSOLETE SIGHT GLASS ASSY - BNR BOX Ideal part n^o. 079333
5	OBSOLETE GAS MANIFOLD SPRINT RS75 Ideal part n^o. 078327
6	OBSOLETE PILOT PIPE SPRINT RS75 Ideal part n^o. 078328
7	OBSOLETE MAIN BURNER FURIGAS 118.500.020 Ideal part n^o. 013326
8	OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 2200 Ideal part n^o. 004049
9	OBSOLETE PILOT BURNER-HONEYWELL W/FXGS Ideal part n^o. 078263
10	OBSOLETE INJECTOR PILOT 4500-41114-001 Ideal part n^o. 003863
11	OBSOLETE PILOT DRAUGHT SHIELD ASS:SPRINT Ideal part n^o. 058644
12	OBSOLETE GAS VALVE V8600N2023 Ideal part n^o. 004611
12	OBSOLETE1/2 BSP HONEYWELL GAS CONTROL Ideal part n^o. 078329
13	OBSOLETE GAS COCK ASSY 004914/920/919 Ideal part n^o. 077014
14	OBSOLETE SPARK GEN ASS SPRINT RS75 Ideal part n^o. 130926
15	OBSOLETE IGN ELECTRODE ASSY KIT SP RS75 Ideal part n^o. 078330
16	NOW USE Q309A2747 THERMOCOUPLE 750MM Ideal part n^o. 003876
16	Q309A2747 - THERMOCOUPLE Baxi part n^o. Q309A2747	£9.18
17	OBSOLETE BNR CTRL ASS SPRINT RS75 Ideal part n^o. 130908
18	OBSOLETE CTRL PNL:SPRINT RS75 Ideal part n^o. 130909
19	OBSOLETE TRANSFORMER-PEKTRON T27. Ideal part n^o. 004378
20	OBSOLETE PCB DRIVER BOARD W/CONN Ideal part n^o. 079654
21	OBSOLETE PRESS/TEMP GAUGE REF 941.61.1. Ideal part n^o. 004171
22	OBSOLETE SINGLE POLE ROCKER SWITCH C145 Ideal part n^o. 004315
23	OBSOLETE NEON LAMPS (PACK OF 2) Ideal part n^o. 078798
24	OBSOLETE PLASTIC CAN SUPPRESSOR STC NO Ideal part n^o. 004033
25	OBSOLETE T/STAT H/STAT ASSY COMBI Ideal part n^o. 079634
26	OBSOLETE L/STAT INT LEAD ASS ELAN Ideal part n^o. 130787
27	OBSOLETE THERMISTOR DOM HOT WATER T7335 TP Ideal part n^o. 004174
28	DOM HOT WTR DIV VALVE Ideal part n^o. 078331	£123.16
29	A21 HT EXCH SPRINT RS75 Ideal part n^o. 079653	£247.14
30	3 BAR SAFETY VALVE R1/2 X RC1/2 Ideal part n^o. 004164	£29.91
31	OBSOLETE PUMP 15-60 MEX/CXC Ideal part n^o. 004812
32	OBSOLETE SYSTEM EXPANSION VESSEL-10LTR SPRINT Ideal part n^o. 004170
33	OBSOLETE DHW EXPANSION VESSEL Ideal part n^o. 079268
34	OBSOLETE BOILER FLOW PIPE C/W FITTINGS Ideal part n^o. 078332
35	OBSOLETE BOILER RETURN PIPE W/FTGS Ideal part n^o. 078333
36	OBSOLETE FLOW PIPE ASSY SPRINT RS75 Ideal part n^o. 075240
37	OBSOLETE DIV VALVE TO CALOR PIPE SPR Ideal part n^o. 079663
38	OBSOLETE DIV/BYPASS PIPE SPT RS75 Ideal part n^o. 078335
39	OBSOLETE DIV VALVE O/LET PIPE SPRINT Ideal part n^o. 079669
40	OBSOLETE DOM WATER INLET PIPE:SPRINT Ideal part n^o. 131674
41	OBSOLETE DOM WATER OUTLET PIPE SPRINT Ideal part n^o. 079664
42	OBSOLETE CALOR OUTLET PIPE SPRINT Ideal part n^o. 078338
43	DRAIN COCK 1/2 INCH Ideal part n^o. 004166	£14.03
44	OBSOLETE PUMP O/LET PIPE AS:SPRINT RS75 Ideal part n^o. 130243
45	OBSOLETE CONNECTOR-BYPASS VALVE Ideal part n^o. 078337
46	OBSOLETE RELIEF VALVE PIPE:SPRINT RS75 Ideal part n^o. 130490
47	OBSOLETE EXP TANK PIPE ASSY SPR 75 Ideal part n^o. 078336
48	BALL VALVE ASS SPRINT Ideal part n^o. 130915	£35.82
50	OBSOLETE FLOW LMTER TYPE A 12 LTR:SPRNT Ideal part n^o. 004310
52	OBSOLETE BLR CSG SPRINT RS75/75P Ideal part n^o. 130910
53	OBSOLETE FASCIA PNL:ELAN RS60/75 Ideal part n^o. 059850
54	OBSOLETE CTRL CSG DOOR ASS:SPRINT RS Ideal part n^o. 130911
55	OBSOLETE SEALING PACK SPRINT RS 75 Ideal part n^o. 078340
59	OBSOLETE H/WARE PK ELAN CF Ideal part n^o. 132961
60	OBSOLETE BACK PNL/INTERPANEL SPRINT RS75 Ideal part n^o. 078341
61	OBSOLETE PROGRAMMER KIT SPRINT RS75 Ideal part n^o. 131003
62	L/STAT 2455 RMT B2035 110C Ideal part n^o. 013843
63	OBSOLETE DIV VALVE M/SWITCH HSG S/M Ideal part n^o. 065750
64	DIV VALVE GSKT SET SPRINT (KIT) Ideal part n^o. 079170	£5.37
65	OBSOLETE CROSS TRIMS ELAN RS 60/75 Ideal part n^o. 058794
