INTERGAS
25 - (Bottom And Controller)
Appliance Code: 47-291-08

Appliance Diagram


Bottom And Controller diagram for Intergas 25Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   COVER PLATE
Intergas part no. 145538		 £2.99
2   SCREW PLASTITE
Intergas part no. 362117		 £3.00
3 Part number 844967, COVER PLATE CABLE TRANSFER COVER PLATE CABLE TRANSFER
Intergas part no. 844967		 £10.03
4   SEAL - COVER CABLE TRANSFER
Intergas part no. 876217		 P.O.A.
5   SEAL - CABLE TRANSFER
Intergas part no. 876227		 P.O.A.
6 Part number 878467, GROMMET BLIND GROMMET BLIND
Intergas part no. 878467		 £2.64
7   ELECTR. CONNECTION WIRE Y
Intergas part no. 230687		 £3.00
8 Part number 260427, Connector 9 Pins 5mm 24V CONNECTOR 9 PINS 5MM 24V
Intergas part no. 260427		 £8.00
9   STICKER (WIRING)
Intergas part no. 888127		 P.O.A.
10   PLASTIC RING M2.5
Intergas part no. 320057		 P.O.A.
11 Part number 878467, GROMMET BLIND GROMMET BLIND
Intergas part no. 878467		 £2.64
12   NUT M12
Intergas part no. 260437		 P.O.A.
13   HINGE PIN L=237
Intergas part no. 872097		 P.O.A.
14   RING M4
Intergas part no. 321007		 P.O.A.
15   TRANSFER PLATE
Intergas part no. 146327		 P.O.A.
16   CABLE SUPPORT M12
Intergas part no. 260447		 P.O.A.
17 Part number 876207, Gasket GASKET
Intergas part no. 876207		 £3.00
18 Part number 866147, Drain DRAIN
Intergas part no. 866147		 £3.00
19   GROMMET BLIND 15MM
Intergas part no. 878347		 P.O.A.
20 Part number 260467, Cable Support Nut M16 CABLE SUPPORT NUT M16
Intergas part no. 260467		 £4.00
21 Part number 260457, Nut M16 NUT M16
Intergas part no. 260457		 £3.00
22 Part number 844707, BOTTOM METALLIC BOTTOM METALLIC
Intergas part no. 844707		 £61.80
23   MOUNTING PLATE - PRESSURE GAUGE
Intergas part no. 145557		 P.O.A.
24 Part number 864137, PRESSURE GAUGE PRESSURE GAUGE
Intergas part no. 864137		 £24.99
25 Part number 312027, Flange Nut M5 FLANGE NUT M5
Intergas part no. 312027		 £3.00
26 Part number 074857, Boiler controlled Rapid (PCB) BOILER CONTROLLED RAPID (PCB)
Intergas part no. 074857		 £396.00
27   STICKER DISPLAY RAPID 25
Intergas part no. 889557		 £16.00
28 Part number 872117, DISPLAY COVER MAGNET DISPLAY COVER MAGNET
Intergas part no. 872117		 £6.17
29   DISPLAY COVER RAPID
Intergas part no. 843847		 £14.00
30 Part number 220977, Power Cord (Without Plug) POWER CORD (WITHOUT PLUG)
Intergas part no. 220977		 £7.00
