INTERGAS
RF 24 - (Burner)
Appliance Code: 47-291-05

Appliance Diagram


Burner diagram for Intergas RF 24Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 800327, NOW USE 086454 Burner KIT NOW USE 086454 BURNER KIT
Intergas part no. 800327

1   BURNER KIT
Intergas part no. 086454
£228.00
2 Part number 877847, Burner Seal BURNER SEAL
Intergas part no. 877847
£4.00
3 Part number 073647, INSULATION PACKAGE - SMALL INSULATION PACKAGE - SMALL
Intergas part no. 073647
P.O.A.
4 Part number 876457, Isolation Front plate ISOLATION FRONT PLATE
Intergas part no. 876457
£8.00
5 Part number 876467, Seal Ring Front plate 24kW SEAL RING FRONT PLATE 24KW
Intergas part no. 876467
£7.50
6   FRONT PLATE LARGE
Intergas part no. 858977
£91.00
7 Part number 875917, O-Ring 6x1.5 Silicone O-RING 6X1.5 SILICONE
Intergas part no. 875917
£3.00
8 Part number 362217, Plate Screw T20 PLATE SCREW T20
Intergas part no. 362217
£3.00
9 Part number 390087, Starlock 4mm STARLOCK 4MM
Intergas part no. 390087
£3.00
10 Part number 305157, Shoulder bolt incl. dry-l SHOULDER BOLT INCL. DRY-L
Intergas part no. 305157
£3.00
