INTERGAS
RF 36 - (Heat Exchanger)
Appliance Code: 47-291-07

Appliance Diagram


Heat Exchanger diagram for Intergas RF 36Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 843017, Air Release Vale 3/8"G(ma AIR RELEASE VALE 3/8"G(MA
Intergas part no. 843017
£5.64
2   FLOW PIPE 36KW
Intergas part no. 854627
£80.00
3 Part number 081097, Inspection. Glass Replacement INSPECTION. GLASS REPLACEMENT
Intergas part no. 081097
£8.00
4 Part number 875517, Bonded Seal 3/4" BONDED SEAL 3/4"
Intergas part no. 875517
£3.00
5 Part number 873337, Clip NTC 1 and NTC 2 CLIP NTC 1 AND NTC 2
Intergas part no. 873337
£3.00
6 Part number 200117, NTC 1 - 2 (S1 Sensors) NTC 1 - 2 (S1 SENSORS)
Intergas part no. 200117
£17.00
7 Part number 873537, Clip Pressure Sensor CLIP PRESSURE SENSOR
Intergas part no. 873537
£3.00
8 Part number 844417, Pressure Relieve Valve 1/2 PRESSURE RELIEVE VALVE 1/2
Intergas part no. 844417
£33.00
9   SEAL RING
Intergas part no. 875907
£3.00
10 Part number 825077, Thread Ring THREAD RING
Intergas part no. 825077
£4.00
11   DRAIN PIPE PRV
Intergas part no. 854647
£4.00
12   FLOW PIPE (EXTENSION)
Intergas part no. 854637
£7.00
13   T-COMPRESSING FITTING
Intergas part no. 823097
£19.00
14 Part number 864087, Pressure Sensor CH/ Pressure Switch PRESSURE SENSOR CH/ PRESSURE SWITCH
Intergas part no. 864087
£38.00
15 Part number 854587, Hot Water Pipe HOT WATER PIPE
Intergas part no. 854587
£14.00
16 Part number 844797, Flow sensor / Flow Turbine FLOW SENSOR / FLOW TURBINE
Intergas part no. 844797
£57.00
17 Part number 829287, Spacer Ring SPACER RING
Intergas part no. 829287
£4.00
18 Part number 200177, NTC DHW NTC DHW
Intergas part no. 200177
£18.00
19 Part number 854527, Cold Water Pipe COLD WATER PIPE
Intergas part no. 854527
£6.00
20 Part number 826047, Nut 1/2" NUT 1/2"
Intergas part no. 826047
£4.00
21 Part number 845127, Filling ring flow sensor FILLING RING FLOW SENSOR
Intergas part no. 845127
£3.00
22 Part number 074607, Ignition Cable + Cap (REPLACES 221467) IGNITION CABLE + CAP (REPLACES 221467)
Intergas part no. 074607
£20.00
22 Part number 221467, NOW USE 074607 Ign.Cable+Cap(old)=>074607 NOW USE 074607 IGN.CABLE+CAP(OLD)=>074607
Intergas part no. 221467

23 Part number 305137, Bolt M4x10 BOLT M4X10
Intergas part no. 305137
£3.00
24 Part number 209327, Ignition Pin / electrode IGNITION PIN / ELECTRODE
Intergas part no. 209327
£21.00
25 Part number 878517, Spacer SPACER
Intergas part no. 878517
£4.00
26 Part number 875677, Gasket Ignition Pin GASKET IGNITION PIN
Intergas part no. 875677
£3.00
27 Part number 313047, Lock Nut M8 LOCK NUT M8
Intergas part no. 313047
£3.00
28 Part number 319047, Insert M4 INSERT M4
Intergas part no. 319047
£3.00
29 Part number 147207, Heat Exch. HRE+ Large Com HEAT EXCH. HRE+ LARGE COM
Intergas part no. 147207
£821.00
30 Part number 231107, Earth Connection EARTH CONNECTION
Intergas part no. 231107
£3.00
31 Part number 875567, Pump Seal 1" PUMP SEAL 1"
Intergas part no. 875567
£3.00
32 Part number 210247, Pump 1" ( REPLACES 210177) NON ERP PUMP 1" ( REPLACES 210177) NON ERP
Intergas part no. 210247

33 Part number 828287, Return Pipe RETURN PIPE
Intergas part no. 828287
£7.00
34 Part number 826207, Pump Nut 1" PUMP NUT 1"
Intergas part no. 826207
£6.00
