MAIN
12 HE A HEAT ONLY - (Controls)
Appliance Code: 41-467-16

Appliance Diagram


Controls diagram for Main 12 HE A Heat OnlyClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

401 Part number 240670, NOW USE 7671970 THERMOSTAT BOILER NOW USE 7671970 THERMOSTAT BOILER
Main part no. 240670
401 Part number 7671970, THERMOSTAT BOILER-240670 THERMOSTAT BOILER-240670
Baxi part no. 7671970		 £13.59
402 Part number 240675, O-RING 22.5mm I/Dx3mm RUBBER O-RING 22.5MM I/DX3MM RUBBER
Main part no. 240675		 £3.16
402 Part number 240812, O-RING 20.64 x 2.62mm O-RING 20.64 X 2.62MM
Main part no. 240812		 £3.26
402 Part number 242459, FLOW SWITCH FLOW SWITCH
Main part no. 242459		 £49.78
403 Part number 242235, NOW USE 7671968 THERMOSTAT OVERHEAT NOW USE 7671968 THERMOSTAT OVERHEAT
Main part no. 242235
403 Part number 7671968, THERMOSTAT OVERHEAT-242235 THERMOSTAT OVERHEAT-242235
Baxi part no. 7671968		 £20.37
404 Part number 240675, O-RING 22.5mm I/Dx3mm RUBBER O-RING 22.5MM I/DX3MM RUBBER
Main part no. 240675		 £3.16
404 Part number 240812, O-RING 20.64 x 2.62mm O-RING 20.64 X 2.62MM
Main part no. 240812		 £3.26
404 Part number 242461, BRASS FITTINGS BRASS FITTINGS
Main part no. 242461		 £29.51
405   SCREW M6X20
Main part no. 633404		 £3.06
406 Part number 5121025, ELECTRONIC CONTROL ELECTRONIC CONTROL
Main part no. 5121025		 £272.31
407   SCR SET M5X15MM CAP HD SOCKET
Main part no. 242226		 £3.26
408 Part number 241900, VALVE MULTIFUNCTIONAL VALVE MULTIFUNCTIONAL
Main part no. 241900		 £144.98
410 Part number 242475, 5mm PIPE - SPARES 5MM PIPE - SPARES
Main part no. 242475		 £19.61
411 Part number 242229, GASKET GASKET
Main part no. 242229		 £3.16
413   NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Main part no. 102012		 £3.12
415 Part number 242493, HEAT EX. MANIFOLD HEAT EX. MANIFOLD
Main part no. 242493		 £34.55
416 Part number 241806, PLUG DRAIN PLUG DRAIN
Main part no. 241806		 £7.09
417 Part number 240676, NOW USE 7671969 SEAL MANIFOLD 2.62mm DIA NOW USE 7671969 SEAL MANIFOLD 2.62MM DIA
Main part no. 240676
417 Part number 7671969, SEAL MANIFOLD 2.62mm D-240676 SEAL MANIFOLD 2.62MM D-240676
Baxi part no. 7671969		 £7.63
418 Part number 240799, PIPE CLIP PIPE CLIP
Main part no. 240799		 £5.88
419 Part number 243007BAX, WIRE G/Y SILICONE x160mm WIRE G/Y SILICONE X160MM
Main part no. 243007BAX		 £12.46
420 Part number 5107787, GAS COCK FLANGED 15MM COMPRESSION GAS COCK FLANGED 15MM COMPRESSION
Main part no. 5107787		 £13.58
420   SCREW M4 HEX POZI SPECIAL
Main part no. 5111915		 £3.10
420 Part number 401648, O RING 21.5 X 2.4 DIA. O RING 21.5 X 2.4 DIA.
Main part no. 401648		 £6.06
421 Part number 5109989, NOW USE 7672047 BUTTON RESET - BLACK NOW USE 7672047 BUTTON RESET - BLACK
Main part no. 5109989
421   BUTTON RESET BLACK
Main part no. 7672047		 £5.88
422   M5 RETAINING WASHER
Main part no. 371875		 £2.65
423 Part number 5114338, FILTER EMC CHASSIS MOUNT FILTER EMC CHASSIS MOUNT
Main part no. 5114338		 £38.51
424   PIPE - RETURN
Main part no. 5121478		 £41.57
425   SPARE FLOW PIPE ASSY (SL)
Main part no. 5121479		 £64.04
425   BRACKET SUPPORT PIPE
Main part no. 242779		 £7.91
426 Part number 241739, BOX MANIFOLD VALVE BOX MANIFOLD VALVE
Main part no. 241739		 £11.10
427 Part number 242520, O RING 15.54mm/IDx2.62 NITRILE O RING 15.54MM/IDX2.62 NITRILE
Main part no. 242520		 £3.16
428 Part number 242228, GROMMET GROMMET
Main part no. 242228		 £4.45
