MAIN
28 SYSTEM ECO ELITE - (Wall Jig & Hydraulic Connections)
Appliance Code: 41-467-22

Appliance Diagram


Wall Jig & Hydraulic Connections diagram for Main 28 System Eco EliteClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

601 Part number 248100, WALL JIG ASSEMBLY WALL JIG ASSEMBLY
Main part no. 248100
£28.54
602 Part number 248224, TAP - ISOLATION - FLOW TAP - ISOLATION - FLOW
Main part no. 248224
£33.91
603 Part number 248225, TAP - ISOLATION - RETURN TAP - ISOLATION - RETURN
Main part no. 248225
£43.27
606 Part number 248230, ELBOW - GAS INLET ELBOW - GAS INLET
Main part no. 248230
£9.51
608   CONNECTION TAIL - 22MM
Main part no. 248229
£9.51
609 Part number 248231, PIPE-DISCHARGE-SAFETY VALVE PIPE-DISCHARGE-SAFETY VALVE
Main part no. 248231
£11.95
610 Part number 247485, TAP TAP
Main part no. 247485
£19.05
612 Part number 247758, LOCK NUT - G3/4 LOCK NUT - G3/4
Main part no. 247758
£5.88
613 Part number 247744, SEALING WASHER G. 1/2 SEALING WASHER G. 1/2
Main part no. 247744
£3.16
614 Part number 247745, SEALING WASHER G. 3/4 SEALING WASHER G. 3/4
Main part no. 247745
£3.16
616 Part number 247764, RUBBER SEAL - GAS TAP RUBBER SEAL - GAS TAP
Main part no. 247764
£3.26
