MYSON
MARATHON (LATER) 500C 1997 - (Appliance Overview)
Appliance Code: 41-494-15

Appliance Diagram


Appliance Overview diagram for Myson Marathon (Later) 500C 1997Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

11 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Myson part no. 635506
17   OBSOLETE LABEL - LIGHTING INSTRUCTION
Myson part no. 305C1278
19   OBSOLETE 8 X 1/2 STEEL SCREW
Myson part no. 168S
32   OBSOLETE THERMOSTAT & HARNESS 231252
Myson part no. 305A1250
38   OBSOLETE CONTROL KNOB COMBI
Myson part no. 309S371
61   OBSOLETE GASKET 231071
Myson part no. 305C205
62   OBSOLETE STUD 231073
Myson part no. B53017
64   OBSOLETE NUT M10 231075
Myson part no. B53020
71   OBSOLETE SEALING STRIP ASSY FLUE
Myson part no. 305A592
74   OBSOLETE THERMOSTAT POCKET
Myson part no. B53736
89   OBSOLETE ROPE GASKET 1.22 METRE
Myson part no. B1078
90   OBSOLETE MOUNTING BRACKET 231098
Myson part no. 305C987
103   OBSOLETE GAS COCK 231110
Myson part no. 402S1074
106 Part number 305S244, OBSOLETE INJECTOR 231105 OBSOLETE INJECTOR 231105
Myson part no. 305S244
107   OBSOLETE BURNER INJECTOR WASHER 1 5MM 2
Myson part no. 301C247
116 Part number 402S571, OBSOLETE SPARK ELECTRODE 231111 OBSOLETE SPARK ELECTRODE 231111
Myson part no. 402S571
117   OBSOLETE SCREW
Myson part no. 11/11592
118 Part number 402S083, SPARK GENERATOR SPARK GENERATOR
Myson part no. 402S083		 £7.59
122   OBSOLETE SEALING GROMMET SPECIAL 23109
Myson part no. 305C992
127   OBSOLETE BURNER END PLATE AB20601
Myson part no. 305S431
130   OBSOLETE END PLATE GASKET
Myson part no. 305S432
133   OBSOLETE BURNER END PLATE
Myson part no. 305S777
136   GASKET
Myson part no. 305S778
136   GASKET BURNER END FOR 414572
Myson part no. 906242
137   OBSOLETE FILTER
Myson part no. 305S775
137   OBSOLETE FILTER
Myson part no. 305S776
145   OBSOLETE KNOB 231830
Myson part no. B53116
