POTTERTON
GOLD 30 FSB - (Controls)
Appliance Code: 41-592-32

Appliance Diagram


Controls diagram for Potterton Gold 30 FSBClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

401 Part number 240670, NOW USE 7671970 THERMOSTAT BOILER NOW USE 7671970 THERMOSTAT BOILER
Potterton part no. 240670

401 Part number 7671970, THERMOSTAT BOILER-240670 THERMOSTAT BOILER-240670
Potterton part no. 7671970
£13.59
402 Part number 242459, FLOW SWITCH FLOW SWITCH
Potterton part no. 242459
£49.78
403 Part number 242235, NOW USE 7671968 THERMOSTAT OVERHEAT NOW USE 7671968 THERMOSTAT OVERHEAT
Potterton part no. 242235

403 Part number 7671968, THERMOSTAT OVERHEAT-242235 THERMOSTAT OVERHEAT-242235
Potterton part no. 7671968
£20.37
404 Part number 243133, ADAPTER RETURN ASSEMBLY ADAPTER RETURN ASSEMBLY
Potterton part no. 243133
£33.69
405   SCREW M6 X 16MM HEX S/S
Potterton part no. 249614
£2.78
407 Part number 242226, SCR SET M5x15mm CAP HD SOCKET SCR SET M5X15MM CAP HD SOCKET
Potterton part no. 242226
£3.26
408 Part number 241900, VALVE MULTIFUNCTIONAL VALVE MULTIFUNCTIONAL
Potterton part no. 241900
£144.98
410 Part number 242475, 5mm PIPE - SPARES 5MM PIPE - SPARES
Potterton part no. 242475
£19.61
411 Part number 242229, GASKET GASKET
Potterton part no. 242229
£3.16
415 Part number 242493, HEAT EX. MANIFOLD HEAT EX. MANIFOLD
Potterton part no. 242493
£34.55
416 Part number 241806, PLUG DRAIN PLUG DRAIN
Potterton part no. 241806
£7.09
417 Part number 240676, NOW USE 7671969 SEAL MANIFOLD 2.62mm DIA NOW USE 7671969 SEAL MANIFOLD 2.62MM DIA
Potterton part no. 240676

417 Part number 7671969, SEAL MANIFOLD 2.62mm D-240676 SEAL MANIFOLD 2.62MM D-240676
Potterton part no. 7671969
£7.63
418 Part number 240799, PIPE CLIP PIPE CLIP
Potterton part no. 240799
£5.88
419 Part number 243007BAX, WIRE G/Y SILICONE x160mm WIRE G/Y SILICONE X160MM
Potterton part no. 243007BAX
£12.46
420 Part number 5107787, GAS COCK FLANGED 15MM COMPRESSION GAS COCK FLANGED 15MM COMPRESSION
Potterton part no. 5107787
£13.58
423 Part number 5114338, FILTER EMC CHASSIS MOUNT FILTER EMC CHASSIS MOUNT
Potterton part no. 5114338
£38.51
424 Part number 242819, NUT COMPRESSION 28MM NUT COMPRESSION 28MM
Potterton part no. 242819
£4.73
425 Part number 102218, OLIVE-28MM-CONEX OLIVE-28MM-CONEX
Potterton part no. 102218
£5.38
426   ASSY PIPE RETURN
Potterton part no. 5116648
£29.16
427   ASSY PIPE FLOW
Potterton part no. 5116646
£52.54
428   PIPE GAS
Potterton part no. 5117463
£3.27
429   FITTING COMPRESSION G 1/2
Potterton part no. 5111802
£4.45
430   OLIVE 15MM
Potterton part no. 631319
£4.03
431   P CLIP DIA 18 - BLACK
Potterton part no. 5117225
£2.72
432 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Potterton part no. 062532
£3.01
