POTTERTON
GOLD SYSTEM 28 HE A (BEFORE SERIAL NO HSA1112) - (Control Assembly)
Appliance Code: 41-592-17 BEFORE

Appliance Diagram


Control Assembly diagram for Potterton Gold System 28 HE A (Before Serial No HSA1112)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

501   ELECTRIC BOX COVER
Potterton part no. 5118383
£30.41
502 Part number 248072, PANEL - ACCESS PANEL - ACCESS
Potterton part no. 248072
£5.88
502 Part number 5118384, ACCESS PANEL ACCESS PANEL
Potterton part no. 5118384
£14.58
503 Part number 5120221, PCB SYSTEM 28 - 6 COIL PCB SYSTEM 28 - 6 COIL
Potterton part no. 5120221
£125.12
504 Part number 5118385, PRESSURE GAUGE PRESSURE GAUGE
Potterton part no. 5118385
£32.14
505 Part number 248076, COVER - INTEGRAL TIMER COVER - INTEGRAL TIMER
Potterton part no. 248076
£5.88
506   PANEL FACIA GOLD SYSTEM
Potterton part no. 720556801
£23.00
507   COVER CONTROL GOLD SYSTEM
Potterton part no. 720557001
£26.01
508 Part number 247480, TERMINAL BLOCK TERMINAL BLOCK
Potterton part no. 247480
£7.15
509 Part number 248089, NOW USE 7727139 FUSE (2A 250V) NOW USE 7727139 FUSE (2A 250V)
Potterton part no. 248089

509 Part number 720853801, NOW USE 7727139 FUSE 2A 250V IN FUSE HOLDER NOW USE 7727139 FUSE 2A 250V IN FUSE HOLDER
Potterton part no. 720853801

509 Part number 7727139, FUSE 2A 250V IN FUSEHOLDER FUSE 2A 250V IN FUSEHOLDER
Baxi part no. 7727139
£29.61
509   KIT TERMINAL BLOCK AND FUSES
Potterton part no. 7727139
£29.61
510 Part number 247481, FUSE HOLDER FUSE HOLDER
Potterton part no. 247481
£4.57
511 Part number 248095, SWITCH - SELECTOR SWITCH - SELECTOR
Potterton part no. 248095
£11.95
512 Part number 5107344, KNOB SELECTOR KNOB SELECTOR
Potterton part no. 5107344
£4.57
513 Part number 5118397, CONTROL KNOB CONTROL KNOB
Potterton part no. 5118397
£14.70
514 Part number 248194, PIN - HINGED FACIA PANEL PIN - HINGED FACIA PANEL
Potterton part no. 248194
£2.29
515 Part number 248096, DRIVE PIN - POTENTIOMETER DRIVE PIN - POTENTIOMETER
Potterton part no. 248096
£3.26
516 Part number 5114775, TERMINAL BLOCK TERMINAL BLOCK
Potterton part no. 5114775
£5.88
517 Part number 247206, KIT TIMER ELEC/MECH 24 HOUR KIT TIMER ELEC/MECH 24 HOUR
Potterton part no. 247206
£57.93
518   SCREW NO.6X20 PLAS PAN POZ SZ
Potterton part no. 5109202
£2.89
519   SCREWNO6X6.5 ABPAN POZ SN
Potterton part no. 612841
£3.05
520 Part number 062699, SCR-ST-No6x3/8 PAN HD PZ ZP SCR-ST-NO6X3/8 PAN HD PZ ZP
Potterton part no. 062699
£3.12
520 Part number 670037, NOW USE 062699 SCREWNO6X9.5 ABPAN POZ SZ NOW USE 062699 SCREWNO6X9.5 ABPAN POZ SZ
Potterton part no. 670037

521 Part number 612830, SCREW 6A X 1" LG S/T SCREW 6A X 1" LG S/T
Potterton part no. 612830
£3.12
