REMEHA-BROAG
AVANTA PLUS HEAT ONLY 18V - (Complete Assembly View)
Appliance Code: 41-288-06

Appliance Diagram


Complete Assembly View diagram for Remeha-Broag Avanta Plus Heat Only 18VClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1001 Part number 720537801, CASING FRONT 12,15,18,24,30V CASING FRONT 12,15,18,24,30V
Remeha-Broag part no. 720537801		 £101.21
1003   CONTROL PCB MOUNTING PLATE FOR 12,15,18,24,30V
Remeha-Broag part no. 720532501		 £42.49
1004 Part number 720534601, SCREW M4X16 (10 PCS) SCREW M4X16 (10 PCS)
Remeha-Broag part no. 720534601		 £12.16
1005   GROMMET 29X1MM
Remeha-Broag part no. 720533601		 £15.15
1006   WALL MOUNTING PLATE
Remeha-Broag part no. 720532401		 £40.72
1007   GASKET 096X055X4 VALVE 11-13ST
Remeha-Broag part no. 720533401		 £14.30
2001 Part number 720531101, HEAT EXCHANGER 12,15,18V HEAT EXCHANGER 12,15,18V
Remeha-Broag part no. 720531101		 £738.55
2002 Part number 720544801, HEAT EXCHANGER FRONT PLATE 24/28KW HEAT EXCHANGER FRONT PLATE 24/28KW
Remeha-Broag part no. 720544801		 £215.18
2003 Part number 720541701, BURNER 18/24/28KW BURNER 18/24/28KW
Remeha-Broag part no. 720541701		 £80.65
2004 Part number S62743, ignition/ionisation electrode IGNITION/IONISATION ELECTRODE
Remeha-Broag part no. S62743		 £36.85
2004 Part number 720481201, NOW USE S62743 ELECTRODE IGNITION/IONISATION C/W LEAD NOW USE S62743 ELECTRODE IGNITION/IONISATION C/W LEAD
Remeha-Broag part no. 720481201
2005   GLASS INSPECTION SET
Baxi part no. S59118		 £42.99
2005 Part number 720537401, NOW USE S59118 GLASS INSPECTION SET NOW USE S59118 GLASS INSPECTION SET
Remeha-Broag part no. 720537401
2006 Part number 7219281, INSULATION BURNER FRONT PLATE INSULATION BURNER FRONT PLATE
Remeha-Broag part no. 7219281		 £81.18
2006 Part number 720557701, NOW USE 7219281 INSULATION BURNER FRONT PLATE NOW USE 7219281 INSULATION BURNER FRONT PLATE
Remeha-Broag part no. 720557701
2007 Part number 720538001, FLUE GAS PIPE 60/100 FLUE GAS PIPE 60/100
Remeha-Broag part no. 720538001		 £27.71
2008 Part number S62232, Screw cap flue gas measure point (5 pcs) Quinta PRO SCREW CAP FLUE GAS MEASURE POINT (5 PCS) QUINTA PRO
Remeha-Commercial part no. S62232		 £42.29
2008 Part number 720538801, NOW USE S62232 SCREW CAP FLUE GAS MEASURE POINT (5 PCS) NOW USE S62232 SCREW CAP FLUE GAS MEASURE POINT (5 PCS)
Remeha-Broag part no. 720538801
2009 Part number 720538701, SEAL 257X120X7 (5PCS) SEAL 257X120X7 (5PCS)
Remeha-Broag part no. 720538701		 £57.14
2010   GASKET FOR COVER PLATE HEAT EXCHANGER (10 PCS)
Remeha-Broag part no. 720538401		 £68.79
2011 Part number S62719, GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS.) GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS.)
Remeha-Broag part no. S62719		 £41.18
2011 Part number 720540201, NOW USE S62719 GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS) NOW USE S62719 GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS)
Remeha-Broag part no. 720540201
2012 Part number 720480101, GASKET FOR BURNER (5 PCS) GASKET FOR BURNER (5 PCS)
Remeha-Broag part no. 720480101		 £37.95
2013 Part number S62718, O-RING 94 X 2 (10 PCS.) O-RING 94 X 2 (10 PCS.)
Remeha-Broag part no. S62718		 £25.93
2013 Part number 720540101, NOW USE S62718 O RING 94X2 (10 PCS) NOW USE S62718 O RING 94X2 (10 PCS)
Remeha-Broag part no. 720540101
2015 Part number S48950, Screw M4x10 (50 pcs.) SCREW M4X10 (50 PCS.)
Remeha-Commercial part no. S48950		 £20.34
2015 Part number 720535301, NOW USE S48950 SCREW M4X10 (50 PCS) NOW USE S48950 SCREW M4X10 (50 PCS)
Remeha-Broag part no. 720535301
2017 Part number S62105, Gasket for electrode (10 pcs.) GASKET FOR ELECTRODE (10 PCS.)
Remeha-Commercial part no. S62105		 £33.22
2017 Part number 720538601, NOW USE S62105 GASKET FOR ELECTRODE (10 PCS) NOW USE S62105 GASKET FOR ELECTRODE (10 PCS)
Remeha-Broag part no. 720538601
2018 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483		 £20.05
2018 Part number 720534901, NOW USE S44483 NUT M8 (10 PCS) NOW USE S44483 NUT M8 (10 PCS)
Remeha-Broag part no. 720534901
2019   GAS/AIR CHAMBER
Remeha-Broag part no. S100013		 £69.83
2019   NOW USE S100013 GAS/AIR CHAMBER
Remeha-Broag part no. 720531601
2020 Part number 720539001, SEALING RING SYPHON SEALING RING SYPHON
Remeha-Broag part no. 720539001		 £32.94
2021 Part number S100015, SYPHON CONDENSE ASSEMBLY SYPHON CONDENSE ASSEMBLY
Remeha-Broag part no. S100015		 £38.80
2021 Part number 720531701, NOW USE S100015 SYPHON CONDENSE ASSEMBLY NOW USE S100015 SYPHON CONDENSE ASSEMBLY
Remeha-Broag part no. 720531701
2023 Part number 720480501, SENSOR TEMPERATURE (2 PCS) SENSOR TEMPERATURE (2 PCS)
Remeha-Broag part no. 720480501		 £55.07
2024 Part number 720538501, O RING (10 PCS) O RING (10 PCS)
Remeha-Broag part no. 720538501		 £16.98
2025 Part number 720538301, HAIRPIN SPRING (10 PCS) HAIRPIN SPRING (10 PCS)
Remeha-Broag part no. 720538301		 £29.57
2026 Part number S54755, FLANGE NUT M6 FLANGE NUT M6
Remeha-Commercial part no. S54755		 £29.29
2026 Part number 720535501, NOW USE S54755 NUT FLANGE M6 (20 PCS) NOW USE S54755 NUT FLANGE M6 (20 PCS)
Remeha-Broag part no. 720535501
2027   PIPING SET HYDRAULIC
Remeha-Broag part no. 720533101		 £229.87
2028   NUT FOR RETURN CONNECTION 1/8"X10.5 (2 PCS)
Remeha-Broag part no. 720532701		 £24.88
2029 Part number S62742, COVER PLATE FOR BURNER COVER PLATE FOR BURNER
Remeha-Broag part no. S62742		 £40.28
2029 Part number 720541801, NOW USE S62742 COVER PLATE FOR BURNER NOW USE S62742 COVER PLATE FOR BURNER
Remeha-Broag part no. 720541801
2030 Part number S62233, CAP CAP
Remeha-Commercial part no. S62233		 £33.22
2030 Part number 720538901, NOW USE S62233 CAP MEASURE POINT AIR INLET (5 PCS) NOW USE S62233 CAP MEASURE POINT AIR INLET (5 PCS)
Remeha-Broag part no. 720538901
3001 Part number 720480001, FAN 24V FAN 24V
Remeha-Broag part no. 720480001		 £252.61
3003   AIR SUPPLY SILENCER
Remeha-Broag part no. 720535901		 £48.03
3006 Part number 720535001, NOW USE S45182 GASKET FOR FLUE FAN (10 PCS) NOW USE S45182 GASKET FOR FLUE FAN (10 PCS)
Remeha-Broag part no. 720535001
3006 Part number S45182, Gasket for flue fan (10 pcs.) GASKET FOR FLUE FAN (10 PCS.)
Remeha-Commercial part no. S45182
3008 Part number 720536301, O RING 63 X 3 (10 PCS) O RING 63 X 3 (10 PCS)
Remeha-Broag part no. 720536301		 £23.41
3011 Part number 720537901, SCREW M6X12 (15 PCS) SCREW M6X12 (15 PCS)
Remeha-Broag part no. 720537901		 £13.56
3012 Part number S56155, Gasket 23.8 x 17.2 (20pc) GASKET 23.8 X 17.2 (20PC)
Remeha-Commercial part no. S56155		 £34.18
3012 Part number 720535601, NOW USE S56155 GASKET 23.8mm O/D X 17.2mm I/D X 2mm (20 PCS) NOW USE S56155 GASKET 23.8MM O/D X 17.2MM I/D X 2MM (20 PCS)
Remeha-Broag part no. 720535601
3015 Part number S62752, GAS COCK GAS COCK
Remeha-Broag part no. S62752		 £27.84
3015 Part number 720542201, NOW USE S62752 GAS COCK NOW USE S62752 GAS COCK
Remeha-Broag part no. 720542201
4001 Part number 7225198, CONTROL BOARD ERP CONTROL BOARD ERP
Remeha-Broag part no. 7225198		 £245.43
4001 Part number 720480201, NOW USE 7225198 CONTROL BOARD NOW USE 7225198 CONTROL BOARD
Remeha-Broag part no. 720480201
4002 Part number 720480601, PCB DISPLAY PCB DISPLAY
Remeha-Broag part no. 720480601		 £90.46
4003 Part number S62750, TRANSFORMER IGNITION (NO LEAD OR PROBE) TRANSFORMER IGNITION (NO LEAD OR PROBE)
Remeha-Commercial part no. S62750		 £44.09
4003 Part number 720481501, NOW USE S62750 TRANSFORMER IGNITION (NO LEAD OR PROBE) NOW USE S62750 TRANSFORMER IGNITION (NO LEAD OR PROBE)
Remeha-Broag part no. 720481501
4004   CABLE SET
Remeha-Broag part no. 720532201		 £112.77
4005   COVER FOR CONTROL PCB 18V
Remeha-Broag part no. 720532301		 £33.27
4006 Part number S43561, Fuses glass 2 Amp Slow Pack of 10 FUSES GLASS 2 AMP SLOW PACK OF 10
Remeha-Commercial part no. S43561		 £35.79
4006 Part number 720480301, NOW USE S43561 FUSE GLASS 2 AMP SLOW (10 PCS) NOW USE S43561 FUSE GLASS 2 AMP SLOW (10 PCS)
Remeha-Broag part no. 720480301
4007 Part number S62710, SCREW K3,5X10 (50 PCS.) SCREW K3,5X10 (50 PCS.)
Remeha-Broag part no. S62710		 £18.93
4007 Part number 720539501, NOW USE S62710 SCREW K3.5X10 (50 PCS) NOW USE S62710 SCREW K3.5X10 (50 PCS)
Remeha-Broag part no. 720539501
4009   NUT CLAMP M5 (10 PCS)
Remeha-Broag part no. 720537201		 £18.02
4010   SCREW M5X16 INC WASHER (10 PCS)
Remeha-Broag part no. 720535401		 £25.63
4011 Part number 720534601, SCREW M4X16 (10 PCS) SCREW M4X16 (10 PCS)
Remeha-Broag part no. 720534601		 £12.16
4012 Part number 720538101, CABLE CLAMP CABLE CLAMP
Remeha-Broag part no. 720538101		 £15.87
4012 Part number S14254, Sheet-metal screw 4,2x9,5 (20 pcs.) SHEET-METAL SCREW 4,2X9,5 (20 PCS.)
Remeha-Commercial part no. S14254		 £12.67
4012 Part number 720534501, NOW USE S14254 SHEET METAL SCREW 4.2X9.5 (20 PCS) NOW USE S14254 SHEET METAL SCREW 4.2X9.5 (20 PCS)
Remeha-Broag part no. 720534501
