REMEHA-BROAG
AVANTA PLUS HEAT ONLY 18V - (Complete Assembly View)
Appliance Code: 41-288-06

Appliance Diagram


Complete Assembly View diagram for Remeha-Broag Avanta Plus Heat Only 18VClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1001 Part number 720537801, CASING FRONT 12,15,18,24,30V CASING FRONT 12,15,18,24,30V
Remeha-Broag part no. 720537801
£98.26
1003   CONTROL PCB MOUNTING PLATE FOR 12,15,18,24,30V
Remeha-Broag part no. 720532501
£41.25
1004 Part number 720534601, SCREW M4X16 (10 PCS) SCREW M4X16 (10 PCS)
Remeha-Broag part no. 720534601
£11.80
1005   GROMMET 29X1MM
Remeha-Broag part no. 720533601
£14.71
1006   WALL MOUNTING PLATE
Remeha-Broag part no. 720532401
£39.53
1007   GASKET 096X055X4 VALVE 11-13ST
Remeha-Broag part no. 720533401
£14.30
2001 Part number 720531101, HEAT EXCHANGER 12,15,18V HEAT EXCHANGER 12,15,18V
Remeha-Broag part no. 720531101
£717.04
2002 Part number 720544801, HEAT EXCHANGER FRONT PLATE 24/28KW HEAT EXCHANGER FRONT PLATE 24/28KW
Remeha-Broag part no. 720544801
£208.92
2003 Part number 720541701, BURNER 18/24/28KW BURNER 18/24/28KW
Remeha-Broag part no. 720541701
£78.30
2004 Part number 720481201, NOW USE S62743 ELECTRODE IGNITION/IONISATION C/W LEAD NOW USE S62743 ELECTRODE IGNITION/IONISATION C/W LEAD
Remeha-Broag part no. 720481201

2004 Part number S62743, ignition/ionisation electrode IGNITION/IONISATION ELECTRODE
Remeha-Broag part no. S62743
£35.78
2005   GLASS INSPECTION SET
Baxi part no. S59118
£42.99
2005 Part number 720537401, NOW USE S59118 GLASS INSPECTION SET NOW USE S59118 GLASS INSPECTION SET
Remeha-Broag part no. 720537401

2006 Part number 720557701, NOW USE 7219281 INSULATION BURNER FRONT PLATE NOW USE 7219281 INSULATION BURNER FRONT PLATE
Remeha-Broag part no. 720557701

2006 Part number 7219281, INSULATION BURNER FRONT PLATE INSULATION BURNER FRONT PLATE
Remeha-Broag part no. 7219281
£78.82
2007 Part number 720538001, FLUE GAS PIPE 60/100 FLUE GAS PIPE 60/100
Remeha-Broag part no. 720538001
£26.90
2008 Part number 720538801, NOW USE S62232 SCREW CAP FLUE GAS MEASURE POINT (5 PCS) NOW USE S62232 SCREW CAP FLUE GAS MEASURE POINT (5 PCS)
Remeha-Broag part no. 720538801

2008 Part number S62232, Screw cap flue gas measure point (5 pcs) Quinta PRO SCREW CAP FLUE GAS MEASURE POINT (5 PCS) QUINTA PRO
Remeha-Commercial part no. S62232
£36.90
2009 Part number 720538701, SEAL 257X120X7 (5PCS) SEAL 257X120X7 (5PCS)
Remeha-Broag part no. 720538701
£55.47
2010   GASKET FOR COVER PLATE HEAT EXCHANGER (10 PCS)
Remeha-Broag part no. 720538401
£66.79
2011 Part number 720540201, NOW USE S62719 GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS) NOW USE S62719 GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS)
Remeha-Broag part no. 720540201

2011 Part number S62719, GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS.) GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS.)
Remeha-Broag part no. S62719
£39.98
2012 Part number 720480101, GASKET FOR BURNER (5 PCS) GASKET FOR BURNER (5 PCS)
Remeha-Broag part no. 720480101
£36.85
2013 Part number 720540101, NOW USE S62718 O RING 94X2 (10 PCS) NOW USE S62718 O RING 94X2 (10 PCS)
Remeha-Broag part no. 720540101

2013 Part number S62718, O-RING 94 X 2 (10 PCS.) O-RING 94 X 2 (10 PCS.)
Remeha-Broag part no. S62718
£25.18
2015 Part number 720535301, NOW USE S48950 SCREW M4X10 (50 PCS) NOW USE S48950 SCREW M4X10 (50 PCS)
Remeha-Broag part no. 720535301

2015 Part number S48950, Screw M4x10 (50 pcs.) SCREW M4X10 (50 PCS.)
Remeha-Commercial part no. S48950
£17.74
2017 Part number 720538601, NOW USE S62105 GASKET FOR ELECTRODE (10 PCS) NOW USE S62105 GASKET FOR ELECTRODE (10 PCS)
Remeha-Broag part no. 720538601

2017 Part number S62105, Gasket for electrode (10 pcs.) GASKET FOR ELECTRODE (10 PCS.)
Remeha-Commercial part no. S62105
£28.98
2018 Part number 720534901, NOW USE S44483 NUT M8 (10 PCS) NOW USE S44483 NUT M8 (10 PCS)
Remeha-Broag part no. 720534901

2018 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483
£17.49
2019   NOW USE S100013 GAS/AIR CHAMBER
Remeha-Broag part no. 720531601

2019   GAS/AIR CHAMBER
Remeha-Broag part no. S100013
£67.80
2020 Part number 720539001, SEALING RING SYPHON SEALING RING SYPHON
Remeha-Broag part no. 720539001
£31.98
2021 Part number 720531701, NOW USE S100015 SYPHON CONDENSE ASSEMBLY NOW USE S100015 SYPHON CONDENSE ASSEMBLY
Remeha-Broag part no. 720531701

2021 Part number S100015, SYPHON CONDENSE ASSEMBLY SYPHON CONDENSE ASSEMBLY
Remeha-Broag part no. S100015
£37.67
2023 Part number 720480501, SENSOR TEMPERATURE (2 PCS) SENSOR TEMPERATURE (2 PCS)
Remeha-Broag part no. 720480501
£53.47
2024 Part number 720538501, O RING (10 PCS) O RING (10 PCS)
Remeha-Broag part no. 720538501
£16.49
2025 Part number 720538301, HAIRPIN SPRING (10 PCS) HAIRPIN SPRING (10 PCS)
Remeha-Broag part no. 720538301
£28.71
2026 Part number 720535501, NOW USE S54755 NUT FLANGE M6 (20 PCS) NOW USE S54755 NUT FLANGE M6 (20 PCS)
Remeha-Broag part no. 720535501

2026 Part number S54755, FLANGE NUT M6 FLANGE NUT M6
Remeha-Commercial part no. S54755
£25.55
2027   PIPING SET HYDRAULIC
Remeha-Broag part no. 720533101
£223.17
2028   NUT FOR RETURN CONNECTION 1/8"X10.5 (2 PCS)
Remeha-Broag part no. 720532701
£24.15
2029 Part number 720541801, NOW USE S62742 COVER PLATE FOR BURNER NOW USE S62742 COVER PLATE FOR BURNER
Remeha-Broag part no. 720541801

2029 Part number S62742, COVER PLATE FOR BURNER COVER PLATE FOR BURNER
Remeha-Broag part no. S62742
£39.11
2030 Part number 720538901, NOW USE S62233 CAP MEASURE POINT AIR INLET (5 PCS) NOW USE S62233 CAP MEASURE POINT AIR INLET (5 PCS)
Remeha-Broag part no. 720538901

2030 Part number S62233, CAP CAP
Remeha-Commercial part no. S62233
£28.98
3001 Part number 720480001, FAN 24V FAN 24V
Remeha-Broag part no. 720480001
£245.25
3003   AIR SUPPLY SILENCER
Remeha-Broag part no. 720535901
£46.63
3006 Part number 720535001, NOW USE S45182 GASKET FOR FLUE FAN (10 PCS) NOW USE S45182 GASKET FOR FLUE FAN (10 PCS)
Remeha-Broag part no. 720535001

3006 Part number S45182, Gasket for flue fan (10 pcs.) GASKET FOR FLUE FAN (10 PCS.)
Remeha-Commercial part no. S45182
£24.33
3008 Part number 720536301, O RING 63 X 3 (10 PCS) O RING 63 X 3 (10 PCS)
Remeha-Broag part no. 720536301
£22.73
3011 Part number 720537901, SCREW M6X12 (15 PCS) SCREW M6X12 (15 PCS)
Remeha-Broag part no. 720537901
£13.17
3012 Part number 720535601, NOW USE S56155 GASKET 23.8MM O/D X 17.2MM I/D X 2MM (20 PCS) NOW USE S56155 GASKET 23.8MM O/D X 17.2MM I/D X 2MM (20 PCS)
Remeha-Broag part no. 720535601

3012 Part number S56155, Gasket 23.8 x 17.2 (20pc) GASKET 23.8 X 17.2 (20PC)
Remeha-Commercial part no. S56155
£29.81
3015 Part number 720542201, NOW USE S62752 GAS COCK NOW USE S62752 GAS COCK
Remeha-Broag part no. 720542201

3015 Part number S62752, GAS COCK GAS COCK
Remeha-Broag part no. S62752
£27.84
4001 Part number 720480201, NOW USE 7225198 CONTROL BOARD NOW USE 7225198 CONTROL BOARD
Remeha-Broag part no. 720480201

4001 Part number 7225198, CONTROL BOARD ERP CONTROL BOARD ERP
Remeha-Broag part no. 7225198
£233.85
4002 Part number 720480601, PCB DISPLAY PCB DISPLAY
Remeha-Broag part no. 720480601
£87.83
4003 Part number 720481501, NOW USE S62750 TRANSFORMER IGNITION (NO LEAD OR PROBE) NOW USE S62750 TRANSFORMER IGNITION (NO LEAD OR PROBE)
Remeha-Broag part no. 720481501

4003 Part number S62750, TRANSFORMER IGNITION (NO LEAD OR PROBE) TRANSFORMER IGNITION (NO LEAD OR PROBE)
Remeha-Commercial part no. S62750
£44.09
4004   CABLE SET
Remeha-Broag part no. 720532201
£109.49
4005   COVER FOR CONTROL PCB 18V
Remeha-Broag part no. 720532301
£32.30
4006 Part number 720480301, NOW USE S43561 FUSE GLASS 2 AMP SLOW (10 PCS) NOW USE S43561 FUSE GLASS 2 AMP SLOW (10 PCS)
Remeha-Broag part no. 720480301

4006 Part number S43561, Fuses glass 2 Amp Slow Pack of 10 FUSES GLASS 2 AMP SLOW PACK OF 10
Remeha-Commercial part no. S43561
£31.23
4007 Part number 720539501, NOW USE S62710 SCREW K3.5X10 (50 PCS) NOW USE S62710 SCREW K3.5X10 (50 PCS)
Remeha-Broag part no. 720539501

4007 Part number S62710, SCREW K3,5X10 (50 PCS.) SCREW K3,5X10 (50 PCS.)
Remeha-Broag part no. S62710
£18.39
4009   NUT CLAMP M5 (10 PCS)
Remeha-Broag part no. 720537201
£17.50
4010   SCREW M5X16 INC WASHER (10 PCS)
Remeha-Broag part no. 720535401
£24.89
4011 Part number 720534601, SCREW M4X16 (10 PCS) SCREW M4X16 (10 PCS)
Remeha-Broag part no. 720534601
£11.80
4012 Part number 720534501, NOW USE S14254 SHEET METAL SCREW 4.2X9.5 (20 PCS) NOW USE S14254 SHEET METAL SCREW 4.2X9.5 (20 PCS)
Remeha-Broag part no. 720534501

4012 Part number 720538101, CABLE CLAMP CABLE CLAMP
Remeha-Broag part no. 720538101
£15.40
4012 Part number S14254, Sheet-metal screw 4,2x9,5 (20 pcs.) SHEET-METAL SCREW 4,2X9,5 (20 PCS.)
Remeha-Commercial part no. S14254
£11.05
