VOKERA
SABRE 25 HE PLUS (OLD VERSION PRE 2007) REV 2 (03/07) - (Combustion Chamber)

Appliance Diagram


Combustion Chamber diagram for Vokera Sabre 25 HE Plus (Old Version Pre 2007) Rev 2 (03/07)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 10025935, Combustion chamber COMBUSTION CHAMBER
Vokera part no. 10025935
£14.10
2 Part number 5270, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5270
£12.97
3 Part number 5271, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5271
£8.46
4 Part number 5269, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5269
£12.97
7   HOOD ASSEMBLY
Vokera part no. 10025934

10 Part number 10025938, Fan FAN
Vokera part no. 10025938
£158.86
16 Part number 10024126, Clamp CLAMP
Vokera part no. 10024126
£16.69
19 Part number 10024137, Fan flue connection FAN FLUE CONNECTION
Vokera part no. 10024137
£33.61
20 Part number 10026933, Block with combustion analysis check BLOCK WITH COMBUSTION ANALYSIS CHECK
Vokera part no. 10026933
£8.37
23 Part number 8086, Brass Cap BRASS CAP
Vokera part no. 8086
£2.22
25 Part number 2677, Air Pressure Switch AIR PRESSURE SWITCH
Vokera part no. 2677
£58.75
100   COMBUSTION CABLE
Vokera part no. 10029426
£48.38
