GLOWWORM
XTRAMAX HE - (11 Pipes)
Appliance Code: 47-047-29

Appliance Diagram


11 Pipes diagram for Glowworm Xtramax HEClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

123 Part number 05459300, O-Ring (PK20) O-RING (PK20)
Glowworm part no. 05459300
£11.00
124 Part number 0020015130, Clip (PK5) CLIP (PK5)
Glowworm part no. 0020015130
£52.94
125   GASKET
Glowworm part no. 0020018548
£6.23
126   NOW USE S1075600 BYPASS PIPE
Glowworm part no. 0020018580

126 Part number S1075600, Pipe bypass PIPE BYPASS
Glowworm part no. S1075600
£8.93
127   NOW USE S1076200 INLET TANK PIPE
Glowworm part no. 0020018594

127 Part number S1076200, Pipe, inlet tank PIPE, INLET TANK
Glowworm part no. S1076200
£13.58
128   NOW USE S1076300 OUTLET TANK PIPE
Glowworm part no. 0020018595

128 Part number S1076300, Pipe, outlet tank PIPE, OUTLET TANK
Glowworm part no. S1076300
£18.06
129   NOW USE S1076400 GAZ PIPE
Glowworm part no. 0020018596

129 Part number S1076400, Pipe, gas PIPE, GAS
Glowworm part no. S1076400
£48.77
130   NOW USE S1076500 PUMP / HEAT EXCHANGER PIPE
Glowworm part no. 0020018597

130 Part number S1076500, Pipe Pump/Heat exchanger PIPE PUMP/HEAT EXCHANGER
Glowworm part no. S1076500
£38.63
131 Part number 0020018598, NOW USE S1076600 3WV / Heat exchanger pipe NOW USE S1076600 3WV / HEAT EXCHANGER PIPE
Glowworm part no. 0020018598

131 Part number S1076600, Pipe heat Exchanger/ 3Wv PIPE HEAT EXCHANGER/ 3WV
Glowworm part no. S1076600
£62.08
132   NOW USE S1076800 PUMP PIPE
Glowworm part no. 0020018600

132 Part number S1076800, Telescopic pipe TELESCOPIC PIPE
Glowworm part no. S1076800
£19.40
133   CONNECTOR GAS PIPE
Glowworm part no. 0020018604
£46.49
134 Part number 2000801883, Sealing ring 3/4 (PK10) SEALING RING 3/4 (PK10)
Glowworm part no. 2000801883
£29.16
135 Part number 2000801885, NOW USE S5496800 o-ring heat exchanger/pipe (50 pcs.) NOW USE S5496800 O-RING HEAT EXCHANGER/PIPE (50 PCS.)
Glowworm part no. 2000801885

135 Part number S5496800, O-Ring (PK50) O-RING (PK50)
Glowworm part no. S5496800
£16.08
136 Part number 2000801953, NOW USE S5466400 o-ring 13mm cv-filter (20 pieces) NOW USE S5466400 O-RING 13MM CV-FILTER (20 PIECES)
Glowworm part no. 2000801953

136 Part number S5466400, O-Ring (PK20) O-RING (PK20)
Glowworm part no. S5466400
£16.51
137 Part number 2000801954, NOW USE S5466500 o-ring (20 pieces) NOW USE S5466500 O-RING (20 PIECES)
Glowworm part no. 2000801954

137 Part number S5466500, O-ring (PK20) O-RING (PK20)
Glowworm part no. S5466500
£14.93
138 Part number A000035169, O-ring d=18mm gas connection (PK10) O-RING D=18MM GAS CONNECTION (PK10)
Glowworm part no. A000035169
£12.41
