GAS 550 & 550 DUO - (Exploded View)

Appliance Diagram


Exploded View diagram for Remeha-Commercial Gas 550 & 550 DuoClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   CLEANING BRUSH BOILER
Remeha-Broag part no. 4532
£39.54
2   (USE 57262) SEALANT DENSITOL -+ KG
Remeha-Broag part no. 2879

2   SEALANT DENSITOL -+ KG
Remeha-Commercial part no. 57262
£23.75
3   GLUE SOLIDIN 300CC
Remeha-Commercial part no. 49112
£18.75
4   SEAL NIPPLE JOINTING COMPOUND 125CC (RED LEAD)
Remeha-Commercial part no. 51279
£26.25
5 Part number S25786, Electrode water level control dungs -¢" ELECTRODE WATER LEVEL CONTROL DUNGS -¢"
Remeha-Commercial part no. S25786
£145.00
6   HOOK FOR TIE ROD
Remeha-Commercial part no. 1284
£7.49
7   FLANGE BLANK
Remeha-Commercial part no. 4270
£67.50
7   FLANGE DRILLED -¢"+M6
Remeha-Broag part no. 7705
£112.84
8 Part number S4407, Gasket set F/R GASKET SET F/R
Remeha-Commercial part no. S4407
£40.00
9   SECTION LEFT HAND END GAS 550, 5A & 5C
Remeha-Commercial part no. 44081
£2,142.50
10   NIPPLE
Remeha-Commercial part no. 29904
£73.75
11   SECTION INTERMEDIATE GAS 550, 5A & 5C
Remeha-Commercial part no. 52776
£1,131.25
12   SEAL WHITE CERAMIC ROPE 16MM
Remeha-Broag part no. 54717
£18.50
13   SECTION RIGHT HAND END GAS 550, 5A & 5C
Remeha-Commercial part no. 44083
£2,142.50
14   INSULATION RADIATION PANEL 454X38X980MM (TO AFFIX USE SOLIDIN GLUE)
Remeha-Commercial part no. 53283
£93.75
15 Part number 53874, (USE S101033) Gasket flue cover (USE S101033) GASKET FLUE COVER
Remeha-Broag part no. 53874

15 Part number S101033, Gasket Flue Cover (10pcs) GASKET FLUE COVER (10PCS)
Remeha-Commercial part no. S101033
£60.00
16   INJECTOR (PILOT) FOR AZ5 D=1.0
Remeha-Commercial part no. 35166
£16.25
17   THERMOSTAT POCKET 437MM
Remeha-Commercial part no. 39850
£620.00
18   FLANGE D=100
Remeha-Commercial part no. 44114
£111.25
19 Part number S41325, Electrode Ionisation az-5 3d/5c/550 ELECTRODE IONISATION AZ-5 3D/5C/550
Remeha-Commercial part no. S41325
£46.25
20 Part number S13102, Plug cap black hooked M6.3 plain pin PLUG CAP BLACK HOOKED M6.3 PLAIN PIN
Remeha-Commercial part no. S13102
£23.75
21 Part number 26325, Plug cap brown M4 threaded pin +1k for Ignition electrode PLUG CAP BROWN M4 THREADED PIN +1K FOR IGNITION ELECTRODE
Remeha-Commercial part no. 26325
£12.50
22 Part number S45537, OBSOLETE Pilot burner assembly az-5 with 1mm injector OBSOLETE PILOT BURNER ASSEMBLY AZ-5 WITH 1MM INJECTOR
Remeha-Commercial part no. S45537
£547.50
23 Part number S23033, Electrode Ignition az-5 ELECTRODE IGNITION AZ-5
Remeha-Commercial part no. S23033
£58.75
24   GASKET FOR INJECTOR -¢"
Remeha-Commercial part no. 42148
£0.44
25   INJECTOR BURNER -¢" D=5.40
Remeha-Commercial part no. 14777
£32.50
26   BURNER RETAINING CLIPS (PACK OF 4)
Remeha-Commercial part no. 33318
£7.20
27   FLOOR PLATE CLIP
Remeha-Commercial part no. 19717
£1.44
28   SIGHT GLASS MICA GLASS D=40
Remeha-Commercial part no. 1301
£4.19
29   BURNER BAR (3 PCS) FURIGAS - PURCHASE ONLY
Remeha-Commercial part no. 52766
£266.25
29 Part number 52767, Burner bar (4 pcs) furigas - PURCHASE ONLY BURNER BAR (4 PCS) FURIGAS - PURCHASE ONLY
Remeha-Commercial part no. 52767
£347.50
29 Part number S52558, Burner bar (1 pcs) furigas BURNER BAR (1 PCS) FURIGAS
Remeha-Commercial part no. S52558
£93.75
30   RETURN WATER DISTRIBUTION PIPE 10 SECTION
Remeha-Commercial part no. 40082
£690.00
30   RETURN WATER DISTRIBUTION PIPE 12 SECTION
Remeha-Commercial part no. 40084
£696.25
30   RETURN WATER DISTRIBUTION PIPE 14 SECTION
Remeha-Commercial part no. 40086
£537.50
30   RETURN WATER DISTRIBUTION PIPE 16 SECTION
Remeha-Commercial part no. 40088
£1,451.25
30   RETURN WATER DISTRIBUTION PIPE 18 SECTION
Remeha-Commercial part no. 40089
£1,212.50
30   RETURN WATER DISTRIBUTION PIPE 20 SECTION
Remeha-Commercial part no. 40090
£405.00
30   RETURN WATER DISTRIBUTION PIPE 22 SECTION
Remeha-Commercial part no. 40091
£518.75
31 Part number 43799, (USE S43799) Door snapper male (USE S43799) DOOR SNAPPER MALE
Remeha-Broag part no. 43799

31 Part number S43799, Door Snapper Male (10 pcs) DOOR SNAPPER MALE (10 PCS)
Remeha-Commercial part no. S43799
£15.00
32 Part number 43798, Door snapper female (NEW PART NO. S43798) DOOR SNAPPER FEMALE (NEW PART NO. S43798)
Remeha-Broag part no. 43798

32 Part number S43798, Door Snapper Female (10 pcs) DOOR SNAPPER FEMALE (10 PCS)
Remeha-Commercial part no. S43798
£18.75
33 Part number S55503, Pilot Solenoid Valve - Gas 350/450 PILOT SOLENOID VALVE - GAS 350/450
Remeha-Commercial part no. S55503
£82.50
34 Part number 19609, Pressure test nipple -+ PRESSURE TEST NIPPLE -+
Remeha-Commercial part no. 19609
£63.75
35 Part number S38298, Control box Satronic MMI 816 mod. 10 CONTROL BOX SATRONIC MMI 816 MOD. 10
Remeha-Commercial part no. S38298
£473.75
36   BASE PLATE FOR CONTROL PANEL
Remeha-Commercial part no. S36629
£68.75
37 Part number 1035, (USE S103279) Pressure test nipple 1/8 (USE S103279) PRESSURE TEST NIPPLE 1/8
Remeha-Broag part no. 1035

37 Part number S103279, Pressure Test Nipple 1/8" Incl Loctite PRESSURE TEST NIPPLE 1/8" INCL LOCTITE
Remeha-Commercial part no. S103279
£25.00
38 Part number S39223, PCB alarm board (r3ca52) PCB ALARM BOARD (R3CA52)
Remeha-Commercial part no. S39223
£250.00
39 Part number S48255, Transformer Ignition satronic zt 870 TRANSFORMER IGNITION SATRONIC ZT 870
Remeha-Commercial part no. S48255
£132.50
40 Part number S36953, Pressure switch gas -+" PRESSURE SWITCH GAS -+"
Remeha-Commercial part no. S36953
£143.75
41   IGNITION CABLE COMPLETE L=1000
Remeha-Commercial part no. 56603
£126.25
42   FLANGE MB 420
Remeha-Commercial part no. 53494
£163.75
43   VALVE MULTI BLOCK
Remeha-Broag part no. 53491
£1,440.87
43   VALVE MULTI BLOCK
Remeha-Broag part no. 53492
£1,822.80
44 Part number S38488, Water level device dungs WATER LEVEL DEVICE DUNGS
Remeha-Commercial part no. S38488
£623.75
45   MODULE SIMPLE
Remeha-Commercial part no. S52177
£143.75
46 Part number S46634, Thermostat control & H/L 35-95 degrees THERMOSTAT CONTROL & H/L 35-95 DEGREES
Remeha-Commercial part no. S46634
£40.00
47   BUTTON LOCKOUT RE-SET
Remeha-Commercial part no. 51196
£22.50
48   SWITCH ON/OFF 40C1350AL
Remeha-Commercial part no. S51393
£11.39
49   OBSOLETE KNOB FOR CONTROL THERMOSTAT
Remeha-Broag part no. 51098

50   KNOB FOR HIGH/LOW THERMOSTAT
Remeha-Commercial part no. 51099
£10.08
51 Part number S45309, Thermometer water temperature 0-120 THERMOMETER WATER TEMPERATURE 0-120
Remeha-Commercial part no. S45309
£43.75
52 Part number S36446, Thermostat TEM high limit 110 C l&g rak 77.4471 THERMOSTAT TEM HIGH LIMIT 110 C L&G RAK 77.4471
Remeha-Commercial part no. S36446
£78.75
