REMEHA-COMMERCIAL
P200 - (Exploded View)

Appliance Diagram


Exploded View diagram for Remeha-Commercial P200Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   THERMOSTAT POCKET L=280 (FOR THE 2 CONTROL STATS & THERMOMETER)
Remeha-Commercial part no. 35154
£73.75
0 Part number S27573, Thermostat control & H./L l&g rak 12.0012 THERMOSTAT CONTROL & H./L L&G RAK 12.0012
Remeha-Commercial part no. S27573
£387.50
0 Part number S32147, Thermostat high limit (ECO) 110 C l&g rak 113.1032 THERMOSTAT HIGH LIMIT (ECO) 110 C L&G RAK 113.1032
Remeha-Commercial part no. S32147
£412.50
1   DRAIN COCK
Remeha-Commercial part no. 1389
£52.50
2   DRAIN OFF COCK HANDLE
Remeha-Broag part no. 8993
£4.24
3 Part number 45783, Cleaning brush D=30mm CLEANING BRUSH D=30MM
Remeha-Commercial part no. 45783
£22.50
4   CLEANING BRUSH D=80MM
Remeha-Commercial part no. 45784
£38.75
5   (USE S45785) CLEANING BRUSH EXTENSION PIECE
Remeha-Broag part no. 45785

5   CLEANING BRUSH EXTENSION PIECE
Remeha-Commercial part no. S45785
£37.50
6   HAND GRIP CLEANING BRUSH
Remeha-Commercial part no. 45786
£70.00
7   GASKET OVAL X 45MM ID
Remeha-Commercial part no. 20903
£17.50
8 Part number S4405, Gasket set F/R GASKET SET F/R
Remeha-Commercial part no. S4405
£30.00
10   SEAL WHITE CERAMIC ROPE 10MM
Remeha-Broag part no. 54715
£9.63
11   (USE 50463) SECTION FRONT P200 & OD13B & C
Remeha-Broag part no. 43141

11   SECTION FRONT
Remeha-Commercial part no. 50463
£2,110.00
12   SECTION INTERMEDIATE P200, OD13, OD13A & OD13B
Remeha-Commercial part no. 50465
£1,478.75
13   SECTION REAR P200 & OD13B (OD13 & OD13A FLOOR PROFILE TO BE SHORTENED)
Remeha-Commercial part no. 50467
£2,151.25
14   TIE ROD BRACKET / HOOK
Remeha-Commercial part no. 18564
£11.10
15 Part number 20017, Nipple NIPPLE
Remeha-Commercial part no. 20017
£26.25
16   FLANGE BLANK
Remeha-Commercial part no. 19262
£43.75
17   FLANGE DRILLED
Remeha-Commercial part no. 19263
£53.75
18   RETARDER 2ND PASS 4 - 8 SECTION (2 REQUIRED PER BOILER)
Remeha-Commercial part no. 43776
£33.75
19 Part number 43777, Retarder 3rd pass (2 required per boiler) RETARDER 3RD PASS (2 REQUIRED PER BOILER)
Remeha-Commercial part no. 43777
£93.75
20 Part number S45004, Glass inspection c/w gasket 32x32x3mm and screws GLASS INSPECTION C/W GASKET 32X32X3MM AND SCREWS
Remeha-Commercial part no. S45004
£41.25
21   FLUE HOOD 4 TO 7 SECTION
Remeha-Commercial part no. 46632
£142.50
22   FLUE HOOD 8 TO 12 SECTION
Remeha-Commercial part no. 46633
£63.75
23   CONNECTION PIECE FLOW 4 TO 7 SECTION
Remeha-Commercial part no. 51258
£317.50
24   CONNECTION PIECE FLOW 8 TO 12 SECTION
Remeha-Commercial part no. 51260
£317.50
25   CONNECTION PIECE RETURN 4 TO 7 SECTION
Remeha-Commercial part no. 51262
£312.50
26   CONNECTION PIECE RETURN 8 TO 12 SECTION
Remeha-Commercial part no. 51263
£286.25
27   PRESSURE SWITCH TYPE DUNGS
Remeha-Commercial part no. S20862
£362.50
27 Part number S51902, Pressure switch type aqua PRESSURE SWITCH TYPE AQUA
Remeha-Commercial part no. S51902
£222.50
28 Part number 43798, Door snapper female (NEW PART NO. S43798) DOOR SNAPPER FEMALE (NEW PART NO. S43798)
Remeha-Broag part no. 43798

28 Part number S43798, Door Snapper Female (10 pcs) DOOR SNAPPER FEMALE (10 PCS)
Remeha-Commercial part no. S43798
£18.75
29 Part number 43799, (USE S43799) Door snapper male (USE S43799) DOOR SNAPPER MALE
Remeha-Broag part no. 43799

29 Part number S43799, Door Snapper Male (10 pcs) DOOR SNAPPER MALE (10 PCS)
Remeha-Commercial part no. S43799
£15.00
30   INSERT PIECE FOR CASINGS
Remeha-Broag part no. 45911
£0.31
31   CONT. SPRING L&G NR 4211.1785.0
Remeha-Commercial part no. 19265
£10.38
32   SUPPORT L&G THERMOSTAT
Remeha-Commercial part no. 19266
£10.38
34   (OBSOLETE) SEAL TAPAKIT 300 CC.
Remeha-Broag part no. 35208
£24.12
36 Part number S53282, Switch On/Off 40c1350al with cap SWITCH ON/OFF 40C1350AL WITH CAP
Remeha-Commercial part no. S53282
£23.75
37 Part number S45309, Thermometer water temperature 0-120 THERMOMETER WATER TEMPERATURE 0-120
Remeha-Commercial part no. S45309
£43.75
39 Part number S36446, Thermostat TEM high limit 110 C l&g rak 77.4471 THERMOSTAT TEM HIGH LIMIT 110 C L&G RAK 77.4471
Remeha-Commercial part no. S36446
£78.75
40 Part number S46634, Thermostat control & H/L 35-95 degrees THERMOSTAT CONTROL & H/L 35-95 DEGREES
Remeha-Commercial part no. S46634
£40.00
41   OBSOLETE KNOB FOR CONTROL THERMOSTAT
Remeha-Broag part no. 51098

42   KNOB FOR HIGH/LOW THERMOSTAT
Remeha-Commercial part no. 51099
£10.08
43 Part number 1035, (USE S103279) Pressure test nipple 1/8 (USE S103279) PRESSURE TEST NIPPLE 1/8
Remeha-Broag part no. 1035

43 Part number S103279, Pressure Test Nipple 1/8" Incl Loctite PRESSURE TEST NIPPLE 1/8" INCL LOCTITE
Remeha-Commercial part no. S103279
£25.00
44   INSULATION DOOR QUARL
Remeha-Commercial part no. 40257
£95.00
45   INSULATION BURNER MOUNTING PLATE P200
Remeha-Commercial part no. 43812
£46.25
46   INSULATION BOILER DOOR FRONT
Remeha-Commercial part no. 51242
£68.75
48   NUT BRASS M12
Remeha-Commercial part no. 19623
£1.88
49   HINGE ASSEMBLY OD13A, OD13B & P200
Remeha-Commercial part no. 20019
£65.00
50   DOOR - P200
Remeha-Commercial part no. 49116
£823.75
51   (USE 50914) (DISCONTINUED) INSULATION DOOR CERAMIC
Remeha-Broag part no. 49181

51   SEAL KIT FRONT DOOR OD13B/P200 (QUARL & FRONT PLATE INSULATION & ROPE)
Remeha-Commercial part no. 50914
£810.00
52   FLUE GAS COLLECTOR
Remeha-Commercial part no. 50469
£787.50
54 Part number 47472, Cover control facia panel COVER CONTROL FACIA PANEL
Remeha-Commercial part no. 47472
£112.50
55   COVER PLATE FOR WATER DISTRIBUTION PIPE
Remeha-Commercial part no. 34943
£31.25
