RIELLO
GULLIVER RS5F 3761971 (TYPE 920T1) - (Exploded View)
Appliance Code: 3761971

Appliance Diagram


Exploded View diagram for Riello Gulliver RS5F 3761971 (Type 920T1)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 3008496, COVER COVER
Riello part no. 3008496		 £75.11
2 Part number 3002979, LEAD LEAD
Riello part no. 3002979		 £47.96
3 Part number 3002972, LEAD LEAD
Riello part no. 3002972		 £24.99
4 Part number 3007458, VIEWING PORT VIEWING PORT
Riello part no. 3007458		 £7.99
5 Part number 3007642, COVER COVER
Riello part no. 3007642		 £8.00
6   ELBOW
Riello part no. 3007979		 £24.99
7   BRACKET AND SCREW
Riello part no. 3008505		 £23.99
8 Part number 3002560, GASKET 10 PCS GASKET 10 PCS
Riello part no. 3002560		 £12.07
9 Part number 3008504, TUBE X 8 TUBE X 8
Riello part no. 3008504		 £90.37
10 Part number 3008501, AIR DIFFUSER AIR DIFFUSER
Riello part no. 3008501		 £29.99
11   ELBOW EXTENSION
Riello part no. 3007992		 £28.99
12   DISTRIBUTOR
Riello part no. 3002969		 £41.99
13   LEAD
Riello part no. 3002494		 £18.83
14 Part number 3007988, PROBE FOR BS3D PROBE FOR BS3D
Riello part no. 3007988		 £23.69
15 Part number 3008932, ELECTRODE (WAS 3008495) ELECTRODE (WAS 3008495)
Riello part no. 3008932		 £17.23
16 Part number 3008506, MOTOR MOTOR
Riello part no. 3008506		 £160.10
17 Part number 3007454, MOTOR SOCKET MOTOR SOCKET
Riello part no. 3007454		 £28.86
18 Part number 3007265, U BOLT (10 PCS) U BOLT (10 PCS)
Riello part no. 3007265		 £12.07
19 Part number 3008552, SUCTION DUCT SUCTION DUCT
Riello part no. 3008552
20 Part number 3008494, FAN FAN
Riello part no. 3008494		 £100.21
21   TEST POINT
Riello part no. 3005447		 £10.17
22 Part number 3008005, O RING SEAL PACK O RING SEAL PACK
Riello part no. 3008005		 £7.99
23 Part number 3008502, MANIFOLD MANIFOLD
Riello part no. 3008502		 £91.96
24   FLAME TUBE
Riello part no. 3002469		 £162.09
25   GASKET
Riello part no. 3008500		 £8.13
26 Part number 3008493, MOVABLE FLANGE MOVABLE FLANGE
Riello part no. 3008493		 £34.99
27 Part number 3002455, AIR DAMPER REGULATOR AIR DAMPER REGULATOR
Riello part no. 3002455		 £18.99
28   AIR DAMPER
Riello part no. 3002866		 £31.50
29   CONNECTOR
Riello part no. 3006605		 £8.02
30 Part number 20087038, CAPACITOR CAPACITOR
Riello part no. 20087038		 £43.76
31 Part number 3008017, CONNECTOR AND TUBE CONNECTOR AND TUBE
Riello part no. 3008017		 £8.86
32 Part number 3007444, AIR PRESSURE SW (REPLACES 8016 AIR PRESSURE SW (REPLACES 8016
Riello part no. 3007444		 £82.16
33 Part number 3006937, PLUG - 7 PIN - MALE PLUG - 7 PIN - MALE
Riello part no. 3006937		 £7.19
34 Part number 3002967, CONTROL BOX CONTROL BOX
Riello part no. 3002967		 £201.03
35 Part number 3002971, ASSEMBLY CONNECTION ASSEMBLY CONNECTION
Riello part no. 3002971		 £22.99
36 Part number 3008491, ELECTRODE LEAD (5 pcs) ELECTRODE LEAD (5 PCS)
Riello part no. 3008491		 £98.69
37 Part number 3008490, HT LEAD HT LEAD
Riello part no. 3008490		 £52.28
