RIELLO
RDB4.2 FIREBIRD C73/250 K 20039514 (TYPE 490 T61) - (Burner Diagram)
Appliance Code: 20039514

Appliance Diagram


Burner Diagram diagram for Riello RDB4.2 Firebird C73/250 K 20039514 (Type 490 T61)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 20039514, RDB4.2 Burner, C73/250K RDB4.2 BURNER, C73/250K
Riello part no. 20039514		 £372.00
1 Part number 3008637, OBSOLETE FLANGE FOR RDB3 OBSOLETE FLANGE FOR RDB3
Riello part no. 3008637		 £15.27
2 Part number 3006392, DISC WITH RING (3 LEGS) DIFFUSER DISC WITH RING (3 LEGS) DIFFUSER
Riello part no. 3006392		 £52.96
3 Part number 3006151, BLAST TUBE 4.5 BLAST TUBE 4.5
Riello part no. 3006151		 £68.37
4 Part number 3008538, ELECTRODE ELECTRODE
Riello part no. 3008538		 £15.45
5 Part number 3006552, ELECTRODE CLAMP (10 PCS) ELECTRODE CLAMP (10 PCS)
Riello part no. 3006552		 £18.53
6   NOZZLE HOLDER
Riello part no. 3008954		 £18.93
7 Part number 3008963, SEAL KIT SEAL KIT
Riello part no. 3008963		 £9.40
8   H T CONNECTION
Riello part no. 3008956		 £7.79
9 Part number 3008839, AIR DAMPER ASSEMBLY AIR DAMPER ASSEMBLY
Riello part no. 3008839		 £73.52
10   DAMPER ACOUSTIC INSERT
Riello part no. 3008958		 £24.01
11   RDB3 COVER
Riello part no. 3008962		 £85.89
12 Part number 3005799, FAN FAN
Riello part no. 3005799		 £38.68
13 Part number 3008646, PHOTOCELL PHOTOCELL
Riello part no. 3008646
15 Part number 20081251, CAPACITOR P2 RDB 3&4 CAPACITOR P2 RDB 3&4
Riello part no. 20081251		 £20.60
16 Part number 3003602, CONNECTOR (G5BF) CONNECTOR (G5BF)
Riello part no. 3003602		 £4.22
17 Part number 20022601, Oil Hose Line 3/8" Angled Male 3/8" OIL HOSE LINE 3/8" ANGLED MALE 3/8"
Riello part no. 20022601		 £17.80
17 Part number 3005720, NOW USE 20022601 FLEXIBLE PIPE NOW USE 20022601 FLEXIBLE PIPE
Riello part no. 3005720
19 Part number 3008876, PRESSURE GAUGE EXTENSION (RDB) PRESSURE GAUGE EXTENSION (RDB)
Riello part no. 3008876		 £14.26
20 Part number 3000443, COUPLING (10PCS) COUPLING (10PCS)
Riello part no. 3000443		 £7.40
21 Part number 3008648, COIL COIL
Riello part no. 3008648		 £20.09
22   COLLAR FOR RDB
Riello part no. 3008957		 £29.43
23 Part number 3008649, PROTECTION PROTECTION
Riello part no. 3008649		 £3.15
24 Part number 3008652, CONTROL BOX 535 SE/LD CONTROL BOX 535 SE/LD
Riello part no. 3008652		 £119.35
25 Part number 3008851, H T LEADS ( WAS 3008877) H T LEADS ( WAS 3008877)
Riello part no. 3008851		 £7.00
26   TUBE
Riello part no. 3008961		 £12.86
27 Part number 20030953, RIELLO - OIL PUMP RIELLO - OIL PUMP
Riello part no. 20030953		 £119.54
28 Part number 3020436, PUMP FILTER 3020436 RDB 3008653 PUMP FILTER 3020436 RDB 3008653
Riello part no. 3020436		 £8.00
29 Part number 3007871, NEEDLE VALVE NEEDLE VALVE
Riello part no. 3007871		 £25.98
30 Part number 20032135, PRESSURE REGULATOR PRESSURE REGULATOR
Riello part no. 20032135		 £4.66
31   4 PIN PLUG
Riello part no. 3007418		 £14.99
32 Part number 3005795, FLANGE GASKET (WAS 3008012) FLANGE GASKET (WAS 3008012)
Riello part no. 3005795		 £7.37
