VAILLANT
ECOTEC PLUS 612, 615, 618, 624, 630, 637 - (04 Burner Sheet 2)
Appliance Code: ECOTEC PLUS 612, 615, 618, 624, 630, 637

Appliance Diagram


04 Burner Sheet 2 diagram for Vaillant Ecotec Plus 612, 615, 618, 624, 630, 637Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020135129, Heat exchanger HEAT EXCHANGER
Vaillant part no. 0020135129		 £545.48
1 Part number 0020135131, Heat exchanger HEAT EXCHANGER
Vaillant part no. 0020135131		 £556.39
1 Part number 0020135133, Heat exchanger HEAT EXCHANGER
Vaillant part no. 0020135133		 £635.45
1 Part number 0020135134, Heat exchanger HEAT EXCHANGER
Vaillant part no. 0020135134		 £648.17
2 Part number 981233, Lip seal EPDM (DN 60) LIP SEAL EPDM (DN 60)
Vaillant part no. 981233		 £7.79
3 Part number 0020135107, Cable CABLE
Vaillant part no. 0020135107		 £9.24
3 Part number 0020135108, Cable CABLE
Vaillant part no. 0020135108		 £9.24
3 Part number 0020135109, Cable CABLE
Vaillant part no. 0020135109		 £9.77
3 Part number 0020135110, Cable CABLE
Vaillant part no. 0020135110		 £9.77
4 Part number 0020135117, Support, heat exchanger SUPPORT, HEAT EXCHANGER
Vaillant part no. 0020135117		 £6.86
5 Part number 0020135112, Support PHE SUPPORT PHE
Vaillant part no. 0020135112		 £9.24
5 Part number 0020135113, Support PHE SUPPORT PHE
Vaillant part no. 0020135113		 £9.77
5 Part number 0020135114, Support PHE SUPPORT PHE
Vaillant part no. 0020135114		 £10.44
5 Part number 0020135115, Support PHE SUPPORT PHE
Vaillant part no. 0020135115		 £11.08
6 Part number 0020135116, Support PHE top SUPPORT PHE TOP
Vaillant part no. 0020135116		 £6.86
7 Part number 0020133828, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020133828		 £6.86
8 Part number 0020136643, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020136643		 £6.86
9 Part number 0020093190, Insulation, 16 mm with nut and washer INSULATION, 16 MM WITH NUT AND WASHER
Vaillant part no. 0020093190		 £53.62
9 Part number 0020143489, Insulation, 16 mm with clips INSULATION, 16 MM WITH CLIPS
Vaillant part no. 0020143489		 £35.01
12 Part number 049324, Burner BURNER
Vaillant part no. 049324		 £110.07
12 Part number 049345, Burner BURNER
Vaillant part no. 049345		 £105.26
12 Part number 050430, Burner BURNER
Vaillant part no. 050430		 £134.78
13 Part number 105900, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 105900		 £6.86
14 Part number 981103, Gasket burner GASKET BURNER
Vaillant part no. 981103		 £8.88
15 Part number 193595, insulation INSULATION
Vaillant part no. 193595		 £26.37
16 Part number 0020038679, Gasket kit GASKET KIT
Vaillant part no. 0020038679		 £19.87
17 Part number 0020135118, Flange FLANGE
Vaillant part no. 0020135118		 £138.02
18 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537		 £6.86
19 Part number 193597, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 193597		 £6.89
20 Part number 193594, Gasket GASKET
Vaillant part no. 193594		 £6.89
21 Part number 161245, inspection glass INSPECTION GLASS
Vaillant part no. 161245		 £6.86
22 Part number 0020133816, ELECTRODE ELECTRODE
Vaillant part no. 0020133816		 £25.87
23 Part number 981330, gasket electrode GASKET ELECTRODE
Vaillant part no. 981330		 £6.40
24 Part number 118937, Pan head screw (M 5x12) PAN HEAD SCREW (M 5X12)
Vaillant part no. 118937		 £5.13
25 Part number 0020135119, Cable CABLE
Vaillant part no. 0020135119		 £21.92
27 Part number 0020135121, Clamp CLAMP
Vaillant part no. 0020135121		 £6.86
29 Part number 0020141345, Siphon/trap SIPHON/TRAP
Vaillant part no. 0020141345		 £25.85
30 Part number 0020077919, O-ring, (PK5) O-RING, (PK5)
Vaillant part no. 0020077919		 £7.84
31 Part number 0020144602, Hose, condensate HOSE, CONDENSATE
Vaillant part no. 0020144602		 £7.34
