VAILLANT
MAG-SINE 325/9 W 1993-1995 - (08A Connection Parts)
Appliance Code: 325/9 W

Appliance Diagram


08A Connection Parts diagram for Vaillant Mag-Sine 325/9 W 1993-1995Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE COLD WATER TUBE
Vaillant part no. 083799

2   WARM WATER TUBE
Vaillant part no. 083965

3 Part number 981143, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981143
£6.28
4 Part number 981141, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981141
£6.28
5   OBSOLETE GAS CONNECTION
Vaillant part no. 080008

6   OBSOLETE GAS FILTER
Vaillant part no. 108905

7   OBSOLETE GAS CONNECTION
Vaillant part no. 082538

8   OBSOLETE GAS FILTER
Vaillant part no. 108921

9   SEALING RING
Vaillant part no. 981756
£5.13
10   PLUG
Vaillant part no. 137262
£9.76
17 Part number 981162, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981162
£5.13
18   OBSOLETE GAS CONNECTION
Vaillant part no. 082599

20 Part number 080177, nut NUT
Vaillant part no. 080177
£6.28
21 Part number 080184, Compression ring, 20 mm COMPRESSION RING, 20 MM
Vaillant part no. 080184
£6.28
22   OBSOLETE CONNECTION PIECE
Vaillant part no. 083629

25 Part number 235727, screw SCREW
Vaillant part no. 235727
£5.13
27 Part number 0020085467, Gasket GASKET
Vaillant part no. 0020085467
£6.17
