VAILLANT
THERMOCOMPACT 620E VU 202/2-5 R1 2002-2003 - (06 Heat Exchanger R1)
Appliance Code: 41-044-24-R1

Appliance Diagram


06 Heat Exchanger R1 diagram for Vaillant Thermocompact 620E VU 202/2-5 R1 2002-2003Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 104593, Heat Exchanger (83 Fins) HEAT EXCHANGER (83 FINS)
Vaillant part no. 104593		 £369.38
2 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £21.39
3 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £7.42
4 Part number 219621, Spring clamp, (PK10) SPRING CLAMP, (PK10)
Vaillant part no. 219621		 £8.95
5 Part number 0020107695, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020107695		 £6.28
6 Part number 117547, Combustion chamber COMBUSTION CHAMBER
Vaillant part no. 117547		 £104.95
6A Part number 0020082195, Insulation (set) INSULATION (SET)
Vaillant part no. 0020082195		 £38.66
