VOKERA
18/72 DMCF COMBINATION BOILER - (Assembly 8)
Appliance Code: 47-094-04

Appliance Diagram


Assembly 8 diagram for Vokera 18/72 DMCF Combination BoilerClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number T0002, 3 Port Valve Service Kit 3 PORT VALVE SERVICE KIT
Vokera part no. T0002
£52.84
1 Part number 0139, 3 Way Valve Tail Plate 3 WAY VALVE TAIL PLATE
Vokera part no. 0139
£25.46
2 Part number 0159, 3 Way Valve Head Shaft 3 WAY VALVE HEAD SHAFT
Vokera part no. 0159
£34.00
3 Part number 0184, Extension Shaft EXTENSION SHAFT
Vokera part no. 0184
£34.07
4 Part number 0216, Front Seal FRONT SEAL
Vokera part no. 0216
£4.84
5   OBSOLETE CLAMP SCREW 3 PORT VALVE TO MANIFOLD
Vokera part no. 0217

6 Part number 0218, Retaining Ring RETAINING RING
Vokera part no. 0218
£5.75
7 Part number 0219, Shuttle SHUTTLE
Vokera part no. 0219
£20.16
8   SCREW
Vokera part no. 0220

9   WASHER
Vokera part no. 0221
£0.96
10 Part number 0226, Diaphragm (6 Screw) DIAPHRAGM (6 SCREW)
Vokera part no. 0226
£7.16
11 Part number 0309, Front Seal FRONT SEAL
Vokera part no. 0309
£13.22
12 Part number 0341, Fibre Washer FIBRE WASHER
Vokera part no. 0341
£2.06
13   MAIN JETS NG 1.25 DIAMETER
Vokera part no. 0357

16   BY PASS PLUG
Vokera part no. 0364

17   BY PASS SPRING
Vokera part no. 0365

19   DOMESTIC WATER FLOW REGULATING SCREW
Vokera part no. 0367

20   WASHER
Vokera part no. 0371
£1.47
21   ALUMINIUM WASHER
Vokera part no. 0373

22   VENTURI
Vokera part no. 0381
£2.97
23 Part number 0394, NG Spring NG SPRING
Vokera part no. 0394
£2.27
24   GAS VALVE SOLENOID 220/240V
Vokera part no. 0402

25 Part number 0536, Nylon Plate NYLON PLATE
Vokera part no. 0536
£10.88
26   AUTO BY-PASS RETAINING CAP
Vokera part no. 0549

27   OBSOLETE WASHER
Vokera part no. 0551

28   SPRING FOR AUTO BY-PASS (LARGE)
Vokera part no. 0552

29   OBSOLETE AUTO BY-PASS BOBBIN
Vokera part no. 0553

30   O-RING
Vokera part no. 0554
£0.44
31 Part number 0555, Spring SPRING
Vokera part no. 0555
£1.18
32 Part number 0556, By-pass Bearer Plate BY-PASS BEARER PLATE
Vokera part no. 0556
£4.41
33 Part number 0557, Diaphragm DIAPHRAGM
Vokera part no. 0557
£6.08
34   AUTO BY-PASS CONNECTING TUBE
Vokera part no. 3183

35 Part number 3207, 3 Port Valve 3 PORT VALVE
Vokera part no. 3207
£135.81
35   MECHANICAL 3 WAY VALVE
Vokera part no. 4495

36   DISTRIBUTION MANIFOLD WITH AUTO BY-PASS
Vokera part no. 3208

37 Part number 3212, Heating Thermostat HEATING THERMOSTAT
Vokera part no. 3212

38   OBSOLETE LINT GUARD
Vokera part no. 3368

40   OBSOLETE MOUNTING PLATE - BLACK
Vokera part no. 3388

41   O-RING FOR PUMP UNION
Vokera part no. 3740

42   NUT
Vokera part no. 4061

43   15MM OLIVE
Vokera part no. 4062

44   NUT (FOR F/R VALVES 4539)
Vokera part no. 4064

45   22MM OLIVE (FLOW AND RETURN VALVES)
Vokera part no. 4065

46   HOT WATER OUTLET NUT AND TAIL
Vokera part no. 4095

48   PUMP UNION NUT
Vokera part no. 4114

49 Part number 4148, Triple Microswitch TRIPLE MICROSWITCH
Vokera part no. 4148
£29.97
50 Part number 4250, Safety Valve (Screw Fit) SAFETY VALVE (SCREW FIT)
Vokera part no. 4250
£13.37
51 Part number 4254, Automatic Air Vent AUTOMATIC AIR VENT
Vokera part no. 4254
£11.99
52 Part number 4302, Microswitch MICROSWITCH
Vokera part no. 4302
£17.36
53   CYLINDER VENTING PLUG
Vokera part no. 4321

54   SINGLE MICRO SWITCH COVER
Vokera part no. 4332

55   OBSOLETE FLUE DRAUGHT DIVERTER
Vokera part no. 4343

55   OBSOLETE FLUE DRAUGHT DIVERTER
Vokera part no. 4344

56 Part number 4441, Temperature Gauge (rep 7171) TEMPERATURE GAUGE (REP 7171)
Vokera part no. 4441
£20.48
57   OBSOLETE BLANKING PLATE T/CLOCK APERTURE
Vokera part no. 4452

58   PRESSURE GAUGE (CLAMP OR PUSH FIT)
Vokera part no. 4472

59   EXPANSION PIPE
Vokera part no. 4489

60   MAIN HEATING RETURN WITH UNION
Vokera part no. 4490

61 Part number 4492, Expansion Vessel EXPANSION VESSEL
Vokera part no. 4492
£92.84
62   HEATING FLOW PIPE WITH UNION
Vokera part no. 4496

63 Part number 4518, Domestic Expansion Vessel DOMESTIC EXPANSION VESSEL
Vokera part no. 4518

64   OBSOLETE MAIN FLOW PIPE WITH AIR SEPARATOR
Vokera part no. 4523

66   GAS CONNECTING BARREL
Vokera part no. 4535

67   OBSOLETE GAS VALVE MOUNTING BRACKET
Vokera part no. 4536

69 Part number 4539, FLOW RETURN VALVE FLOW RETURN VALVE
Vokera part no. 4539

71   COCK
Vokera part no. 4541

72   CONNECTION FOR DOM EXP VESSEL
Vokera part no. 4544
£3.48
73   HEAT EXCHANGER
Vokera part no. 4545

73 Part number 4549, Domestic Heat Exchanger DOMESTIC HEAT EXCHANGER
Vokera part no. 4549

74   PCB
Vokera part no. 4546

77   EXPANSION VESSEL FIXING BRACKET
Vokera part no. 4581

78   OBSOLETE NUT
Vokera part no. 0599

79   OBSOLETE MOUNTING RING
Vokera part no. 4626

80 Part number 4632, ELECTRODE ELECTRODE
Vokera part no. 4632

81 Part number 4640, Gas Valve GAS VALVE
Vokera part no. 4640
£206.90
82   SPRING FOR GAS REGULATOR LPG
Vokera part no. 4668

84   TAIL PLATE SEAL
Vokera part no. 4723

85 Part number 4875, Case Clips CASE CLIPS
Vokera part no. 4875

85   ELEC. MAGNETIC COMP. + SPRING + CORE
Vokera part no. 4751

86   OBSOLETE MAIN HEAT EXCHANGER
Vokera part no. 4755

86   MAIN HEAT EXCHANGER RS TURBO
Vokera part no. 4333

87   OBSOLETE ELECTRIC WIRE LOCKING SLEEVE
Vokera part no. 4838

89   FINGER GUARD
Vokera part no. 4881

90 Part number 5394, Domestic Thermostat DOMESTIC THERMOSTAT
Vokera part no. 5394

91 Part number 4891, Pilot Jet NG.27 PILOT JET NG.27
Vokera part no. 4891
£0.89
92 Part number 4893, Pilot Jet LPG 22 PILOT JET LPG 22
Vokera part no. 4893
£1.00
93   MAIN BURNER NG
Vokera part no. 4918

96   OBSOLETE GREY CONTROL PANEL
Vokera part no. 4898

97   MAIN BURNER SUPPORTING SHAFT
Vokera part no. 4925

99   PILOT PIPE
Vokera part no. 4932

100   THERMOSTAT KNOB
Vokera part no. 4936

101 Part number 4961, Thermocouple THERMOCOUPLE
Vokera part no. 4961
£9.45
102 Part number 4962, Domestic Distribution Manifold DOMESTIC DISTRIBUTION MANIFOLD
Vokera part no. 4962

103   DOMESTIC HEAT EXCHANGER RETURN PIPE
Vokera part no. 4965

104   SPACER FOR THERMOSTATS
Vokera part no. 4976

105   NOW USE 4888 HIGH LIMIT THERMOSTAT
Vokera part no. 4978

105 Part number 4888, H/l Stat (replaces 6399) H/L STAT (REPLACES 6399)
Vokera part no. 4888
£41.49
106 Part number 4980, On/Off Switch ON/OFF SWITCH
Vokera part no. 4980

107   SWITCH
Vokera part no. 4981

109 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
110   FIBRE WASHER (PRESSURE GAUGE)
Vokera part no. 5024

111 Part number 5025, WASHER WASHER
Vokera part no. 5025
£0.92
112 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
113   PUMP WASHER
Vokera part no. 5036
£0.96
114 Part number 5038, Washer WASHER
Vokera part no. 5038
£0.44
115   WASHER
Vokera part no. 5039
£0.44
116 Part number 5041, Washer WASHER
Vokera part no. 5041
£0.19
117 Part number 5049, Gasket GASKET
Vokera part no. 5049
£0.55
118   SEAL
Vokera part no. 5068
£0.51
120 Part number 5070, Fibre Washer FIBRE WASHER
Vokera part no. 5070
£0.30
121 Part number 5071, Fibre Washer FIBRE WASHER
Vokera part no. 5071
£0.25
122   OBSOLETE SPLIT PIN FOR AIR SEPARATOR
Vokera part no. 5117

123   SCREW
Vokera part no. 5124
£0.30
124 Part number 5128, Edge Clip EDGE CLIP
Vokera part no. 5128
£0.21
125   OBSOLETE CUP WASHER
Vokera part no. 5138

126   EDGE CLIP FOR 4577
Vokera part no. 5143

127   NOW USE 20109067 PUMP 25-50
Vokera part no. 6090

127   ERP PUMP - REPLACED 6090 AND 6110
Vokera part no. 20109067
£141.00
